WARNING: Fire hazard. Collected sanding dust from
sanding surface coatings (polyurethane, linseed
oil, etc.) can self‑ignite and cause fire. To reduce
risk, strictly follow sander manual and coating
manufacturer's instructions.
WARNING: Fire hazard. When sanding wood that
could contain nails or when sanding metal surfaces, do
not use a dust bag or a vacuum cleaner because sparks
are generated. Instead, attach the deflector with the
open area facing away from your body. Wear safety
glasses and a dust mask. Due to the danger of fire, do
not use your sander to sand magnesium surfaces. Do
not use for wet sanding.
Applications
Sharpening Knife (Fig. H, I)
1. Attach the knife sharpener
"Attaching and Removing Knife Sharpener" section.
2. On a flat surface, rest the Power Unit face down so the
the front of the battery and the tool housing raise the
sanding arm
2
off the table.
nOTE: Keep sander away from other objects and surfaces
while in use to avoid sanding other objects.
3. Depress the variable‑speed trigger on the Power Unit.
4. Hold the knife tightly. Point the point of the knife
the left and rest the blade of the knife fully on the Front
Knife Edge Angle
7
so your knife is at an angle to the
sanding belt
3
.
5. Slide the knife to the right 2 to 3 times.
6. Rest the other side of the blade against the Back Knife Edge
Angle
8
so your knife is at an angle to the sanding belt.
7. Slide the knife to the right 2 to 3 times.
8. Test the sharpness of the knife.
9. Repeat if needed.
Hints for Optimum Use
•
Do not exert too much pressure on the tool.
•
Regularly check the condition of the sanding belt.
Replace when necessary.
•
Always sand with the grain of the wood.
•
Always start your sander before it is in contact with the
workpiece and do not switch it off until after it has been
lifted from the workpiece.
•
Where possible, clamp the workpiece to a work bench or
similar sturdy surface.
•
When sanding new layers of paint before applying
another layer, use extra fine grit.
•
On very uneven surfaces, or when removing layers of
paint, start with a coarse grit. On other surfaces, start with
a medium grit. In both cases, gradually change to a fine
grit for a smooth finish.
•
Use the correct grit sanding belt for your application.
The following is a suggested list of belt grits to use with
different materials.
MATERiAl
Paint Removal
6
as described in the
BElT gRiT
40/60
Chipboard
Solid Wood
Steel
Plastics
Balsa Wood
Acrylic
Knife Sharpening
Veneer
MAINTENANCE
WARNING: To reduce the risk of serious personal
injury, turn unit off and remove the battery pack
before making any adjustments or removing/
installing attachments or accessories. An
accidental start‑up can cause injury.
Your BLACK+DECKER power tool has been designed to
operate over a long period of time with a minimum of
maintenance. Continuous satisfactory operation depends
upon proper tool care and regular cleaning.
Cleaning
WARNING: Never use solvents or other harsh
chemicals for cleaning the non‑metallic parts of the
tool. These chemicals may weaken the plastic materials
used in these parts. Use a cloth dampened only with
19
to
water and mild soap. Never let any liquid get inside the
tool; never immerse any part of the tool into a liquid.
Accessories
WARNING: Since accessories, other than those
offered by BLACK+DECKER, have not been tested with
this product, use of such accessories with this tool
could be hazardous. To reduce the risk of injury, only
BLACK+DECKER recommended accessories should be
used with this product.
Recommended accessories for use with your tool are available
at extra cost from your local dealer or authorized service
center. If you need assistance in locating any accessory, please
contact BLACK+DECKER call 1‑800‑544‑6986.
Repairs
The charger and battery pack are not serviceable. There are
no serviceable parts inside the charger or battery pack.
WARNING: To assure product SAFETY and RELIABILITY,
repairs, maintenance and adjustment (including brush
inspection and replacement, when applicable) should
be performed by a BLACK+DECKER factory service
center or a BLACK+DECKER authorized service center.
Always use identical replacement parts.
Register Online
Thank you for your purchase. Register your product now for:
• WARRAnTY sERViCE: Registering your product will
help you obtain more efficient warranty service in case
there is a problem with your product.
60/80
80
80
100
100
100
120
150
