Page 2: Table Of Contents
4.6. OUT recording connection ............................8 PLACEMENT OF THE BATTERY ..............................9 COMMISSIONING THE UNIT ..............................11 6.1. Configuration of the FU-700ETH network address ...................... 11 OPERATING SYSTEM RECOVERY ............................12 PUBLIC ADDRESS ANNOUNCEMENTS OPERATIONS ......................13 8.1. Sending a live voice announcement to one or several zones or groups ..............13 8.2. -
Page 3: Introduction
(8) TALK indicator. Illuminates when TALK, GONG+TALK or hand-held microphone talk button is pressed, indicating that you can begin speaking. (9) GENERAL FAULT indicator. Yellow LED system alarm indicator. (10) POWER. Power supply indicator. (11) CPU FAULT indicator. Internal error indicator of the application. FU-700ETH version 4.3.000... - Page 4 Selection of the group: A group is assigned to the key using the PA Manager software. When the key is pressed, the assigned group will be pre-selected and the LED will illuminate. When a live voice message, or pre-recorded message is activated, the message will be broadcast in that group. FU-700ETH version 4.3.000...
- Page 5 IN CALL LED. The indicator is blinking when an incoming call is present. g) CLEAR Key. Clear intercom selection. h) TALK LED. When ON indicates that is possible to talk. When OFF, indicates cannot talk. i) TALK/LISTEN Key. It allows talk – listen in the intercom communication. FU-700ETH version 4.3.000...
-
Page 6: Rear View
Connectors IN “L” and IN “R” RCA type connectors. Allow connecting a music source using the FU-700ETH as a way to input analogue audio and send this music programme via IP through the ETH connectors. To connect follow section 4.5. -
Page 7: Connections
4.2. Secondary power supply 24V DC Power supply I924K25 Figure 5 (Not included) POWER JACK PLUG CONNECTOR IEC 60130-10 Type A, outer diameter = 5.5mm, inner diameter = 2.1mm 4.3. Ethernet connection Figure 6 Connection to the Ethernet switch FU-700ETH version 4.3.000... -
Page 8: Connection In Installations With A Redundant Ethernet Network
Figure 7 Connection to the Ethernet switch 1 Connection to the Ethernet switch 2 4.5. Connection of a music source to the paging desk Figure 8 From music source 4.6. OUT recording connection Figure 9 To recording system FU-700ETH version 4.3.000... -
Page 9: Placement Of The Battery
Do not throw used batteries into the household waste. The batteries must be deposited in a collection point for used batteries. Battery placement procedure: Disconnect the equipment Remove the cover by removing the fasten screws. Figure 10 FU-700ETH version 4.3.000... - Page 10 Ethernet flush mounted Microphone FU-700ETH desk with intercom Insert the battery respecting the polarity indicated in the figure 11. Figure 11 Reassemble the cover and connect the equipment FU-700ETH version 4.3.000...
-
Page 11: Commissioning The Unit
To commission the paging desk we must send configurations to it via an ethernet connection. Accomplishing this requires a PC equipped with a network card and connected to the FU-700ETH unit through a switch or directly using a network cable. The PC must have the PA Manager 4.3 software installed. -
Page 12: Operating System Recovery
3. Turn ON the unit. 4. After two minutes, turn OFF the unit. 5. Put de internal dipswitch in OFF position. (NORMAL MODE). 6. Turn ON the FU-700ETH. The unit restarts with default factory values (without configurations and default IP address 10.1.1.1). NORMAL MODE... -
Page 13: Public Address Announcements Operations
The indicator light should go out. 9. INTERCOM OPERATIONS This equipment allows to establish a half-duplex intercommunication system between three FU-700ETH elements. 9.1. Make an intercom call 9.2. Receive an intercom call When receiving an intercom call, the buzzer sounds and the 1. -
Page 14: System Alarms
Connector DIN 5 pins 180°, metal, with thread. Sensitivity -60 dB. Hand-held, dynamic Low impedance Microphone With PTT button 300-6,000 Hz, 2.5 mV/Pa/1 kHz, 500 Ω Twisted cable, 1.5 metres (maximum extension) Weight 3 Kg Finishes Iron front plate, painted RAL9005 black FU-700ETH version 4.3.000... -
Page 15: Dimensions
Ethernet flush mounted Microphone FU-700ETH desk with intercom 12. DIMENSIONS FU-700ETH version 4.3.000... -
Page 16: Optimax2 System Network Specifications
Ports for the SECURE communication services used in the OPTIMAX2 system: Protocol Multicast address Port Others TCP (unicast) TFTP UDP (unicast) Optional TCP (unicast) Between 135 and 139, and 445 Optional UDP (unicast) Between 135 and 139, and 445 FTPS TCP (unicast) FU-700ETH version 4.3.000... - Page 17 UDP Unicast for Local Audio UDP Multicast for Global Audio Multicast snooping: Multicast filtering IGMP v2 For large installations: Multicast Routing (Spanning Tree) Capable to handle TOS (Type Of Service) (*) Multicast addresses and reserved ports Network protocol stack FU-700ETH version 4.3.000...
-
Page 18: Software And Firmware Versions
15. DOCUMENT VERSION TRACKING Reference system Type of Document Confidentiality OPTIMAX2 Installation and operation guide Date Modifications Content Written by: 4.3.000 May 2018 Version R+D Department Approved By Function Date Ferran Gironès i Puig R+D Director 05/2017 FU-700ETH version 4.3.000... -
Page 19: Guarantee
In the event that the guarantee rights do not In order to claim the guarantee rights, it shall be an essential requirement apply, OPTIMUS S.A. shall duly inform the client. If, within a period of 6 weeks to present the original purchase invoice or the guarantee certificate.
