- Page 1 ® System distributor for temporary electrical installations Manual Doc. No. BA001281 Last Update: 04/2022 (Rev. A)
- Page 2 Info NOTES This work is copyrighted material. The resulting rights remain with Wieland Electric GmbH. Any du- plication of this document or parts thereof is permitted only within the limits of the statutory provi- sions of the Copyright Act. Alteration or abridgement of this document without the express written consent of Wieland Electric GmbH is prohibited.
-
Page 3: Table Of Contents
Connections pluggable with self-assembled connectors 6.3.3 Connecting the earthing point Possible system layout Commissioning Operation Type of outlets 9.1.1 Switchable outlets 9.1.2 Non-switchable outlets Use of the 40 kVA distributor Measuring device Wieland Electric GmbH | BA001281 | 04/2022 (Rev. A) - Page 4 Table of contents Maintenance Disassembly 11.1 Disassembly steps 11.2 Storage 11.3 Recommissioning Product disposal Service and support Wieland Electric GmbH | BA001281 | 04/2022 (Rev. A)
-
Page 5: About This Manual
About this manual ABOUT THIS MANUAL Please read this chapter carefully before using the user manual or the products. Scope of application This manual is valid for the following product family: System distributor - gesis WIV. ® Function of this document This manual supports you in the project planning electrical systems and the assembly, installation, commissioning, maintenance and disposal of the system distributors. -
Page 6: Symbols And Notations
Notes concerning the special functions of the device. NOTE Instructions also advise you of a potentially dangerous situation. If the symbol is not observed, it can lead to damage to the system or the system environment. Wieland Electric GmbH | BA001281 | 04/2022 (Rev. A) -
Page 7: Safety
You can find the relevant CE declaration at: https://eshop.wieland-electric.com or via the QR code below. Navigate to the download area of your product. You will then find the CE declaration under the item "EC Declaration of Conformity". Wieland Electric GmbH | BA001281 | 04/2022 (Rev. A) -
Page 8: General Product Information
General product information GENERAL PRODUCT INFORMATION Product description The product is a pre-wired system distributor for pluggable electrical installation with gesis CLAS- ® SIC / gesis MINI / RST CLASSIC. The outlets are pluggable via the installation connector system ap- ®... -
Page 9: Technical Data
* Lead is connected in the distributor ** 20 kVA direct outlets + 20 kVA fused outlet for a 20 kVA distributor *** Connection cable CEE 32A to RST50 included in scope of delivery Wieland Electric GmbH | BA001281 | 04/2022 (Rev. A) - Page 10 • Black connectors • Safety sockets • Residual current and circuit breakers • Wired directly Transfer, on the 40 kVA distributor • RST50 / 5-pole • Circuit breaker, 3-pole, B, 32 A Wieland Electric GmbH | BA001281 | 04/2022 (Rev. A)
-
Page 11: Wiv Gst15 Outlets
* Lead is connected in the distributor ** 20 kVA direct outlets + 20 kVA fused outlet for a 20 kVA distributor *** Connection cable CEE 32A to RST50 included in scope of delivery Wieland Electric GmbH | BA001281 | 04/2022 (Rev. A) - Page 12 • Black connectors • Safety socket • Residual current and circuit breakers • Wired directly Transfer, on the 40 kVA distributor • RST50 / 5-pole • Circuit breaker, 3-pole, B, 32 A Wieland Electric GmbH | BA001281 | 04/2022 (Rev. A)
-
Page 13: Wiv With Rst20 Outlets
** 20 kVA direct outlets + 20 kVA fused outlet for a 20 kVA distributor *** Connection cable CEE 32A to RST50 included in scope of delivery **** Protect the installation distributor and connection cable with CEE plug from direct weathering and UV exposure. Wieland Electric GmbH | BA001281 | 04/2022 (Rev. A) - Page 14 Non-switchable outputs • Black connectors • Residual current and circuit breakers • Wired directly Transfer, on the 40 kVA distributor • RST50 / 5-pole • Circuit breaker, 3-pole, B, 32 A Wieland Electric GmbH | BA001281 | 04/2022 (Rev. A)
-
Page 15: Dimensions
315 × 780 × 156 mm 415 × 1380 × 156 mm Table 1: Overview of dimensions gesis ® * Front side open Figure 2: Front and side view gesis WIV, height 630 mm ® Wieland Electric GmbH | BA001281 | 04/2022 (Rev. A) - Page 16 Dimensions Figure 3: Front and side view gesis ® WIV, height 780 mm Figure 4: Front and side view gesis ® WIV, height 930 mm Wieland Electric GmbH | BA001281 | 04/2022 (Rev. A)
-
Page 17: Mounting
• the system distributor is not exposed to direct sunlight. Exposure to sunlight can lead to an un- authorized increase in temperature, malfunction and premature aging of the components and the housing. Wieland Electric GmbH | BA001281 | 04/2022 (Rev. A) -
Page 18: Connecting The Leads
(cross-sec- tion depends on the distributor). The mounting frame with earthing point is earthed via M8 bolts. Wieland Electric GmbH | BA001281 | 04/2022 (Rev. A) -
Page 19: Possible System Layout
CLASSIC, gesis MINI or RST CLASSIC components. ® ® ® The following articles can be added to the gesis WIV system distributor - sample listing: ® Additional components (illustrative) Valid for 93.053.6009.0 gesis CLASSIC h-distributor, 3-pole (1 input, 2 outputs) ®... -
Page 20: Commissioning
During installation and commissioning, you must make sure that the necessary EMC directives are complied with. For further details on the mechanical or electrical data, see the enclosed documentation in the scope of delivery or at https://eshop.wieland-electric.com Wieland Electric GmbH | BA001281 | 04/2022 (Rev. A) -
Page 21: Operation
These outlets cannot be switched via the main switch but are fused, so that voltage is present at these outlets as soon as the system distributor is in operation. Wieland Electric GmbH | BA001281 | 04/2022 (Rev. A) -
Page 22: Use Of The 40 Kva Distributor
If your installation distributor has a measuring device, it must be put into operation. Please read the operating instructions of the manufacturer's measuring device. The recommissioning (e.g. resetting RCD) can be carried out by trained laypersons. NOTE Wieland Electric GmbH | BA001281 | 04/2022 (Rev. A) -
Page 23: Maintenance
• Changes to the system distributor render this manual invalid. The specialist who made the change is responsible for updating or creating a new manual. Wieland Electric GmbH | BA001281 | 04/2022 (Rev. A) -
Page 24: Disassembly
Store the system distributor in a dry place protected from mechanical damage until it is recom- missioned. 11.2 Storage Store the system distributor in a dry place protected from mechanical damage until it is recommis- sioned. 11.3 Recommissioning For the correct recommissioning read chapter 8 "Commissioning". Wieland Electric GmbH | BA001281 | 04/2022 (Rev. A) -
Page 25: Product Disposal
EAK: 16 02 16 If the system distributor is defective, it must be disposed of or sent to Wieland Electric GmbH for repair. To initiate the process, contact your responsible contact partner. -
Page 26: Service And Support
49 (0) 951 / 9324-0 49 (0) 951 / 9324-198 E-mail info@wieland-electric.com http://eshop.wieland-electric.com http://www.wieland-electric.com UKCA – for UK: Wieland Electric Ltd | Ash House, Tanshire Park | Shackleford Road | Elstead, Godalming GU8 6LB Wieland Electric GmbH | BA001281 | 04/2022 (Rev. A) - Page 27 Wieland Electric GmbH Brennerstraße 10 – 14 DE-96052 Bamberg Tel +49 951 9324-0 Fax +49 951 9324-198 info@wieland-electric.com www.wieland-electric.com...
