GS-1510
Web Smart+ GbE Switch
Quick Installation and
Initial Configuration
お問い合わせ先:
データコントロルズ株式会社
support@dci.jp
www.dci.jp
電波障害について

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GS-1510 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for ZyXEL Communications GS-1510

  • Page 1 GS-1510 Web Smart+ GbE Switch Quick Installation and Initial Configuration お問い合わせ先: データコントロルズ株式会社 support@dci.jp www.dci.jp 電波障害について...
  • Page 2: Table Of Contents

    Contents Chapter 1 Introduction ............ 1 Overview ..................1 Front View of the Switch ............1 Rear View of the Switch ............. 1 LED Descriptions ................2 Reset Button .................. 3 Chapter 2 Installing the Switch ........4 Package Contents ................ 4 Mounting the Switch on Wall ..........
  • Page 3: Chapter 1 Introduction

    Overview This user guide describes how to install, configure, and troubleshoot the GS-1510, 10 Ports Web Smart+ GbE Switch. By reading this user guide, users can perform the following tasks: To check the switch status by reading the LED behavior •...
  • Page 4: Led Descriptions

    LED Descriptions The LEDs on the front panel provide users with switch status checking and monitoring. There are three types of LEDs as follows: System LED • indicates if the switch is powered up correctly or not. Port Status LEDs •...
  • Page 5: Reset Button

    The port is transmitting/receiving packets, and the Green Blinking connection speed is 1000Mbps. The port is enabled and established a link to connected Amber device, and the connection speed is 100Mbps. The port is transmitting/receiving packets, and the Amber Blinking connection speed is 100Mbps.
  • Page 6: Chapter 2 Installing The Switch

    Chapter 2 Installing the Switch Package Contents The Switch • AC Power cord (Option) • Four adhesive rubber feet • Installation Guide • Note The switch is an indoor device. If it is to be used with outdoor devices such as outdoor IP cameras or outdoor WiFi APs, then users are strongly suggested to install a surge protector or surge suppressor in order to protect the switch.
  • Page 7: Mounting The Switch On Desk Or Shelf

    Step 2: make sure that the switch is attached securely to wall. Figure 4: Attaching switch to the wall Mounting the Switch on Desk or Shelf Step 1: Verify that the workbench is sturdy and reliably grounded. Step 2: Attach the four adhesive rubber feet to the bottom of the switch.
  • Page 8: Connecting The Ac Power Cord

    Connecting the AC Power Cord Step 1: Connect the AC power cord to the AC power receptacle of switch. Step 2: Connect the other end of the AC power cord to the AC power outlet. Step 3: Check the SYS LED. If it is ON, the power connection is correct. Figure 6: Connecting AC power cord Installing SFP Modules You can install or remove a mini-GBIC SFP module from a SFP port...
  • Page 9 Figure 7: Installing a SFP Module into a SFP Port Note The SFP ports should use UL Listed Optional Transceiver product, Rated 3.3Vdc, Laser Class 1. rev.1.0a...
  • Page 10: Chapter 3 Initial Configuration Of Switch

    Chapter 3 Initial Configuration of Switch Initial Switch Configuration Using Web Browsers After powering up the switch for the first time, you can perform the initial switch configuration using a web browser. For managing other switch features, please refer to the Web interface user guide for details. To begin with the initial configuration stage, you need to reconfigure your PC’s IP address and subnet mask so as to make sure the PC can communicate with the switch.
  • Page 11 Step 2: Select Network and Sharing Center Step 3: Click on Change adapter settings on the left of PC screen Note Users can also skip step 1 to 3, by pressing WinKey+R and type ”ncpa.cpl” command to get to step 4 directly. Step 4: Right-click on your local adapter and select Properties Step 5:...
  • Page 12 If your PC is configured correctly, you will see the login page of the switch as shown by Figure 9 below. Figure 8: Web Interface login page If you do not see the above login page, please perform the following steps: - Refresh the web page.
  • Page 13: Chapter 4 Troubleshooting

    Chapter 4 Troubleshooting The following table provides information for users to easily troubleshoot problems by taking actions based on the suggested solutions within. Table 4: Troubleshooting Table Possible Symptoms Suggested Solutions Causes 1. Check if correct power cord is connected firmly to the switch and to the AC outlet socket.
