Haier HWM60-0713S User Manual

Twin-tub washing machine
Hide thumbs

Advertisement

Quick Links

Twin-tub Washing Machine
User's manual
This manual is for
HWM60-0713S
Please read this manual
carefully before using.
Retain it for future reference.
0030807907

Advertisement

loading

  Related Manuals for Haier HWM60-0713S

  Summary of Contents for Haier HWM60-0713S

  • Page 1 Twin-tub Washing Machine User's manual This manual is for HWM60-0713S Please read this manual carefully before using. Retain it for future reference. 0030807907...
  • Page 2: Table Of Contents

    Contents Names of the parts - - - - - - - - - - - - - - - - - 1 Safety precautions - - - - - - - - - - - - - - - - - 2 Installation and adjustment - - - - - - - - - - - 4 Preparation before washing - - - - - - - - - - 6 The musts in washing - - - - - - - - - - - - - - - 7...
  • Page 3: Names Of The Parts

    Names of the parts Wash selector Wash timer Water-filling entrance Control panel Overflow filter Water level adjusting lever Wash tub Protecting cover Valve cover Pulsator Wash tub cover Drain hose Base frame Notes: All illustrations in this manual are given for reference only. Your products and accessories may show differences from these illustrations due to our continuous improvement.
  • Page 4: Safety Precautions

    Safety precautions Please insert the power cord into special receptacle with rated vol- tage. Be sure to use single-phase three pins receptacle. The earthing terminal of the receptacle must be earthed reliably. If possible, please adopt electric leakage protector. If the power cord is bad, to avoid risk it is required to replace it by the technicians of our special shop or the after-sale service department.
  • Page 5 It is suggested to use foamless washing powder. Please don t use the washer in the environment below 0 C. If the washer is below 0 C, the washer s water inlet system and draining system will be frozen ,then result in the damaged of the whole machine.
  • Page 6: Installation And Adjustment

    Installation and adjustment Please install and adjust the machine according to the requirement of the manual. It is very important to your security and correct operating the machine. Install the lint filter After opening the package, please take out the lint filter from the document bag, install it to the overflow filter of the wash tub.
  • Page 7: How To Change The Direction Of The Drain Hoses

    How to change the direction of the drain hoses Figure 1 indicates the ex factory installation position of the drain hose. Extend the drain hose from the side of spin tub Put soft items on the ground. Lean the machine down gently with the front surface facing the ground.
  • Page 8: Preparation Before Washing

    Preparation before washing Preparation before washing 1.Connect the water inlet hose. 2.Confirm that the washing machine is earthed 3.Put down the drain hose . 4.Slanting or uneven ground may result in Pay attention to followings before washing the laundries Check if Clear the Tie the long the laundries...
  • Page 9: The Musts In Washing

    The musts in washing Usage of the detergent How to use the whitener Fill water to decided level. Dilute the whitener with container. Pour it slowly into the washing tub. Avoid using whitener on laun- dries with color or pattern as they are prone to lose color.
  • Page 10: Washing Sequence

    Washing sequence Wash timer (To set to below 2 minute, Inlet selector first set to 6 minute then turn it back. it can increase the service life of the timer). SPIN WASH TIMER Wash 1 Fill selection Set fill selection to Wash side (2 ) Adjust water level rod to a position as needed.
  • Page 11 Midway spinning 1.Put the laundries into the spin tub evenly and smoothly. 2.Spin (1) Put the gland in properly. Please put in the gland properly even if the laundries quantity is small. Push Gland Proper The laundries are slanting (2) Close the inner and outer cover of the spin tub. (3) Spin for 1-2 minutes.
  • Page 12: Rinse With Water-Filling

    Rinsing Rinse with water-filling 1.Put the laundries into the wash tub. Select suitable current according to the laundries. 2.Adjust the water level Set the water level with water level adjusting lever according to the laundries quantity. Then fill suitable water continuously. 3.Rinse Adjust the wash timer to 5-7 minutes to do rinsing.
  • Page 13 Spinning 1. Put the laundries into the spin tub evenly and smoothly. 2. Press the gland in the tub properly. Close the inner and outer cover of the spin tub. 3. Spin Select suitable spin time according to the laundries, and do spinning. During spinning, if there's abnormal sound, it is generally owing to slanting placement of the laundries.
  • Page 14: Disposal After Washing

    Disposal after washing After using, please clean the lint and foreign materials of the lint filter and overflow filter in time. Otherwise it may influence your using the machine. Please first pull off the power plug from the receptacle before cleaning. Cleaning the lint filter The lint filter must be used during washing.
  • Page 15: Cleaning The Overflow Filter

    Cleaning the overflow filter 2. Take off the corrugation pipe. Dismantle the upper part of the corrugation pipe inside overflow filter ( as indicated in Figure 1). 3. Cleaning the overflow filter Clean the lint around the filter and flush with tap water. 4.
  • Page 16 Clean the safeguard cover 2. Clean the underside of the cover Use the nipper or other spindly clamps to take out the lint , sundries etc. 3. Install the safeguard cover After finish cleaning , fasten the safeguard cover to the tub bottom, infirm the claw install correctly and hard to fall off.
  • Page 17: Trouble-Shooting Answer To Question

    Trouble-shooting Answer to question If the laundries fall to the outer side of the spin tub If the laundries fall to the outer side of the spin tub, contact the after-sales service department. please When the remained water is frozen Prevent the freezing (be sure to discharge the water completely after using) After complete draining, set the "WASH SELECTOR"...
  • Page 18 Trouble-shooting Answer to question (If there's breakdown, please pull off the power plug before checking) The following phenomena are not breakdowns sometimes. Please confirm again before sending it to repair. If there are real breakdowns, please come to the special maintenance department or after-sale service department of our company.
  • Page 19: Packing List

    Packing list Quantity Name One piece User's manual One piece Water inlet hose One piece Lint filter One piece Gland One set Twin-tub washing machine...
  • Page 20: Specification

    Specification Water level/Water quantity (L) (about) Maximum/48 Medium/39 Minimum/33 Injection pressure(Mpa) 0.02 0.2...
