Automatic Washing Machine
Please check if the power receptacle is earthed
reliably before usage to guarantee your safety.
Please read this manual carefully before use.
The manufacturer is not responsible for any
risks occurred owing to disobey these
stipulations.
Please retain it attentively for future reference.
HWM100-97

Advertisement

loading

  Related Manuals for Haier HWM100-97

  Summary of Contents for Haier HWM100-97

  • Page 1 Please check if the power receptacle is earthed reliably before usage to guarantee your safety. Please read this manual carefully before use. The manufacturer is not responsible for any risks occurred owing to disobey these stipulations. Please retain it attentively for future reference. HWM100-97...
  • Page 2: Table Of Contents

    Contents Names of the parts Safety precautions Installation and adjustment Preparation before washing Put in the laundries Usage of detergent Usage of the operation buttons Close the top lid Finish washing After washing Trouble shooting answer to question Packing list Specification the back cover...
  • Page 3: Names Of The Parts

    Names of the parts Top lid Control panel Inner tub Agitator Cabinet Control panel seat Accessories Water inlet hose Outer drain hose component Drain hose hook Drain hose clamp Please understand the shapes of the washing machine and accessories may be different from the sketch figures in this manual due to product improvement.
  • Page 4: Safety Precautions

    Safety precautions Please insert the power cord into special three -phase receptacle.The earthing terminal of the receptacle must be earthed reliably.If possible , please adopt electric leakage protector. Earth Do not bend ,extend,twist,bind by force.Do not press or nip it with weight. Keep the pin of the power plug clean,if the power plug is polluted with dust,please wipe with dry cloth carefully.
  • Page 5 Safety precautions Do not stretch hands into the working machine. It is dangerous even if the rotation is slow. Take special care of the children. Do not put any hot or heavy items (such as the kettle with hot water ) on the washing machine.
  • Page 6: Installation And Adjustment

    Installation and adjustment Adjust the installation position The largest allowed slope of the base of the machine is 2 . The slanting or rough ground will result in unstable running or stoppage of the machine. Please adjust it with following methods: Confirm it's horizontal: Hang the lead line to confirm if it is horizontal.
  • Page 7: Install The Water Inlet Hose

    Installation position. Take down the water inlet hose 1.Close the water tap. 2. Pull off the water inlet hose from the water tap and washer Figure 2 Figure 1...
  • Page 8: Preparation Before Washing

    Preparation before washing Pay attention to followings before washing the laundries Confirm if Clear the pocket. there's special Take out the requirment for coins , sand, the laundries. hairpins etc. a.Please check if the laundries are applicable for washing. b.Separate those not colorfast from other laundries. c.For laundries not water absorbing,please put them into water with hands.
  • Page 9: Put In The Laundries

    Procedures 1.Check clothing care labels for special instructions 2. Measure liquid bleacher carefully, following instructions on the bottle. 3. Before starting the washer, pour measured amount of bleach directly int bleach dispenser. Avoid splashing or over-filling dispenser. Note Never pour undiluted liquid chorine bleacher directly onto clothes or int the inner tub.
  • Page 10: Usage Of The Operation Buttons

    Usage of the operation buttons Explanation of Buttons Indicator mode and meaning The indicator is off, indicating that the program or mode is not selected The indicator is on, indicating the program or mode selected and about to run Flashing Normal running mode For setting, changing water level and manually replenishing water.
  • Page 11 Numeral tube s window To indicate remaining min. during program running. To indicate remaining reserved hr. during reservation period. To indicate fault symbols for abnormal conditions. Soak Wash Rinse Quick Wash 2nd Rinse Spin Delicate Casual Process Hand Wash For selecting processes. Soak process is Invalid if Hand wash, Delicate Casual or Quick Wash program is selected;...
  • Page 12: Operating Procedure

    Pressing Power On/Off button, all programs will stop and the unit enters standby, regardless of the computer conditions (start, pause, alarm etc.). The washer has intelligent wash resumption. After the power is cut off abnormally, the washer could resume working at stoppage while the power resumption.
  • Page 13 Usage of the operation buttons 2. Press the button of cycles to select a suitable full-automatic program. After switching on, the Normal program will be the default. If other full-automatic program is desired, you can press the button of cycles to get the corresponding indicator on.
  • Page 14 Usage of the operation buttons Note Spin shall begin after some time even there is no water in the tub Do not use soak process for woolen articles. Clothes prone to fade and other clothes shall be separately washed. 4. Press the button of Load Size to select a suitable water level.
  • Page 15 Usage of the operation buttons 8. Press the button of Cycle Signal , which will accordingly remind you of the cycle completion. After the power is switched on, the washing machine will automatically set at Softer . The user himself could also set three warning volumes Louder, Softer or Off for the completion of a cycle.
  • Page 16: Close The Top Lid

    Close the top lid If you open the top lid, the machine will stop working except for water filling and draining water Finish washing The power will be switched off automatically after the finishing of the washing. After Finishing wash alarm automatically...
  • Page 17: After Washing

    After washing After using, please clean the lint and foreign materials of the lint filter etc. in time. Otherwise it may influence your using the machine. Please first pull off the power plug from the receptacle before cleaning. Cleaning the lint filter The lint filter must be used during washing.
  • Page 18: Trouble Shooting Answer To Question

    Trouble shooting answer to question (If there's breakdown, please pull off the power plug before checking) The following phenomena are not breakdowns sometimes. Please confirm again before sending it to repair. If there are real breakdowns, please come to the special maintenance department or after-sale service department of our company.
  • Page 19: Packing List

    Packing list Name User's manual Drain hose Drain hose hook Water inlet hose Drain hose clamp Automatic washing machine Quantity...
  • Page 20 Water level/Water quantity (about) Max water consumption Injection pressure Rated washing power Rated spinning power Weight(about) Dimension HWM100-97 220-240V~ 50Hz 8.5kg (weight of standard dry cloth) 1/25L, 2/35L, 3/45L, 4/52L, 5/60L,6/68L, 7/72L, 8/80L, 9/88L, 10/100L About 185L(High water level; Normal program) 0.03MPa-1.0MPa...
