- Page 1 USER MANUAL VIPColor VP485 Unwinder Please keep the original packaging in case you need to return the unit. If we receive the system in non-original packaging, the warranty may be void.
- Page 2 APPLICATIONS The VIPColor VP485 Unwinder is used to unwind labels onto a 3” core holder. The unwinder can handle labels up to 220mm (8.6”) wide and unwind rolls with external diameter up to 250mm (10”). POWER SUPPLY An external power supply 100/240VAC - 2.5A at 24V allows an electronic circuit to provide, through the tension arm, the speed and sense of rotation auto adjustment.
- Page 3 INSTALLATION STEP 1 STEP 2 Remove the two knobs from the Put the second plate near the first one. unwinder’s plate. STEP 3 STEP 4 Use the two knobs to fasten the plates. Load the roll onto the core holder. STEP 6 STEP 5 Install the support and fasten it to the...
- Page 4 smart solutions for the labeling industry Label rewinder, label unwinder, electronic label dispenser and more... - FOR MORE INFO CONTACT YOUR RESELLER -...
