Summary of Contents for Concept Pro VXH5AHDE-8
- Page 1 VXH5AHDE-8 VXH5AHDE-16 DIGITAL VIDEO RECORDER QUICK START GUIDE Technical Documents VXH5AHDE QUICK START GUIDE...
-
Page 2: What's In The Box
HDD Mounting Screws x25 HDD Mounting Gaskets x5 (x10) Remote Control Batteries x2 Cable Clamp x1 Cable Clamp Screws x2 10-Pin Terminal Block x2/x4 Technical Documents INSTALLATION Back Panel 1. VXH5AHDE-8 AUDIO IN AUDIO SPOT WAN(UPLINK) e-SATA USB LAN(DOWNLINK) DC12V VIDEO IN... - Page 3 INSTALLATION AU DI O IN AU DI O UT SP O O UT Camera VI DE O IN W AN (U PL IN K) VG A M O NI TO R e- SA Alarm US B LA N( DO W NL IN Speaker DC 12...
-
Page 4: Getting Started
GETTING STARTED Network Setup Wizard The Network Setup Wizard will help configure important network settings when the device is first booted up. Log in The log-in screen will appear after the system boots up. Select a user ID and enter the corresponding password. The default user ID is “ADMIN”... - Page 5 GETTING STARTED Status Bar: The status bar can be used in addition to the included remote control to access key features. Icon Description Icon Description [MENU] Select system setup, record [ZOOM] Move to the Digital Zoom screen. setup, search, and archiving menus.
- Page 6 AUTOMATIC RECORDING PROFILES 1. Press [MENU] on the remote control and use the direction buttons to select <RECORD SETUP>, then press [ENTER]. Alternatively, select <MENU> - <RECORD SETUP> from the status bar. 2. Set <RECORD SETUP MODE> to <AUTO CONFIGURATION> and select a desired recording profile: • CONTINUOUS RECORD: Always record video.
-
Page 7: Searching Recorded Video
SEARCHING RECORDED VIDEO 1. From the <SEARCH> menu, select <TIME SEARCH>. 2. Specify the date and time from the calendar. 3. Identify the type of recording data by the colour in the bar. • Light Green: Pre-Recording • Green: Continuous Recording •... - Page 8 Concept Pro suite of recorders. To use video analytics, you must first ensure the license is recognised by the recorder. To do this, first connect the camera to the Concept Pro recorder over the network.
- Page 9 ARCHIVING RECORDED VIDEOS 1. Click <MENU> and select <ARCHIVING>. This can be selected from either the Live or Playback screens. From <ARCHIVING>, select <NEW ARCHIVING>. 2. Select a date for the archive from the calendar to the left. Any dates containing recorded data will be coloured boxes.
- Page 10 ARCHIVING RECORDED VIDEOS 6. To export to an external USB storage device, connect the device to the NVR and click <EXPORT>. 7. To reserve the data, click <RESERVE>. Enter a <TAG NAME> and click <OK>. Click <RESERVE> to save the archive to the internal hard disk. •...
-
Page 11: App Setup
Concept Pro Viewer SEQURINET REGISTER / LOGIN You will need to register your details with Sequrinet to set up any recording devices. You can login or set up your Securinet account with the Concept Pro App. Already registered? Complete the fields Click OK. -
Page 12: Dvr Setup
ACCESSING FROM THE VIEWER APP Connect to router or switch with router attached via a network patch cable. Navigate to the network menu in the recorder and either select DHCP or alternatively statically assign a valid IP address for your local network. Apply all settings and select Close DVR SETUP Select Menu at the bottom left hand corner of the screen and select Sequrinet at the... - Page 13 NOTES VXH5AHDE QUICK START GUIDE...
- Page 14 NOTES VXH5AHDE QUICK START GUIDE...
- Page 15 NOTES VXH5AHDE QUICK START GUIDE...
- Page 16 MW91AU01_Rev01 VXH5AHDE QUICK START GUIDE...
