- Page 1 KMK721880M User Manual Microwave Oven KMK721880W USER MANUAL...
-
Page 2: Table Of Contents
FOR PERFECT RESULTS Thank you for choosing this AEG product. We have created it to give you impeccable performance for many years, with innovative technologies that help make life simpler – features you might not find on ordinary appliances. Please spend a few minutes reading to get the very best from it. -
Page 3: Safety Information
SAFETY INFORMATION 9.3 Cooling fan........20 12.2 How to manage: Error codes..26 12.3 Service data.........26 10. HINTS AND TIPS........20 13. ENERGY EFFICIENCY......26 10.1 Cooking recommendations..20 10.2 Microwave recommendations ..20 13.1 Energy saving......26 10.3 Microwave suitable cookware and 14. -
Page 4: General Safety
SAFETY INFORMATION WARNING: Keep children and pets away from the appliance • when it operates or when it cools down. Accessible parts become hot during use. If the appliance has a child safety device, it should be • activated. Children shall not carry out cleaning and user maintenance •... - Page 5 SAFETY INFORMATION Do not activate the microwave function when the appliance • is empty. Metal parts inside the cavity can create electric arcing. Metallic containers for food and beverages are not allowed • during microwave cooking. This requirement is not applicable if the manufacturer specifies size and shape of metallic containers suitable for microwave cooking.
-
Page 6: Safety Instructions
SAFETY INSTRUCTIONS The appliance should be cleaned regularly and any food • deposits removed. Do not use a steam cleaner to clean the appliance. • Do not use harsh abrasive cleaners or sharp metal scrapers • to clean the glass door since they can scratch the surface, which may result in shattering of the glass. -
Page 7: Electrical Connection
SAFETY INSTRUCTIONS Width of the back of the appliance 559 mm Depth of the appliance 567 mm Built in depth of the appliance 546 mm Depth with open door 882 mm Ventilation opening minimum size. Opening placed 560x20 mm on the bottom rear side Mains supply cable length. -
Page 8: Use
SAFETY INSTRUCTIONS 2.3 Use WARNING! Risk of injury, burns and electric shock or explosion. • Do not change the specification of this appliance. • Make sure that the ventilation openings are not blocked. • Do not let the appliance stay unattended during operation. •... -
Page 9: Internal Lighting
SAFETY INSTRUCTIONS • Make sure the cavity, the turntable and the door are wiped dry after each use. Steam produced during the operation of the appliance condensates on cavity walls and can cause corrosion. • Clean regularly the appliance to prevent the deterioration of the surface material. •... -
Page 10: Product Description
PRODUCT DESCRIPTION 3. PRODUCT DESCRIPTION 3.1 General overview Control panel Display Heating element Microwave generator Lamp Turntable shaft 3.2 Accessories Turntable set To prepare food. ≤ 4 kg Grill rack set To grill. 4. HOW TO TURN OVEN ON AND OFF 4.1 Control panel 10/32... -
Page 11: Display
HOW TO TURN OVEN ON AND OFF ON / OFF Press and hold to turn the oven on and off. Menu Lists the oven functions. Favourites Lists the favourite settings. Display Shows the current settings of the oven. Lamp switch To turn the lamp on and off. -
Page 12: Before First Use
BEFORE FIRST USE If you do not use the oven for 2 minutes, the display goes to standby. 12 : 34 When you cook, the display shows the set 12:34 12:34 functions and other available options. 1m23s 1000W +30s STOP STOP Display indicators Basic indicators - to navigate on the display. -
Page 13: Initial Cleaning
DAILY USE 5.1 Initial Cleaning Step 1 Step 2 Step 3 Clean the oven and the ac‐ Remove all accessories from cessories with a soft cloth, Place the accessories in the the oven. warm water and a mild deter‐ oven. gent. - Page 14 DAILY USE Setting the function: Grill + MW Step 6 Press: Step 7 Press: - press to turn off the oven. Step 8 Turn off the oven. Microwave power is limited to 500 W when you use the function: Grill + MW. Setting the function: Grill Step 1 Insert the high grill rack.
-
Page 15: How To Set: Microwave Heating Functions
DAILY USE 6.2 How to set: Microwave heating functions Step 1 Turn on the oven. Step 2 Press the symbol of the heating function to enter the submenu. Step 3 Select the microwave heating function and press: . The display shows: micro‐ wave power. -
Page 16: Heating Functions
DAILY USE Step 2 To extend the cooking time: Press on the running time value to go Press +30 s. to the time settings. Set the cooking time. The microwave can be switched on at any time with: Microwave quick start. 6.4 Heating functions STANDARD Heating function... -
Page 17: Clock Functions
CLOCK FUNCTIONS Heating function Application Preparing popcorn, power range: 700 - 1000 W Popcorn Heating up drinks and soups, power range: 800 - 1000 W Liquid 7. CLOCK FUNCTIONS 7.1 Clock functions description Clock function Application Cooking time To set the length of cooking. Maximum is 23 h 59 min. End action To set what happens when the timer ends counting. - Page 18 CLOCK FUNCTIONS How to set cooking time Step 2 Press: Step 3 Set the time. Press: How to choose end option Step 1 Choose the heating function. Step 2 Press: Step 3 Set the cooking time. Step 4 Press: Step 5 Press: End action.
-
Page 19: How To Use: Accessories
HOW TO USE: ACCESSORIES 8. HOW TO USE: ACCESSORIES 8.1 Inserting accessories Use only suitable cookware and material. Refer to "Hints and tips" chapter, Microwave suitable cookware and materials. Turntable set: Always cook food on the turntable set. Place the roller guide around the turntable shaft. -
Page 20: Function Lock
HINTS AND TIPS 9.2 Function lock This function prevents an accidental change of the heating function. Step 1 Turn on the oven. Step 2 Set a heating function. Step 3 - press at the same time to turn on the function. To turn off the function repeat step 3. -
Page 21: Microwave Suitable Cookware And Materials
HINTS AND TIPS Cook food covered. If you want to keep a crust cook food without a cover. Do not overcook the dishes by setting the power and time too high. The food can dry out, burn or cause fire. Do not use the oven to cook eggs or snails in their shells, because they can burst. -
Page 22: Recommended Power Settings For Different Kinds Of Food
HINTS AND TIPS Cookware / Material Heat-resistant plastic up to 200 °C Cardboard, paper Clingfilm Roasting film with microwave safe closure Roasting dishes made of metal, e.g. enamel, cast iron Baking tins, black lacquer or silicon-coated Cookware for microwave use, e.g. -
Page 23: Cooking Tables For Test Institutes
HINTS AND TIPS 500 - 700 W Defrosting Cooking veg‐ Cooking egg Simmering Simmering Heating one- and heating etables dishes stews rice plate meals frozen meals 300 - 400 W Melting cheese, chocolate, but‐ Cooking / Heating delicate food Continuing cooking 100 - 200 W Defrosting Heating baby... -
Page 24: Care And Cleaning
CARE AND CLEANING MICROWAVE FUNCTION (kg) (min) Meat defrosting Turntable 8 - 9 Use the function: Microwave grilling. Use the low grill rack. MICROWAVE COMBI FUNCTION Grill intensity (min) level Potato gratin, 1.1 kg 30 - 35 Chicken, 1.1 kg high 30 - 35 Put the meat in... -
Page 25: Troubleshooting
TROUBLESHOOTING Clean all accessories after each use and let them dry. Before cleaning, wait un‐ til the turntable is cold. There is a risk that the turntable can break. Use a soft cloth with warm water and a mild detergent. Do not clean the accessories in a dishwasher. -
Page 26: How To Manage: Error Codes
ENERGY EFFICIENCY Components Description Remedy The lamp is burnt out. Replace the lamp, for details refer to "Care and Cleaning" chapter, How to replace: Lamp. The turntable set makes noise. There is food residue below the turntable set. 12.2 How to manage: Error codes When the software error occurs, the display shows error message. -
Page 27: Menu Structure
MENU STRUCTURE Make sure that the oven door is closed when the oven operates. Do not open the oven door too often during cooking. Keep the door gasket clean and make sure it is well fixed in its position. When possible, do not preheat the oven before cooking. Keep breaks between baking as short as possible when you prepare a few dishes at one time. -
Page 28: Submenu For: Setup
IT'S EASY! 14.3 Submenu for: Setup Submenu Description Language Sets the oven language. Display brightness Sets the display brightness. Key tones Turns the tone of the touch fields on and off. It is not possi‐ ble to mute the tone for: Buzzer volume Sets the volume of key tones and signals. -
Page 29: Environmental Concerns
IT'S EASY! Start using the oven MW quick start Start Microwave at any time with Press: default settings: 30 sec / 1000W. heating / cooking cooking / browning heating liquids cooking / browning 100 - 1000 W intensity: low / high 800 - 1000 W reheating defrosting... - Page 30 ENVIRONMENTAL CONCERNS appliances. Do not dispose of appliances marked with the symbol with the household waste. Return the product to your local recycling facility or contact your municipal office. 30/32...
- Page 31 31/32...
- Page 32 www.aeg.com/shop...
