Summary of Contents for AEG KMK76108HM
- Page 1 EN User Manual | Microwave combi-oven KMK76108HM aeg.com\register...
-
Page 2: Table Of Contents
FOR PERFECT RESULTS Thank you for choosing this AEG product. We have created it to give you impeccable performance for many years, with innovative technologies that help make life simpler – features you might not find on ordinary appliances. Please spend a few minutes reading to get the very best from it. -
Page 3: Safety Information
SAFETY INFORMATION Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damage that are the result of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference. - Page 4 similar accommodation where such use does not exceed (average) domestic usage levels. • Only a qualified person must install this appliance and replace the cable. • Do not use the appliance before installing it in the built-in structure. • Disconnect the appliance from the power supply before carrying out any maintenance.
- Page 5 • When heating food in plastic or paper containers, observe the appliance due to the possibility of ignition. • The appliance is intended for heating food and beverages. Drying of food or clothing and heating of warming pads, slippers, sponges, damp cloth and similar may lead to risk of injury, ignition or fire.
-
Page 6: Safety Instructions
2. SAFETY INSTRUCTIONS 2.1 Installation Ventilation opening mini‐ 560x20 mm mum size. Opening placed WARNING! on the bottom rear side Only a qualified person must install this Mains supply cable length. 1500 mm appliance. Cable is placed in the right corner of the back side •... - Page 7 • The electrical installation must have an – be careful when you remove or install isolation device which lets you disconnect the accessories. the appliance from the mains at all poles. • Discoloration of the enamel or stainless The isolation device must have a contact steel has no effect on the performance of opening width of minimum 3 mm.
-
Page 8: Product Description
2.5 Internal lighting • Use original spare parts only. 2.7 Disposal WARNING! Risk of electric shock. WARNING! • Concerning the lamp(s) inside this product Risk of injury or suffocation. and spare part lamps sold separately: • Contact your municipal authority for These lamps are intended to withstand information on how to dispose of the extreme physical conditions in household... -
Page 9: Control Panel
3.2 Accessories Wire shelf For cookware, cake tins, roasts. Grill- / Roasting pan To bake and roast or as a pan to collect fat. 4. CONTROL PANEL 4.1 Control panel overview ON / OFF Press and hold to turn the appliance on and off. Menu Lists the appliance functions. -
Page 10: Before First Use
Press Move Press and hold Touch the surface with fingertip. Slide fingertip over the surface. Touch the surface for 3 seconds. 4.2 Display Display with key functions set. Time of day START/STOP 12:30 Temperature / Microwave timer 150°C Heating functions Timer START 15min... -
Page 11: Daily Use
5.1 Initial Cleaning Step 1 Step 2 Step 3 Remove all accessories and remov‐ Clean the appliance and the acces‐ Place the accessories and the re‐ able shelf supports from the appli‐ sories only with a microfibre cloth, movable shelf supports in the appli‐ ance. - Page 12 Step 5 Press: - press to turn off the function. Step 6 Turn off the appliance. The maximum time of microwave functions depends on microwave power you set: MICROWAVE POWER MAXIMUM TIME 100 - 600 59:55 > 600 Step 2 To extend the cooking time: If you open the door, the function stops.
- Page 13 6.5 Heating functions STANDARD Heating function Application To grill thin pieces of food and to toast bread. Grill To roast large meat joints or poultry with bones on one shelf position. To make gratins and to brown. Turbo Grilling To bake on up to two shelf positions at the same time and to dry food. Set the temper‐ ature 20 - 40 °C lower than for Conventional Cooking.
- Page 14 Heating function Application To speed up the rising of the yeast dough. It prevents dough surface from drying and keeps the dough elastic. Dough Proving For dishes such as lasagna or potato gratin. To make gratins and to brown. Au Gratin To prepare tender, succulent roasts.
-
Page 15: Clock Functions
7. CLOCK FUNCTIONS 7.1 Clock functions description Clock function Application Cooking time To set the length of cooking. Maximum is 23 h 59 min. Maximum for combined functions (microwave + standard) is: 23 h 59 min. End action To set what happens when the timer ends counting. Delayed start To postpone the start and / or end of cooking. -
Page 16: Using The Accessories
How to choose end option Step 7 Press: . Repeat the action until the display shows the main screen. How to delay start of cooking Step 1 Set the heating function and the temperature. Step 2 Press: Step 3 Set the cooking time. Step 4 Press: Step 5... -
Page 17: Additional Functions
Wire shelf: Push the shelf between the guide bars of the shelf support and make sure that the feet point down. Deep pan: Push the tray between the guide bars of the shelf support. 9. ADDITIONAL FUNCTIONS 9.1 How to save: Favourites You can save your favourite settings, such as the heating function, the cooking time, the temperature or the cleaning function. -
Page 18: Hints And Tips
Step 3 - press at the same time to turn on the function. To turn off the function repeat step 3. 9.3 Automatic switch-off For safety reasons the appliance turns off after some time, if a heating function works (°C) and you do not change any settings. - Page 19 Pierce the yolk of fried egg before reheating Put the frozen, unwrapped food on a small upturned plate with a container below it, or on a defrosting rack or plastic sieve so that the Pierce food with skin or peel several times defrosting liquid can leak out.
- Page 20 10.4 Recommended power settings for different kinds of food The data in the table is for guidance only. 700 - 1000 W Searing at the start of the cooking process Heating liquids 500 - 600 W Defrosting and Cooking egg Heating one-plate Cooking vegetables Simmering stews...
-
Page 21: Care And Cleaning
Egg custard 30 - 33 Meat defrosting Turn the meat upside down halfway through the cooking time. Microwave Combi function Use the wire shelf. Cake, 0.7 kg Conventional 23 - 27 Turn container around Cooking + MW by 1/4, halfway through the cooking time. - Page 22 Clean all accessories after each use and let them dry. Use only a microfibre cloth with warm water and a mild detergent. Do not clean the accessories in a dishwasher. Do not clean the non-stick accessories using abrasive cleaner or sharp-edged objects. Accessories 11.2 How to remove: Shelf supports Remove the shelf supports to clean the oven.
-
Page 23: Troubleshooting
12. TROUBLESHOOTING WARNING! Refer to Safety chapters. 12.1 What to do if... The appliance does not turn on or does not heat up Possible cause Remedy The appliance is not connected to an electrical supply Check if the appliance is correctly connected to the or it is connected incorrectly. -
Page 24: Energy Efficiency
Code and description Remedy F131 - the temperature of magnetron sensor is too Turn the appliance off and wait until it cools down. Turn high. the appliance on again. 12.3 Service data If you cannot find a solution to the problem yourself, contact your dealer or an Authorised Service Centre. -
Page 25: Menu Structure
14. MENU STRUCTURE 14.1 Menu Menu item Application Assisted Cooking Lists automatic programmes. Favourites Lists the favourite settings. Options To set the appliance configuration. Settings Setup To set the appliance configuration. Service Shows the software version and configuration. 14.2 Submenu for: Options Submenu Application Light... -
Page 26: S Easy
15. IT'S EASY! Before first use you have to set: Language Display brightness Key tones Buzzer volume Time of day Familiarize yourself with the basic icons on the control panel and the display: ON / OFF Menu Favourites Timer Start using the appliance Quick start Turn on the appli‐... -
Page 27: Environmental Concerns
16. ENVIRONMENTAL CONCERNS appliances marked with the symbol with Recycle materials with the symbol . Put the the household waste. Return the product to packaging in relevant containers to recycle it. your local recycling facility or contact your Help protect the environment and human municipal office. - Page 28 867370652-B-052023...
