915GV-M7 DDR2
FCC Information and Copyright
This equipment has been tes ted and found to comply with the limits of a Class
B digital devic e, purs uant to Part 15 of the FCC Rules . T hese limits are designed
to provide reasonable protec tion against harmful interference in a residential
installation. T his equipment generates , uses and can radiate radio frequency
energy and, if not ins talled and used in accordance with the instructions , may
cause harmful interference to radio communications . There is no guarantee
that interference will not occur in a particular ins tallation.
The vendor makes no representations or warranties with respec t to the
contents here and s pecially disclaims any implied warranties of merchantability
or fitness for any purpose. Further the vendor reserves the right to revise this
publication and to make c hanges to the c ontents here without obligation to
notify any party beforehand.
D uplication of this publication, in part or in whole, is not allowed without first
obtaining the vendor's approval in writing.
The content of this user's manual is subject to be c hanged without notice and
we will not be res ponsible for any mis takes found in this user's manual. All the
brand and produc t names are trademarks of their respec tive companies .
i

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 915GV-M7 and is the answer not in the manual?

Questions and answers

Summary of Contents for Biostar 915GV-M7

  • Page 1 915GV-M7 DDR2 FCC Information and Copyright This equipment has been tes ted and found to comply with the limits of a Class B digital devic e, purs uant to Part 15 of the FCC Rules . T hese limits are designed to provide reasonable protec tion against harmful interference in a residential installation.
  • Page 2: Table Of Contents

    Table of Contents Chapter 1: Introduction ..............1 Motherboard Features............. 1 Package Checklist ............4 Layout and Components..........5 Chapter 2: Hardware Installation ..........6 Installing Central Processing Unit (CPU)......6 FAN Headers ..............8 Installing System Memory..........9 Connectors and Slots............. 10 Chapter 3: Headers &...
  • Page 3: Chapter 1: Introduction

    915GV-M7 DDR2 CHAPTER 1: INTRODUCTION OTHERBOARD EATURES Supports LGA 775. Supports Intel Pentium 4 processor up to 3.8GHz. Supports Intel Celeron D processor. Front side bus at the following frequency ranges: 533 MHz (133MHz Core Clock) 800 MHz (200MHz Core Clock)
  • Page 4 915GV-M7 DDR2 Se rial ATA Controller integrated in ICH6. Supports 4 Serial ATA (SATA) ports. Intel Advanced Host Controller (AHCI). Compliant with SATA 1.0 specification. Data transfer rates up to 1.5Gb/s. Slots (See p.11 for detail information) Two 32-bit PCI bus master slots.
  • Page 5 915GV-M7 DDR2 Front Side On-board Pe ripherals 1 IDE connector supports 2 hard disk devices. 1 front panel header supports front panel facilities. 1 AUX-in connector supports 1 AUX audio-in device. 1 CD-in connector supports 1 CD-ROM audio-in device. 1 front audio header supports front panel audio function.
  • Page 6: Package Checklist

    915GV-M7 DDR2 ACKAGE HECKLIST FDD Cable * 1 HDD Cable * 1 User’s Manual * 1 Serial ATA Cable * 1 Fully Setup Driver CD * 1 Rear I/O Panel for ATX Case * 1 S/PDIF Cable * 1 (optional) USB 2.0 Cable *1 (optional)
  • Page 7: Layout And Components

    915GV-M7 DDR2 AYOUT AND OMPONENTS JKBMS1 JATXPWR2 LGA775 JKBV1 C PU1 JUSB 2 J CFAN1 JU SBV1 I ntel 91 5G V JRJ45USB1 Super JAUDIO1 JAUDIO2 PCI-EX JCMOS1 JCI 1 XGP1 CODEC JU SBV3_1 BAT 1 JSFAN1 JCDIN1 SA TA2...
  • Page 8: Chapter 2: Hardware Installation

    915GV-M7 DDR2 CHAPTER 2: HARDWARE INSTALLATION (CPU) NSTALLING ENTRAL ROCESSING Special Notice: Remove Pin Cap before installation, and make good preservation for future use. When the CPU is removed, cover the Pin Cap on the empty socket to ensure pin legs won’t be damaged.
  • Page 9 915GV-M7 DDR2 Step 2: Look for the triangular cut edge on socket, and the golden dot on CPU should point forwards this triangular cut edge. The CPU will fit only in the correct orientation. Step 2-1: Step 2-2: Step 3: Hold the CPU down firmly, and then lower the lever to locked position to complete the installation.
  • Page 10: Fan Headers

    915GV-M7 DDR2 FAN H EADERS These fan headers support cooling-fans built in the computer. The fan cable and connector may be different according to the fan manufacturer. Connect the fan cable to the connector while matching the black wire to pin#1.
  • Page 11: Installing System Memory

    915GV-M7 DDR2 NSTALLING YSTEM EMORY 1. Unlock a DIMM slot by pressing the retaining clips outward. Align a DIMM on the slot such that the notch on the DIMM matches the break on the Slot. 2. Insert the DIMM vertically and firmly into the slot until the retaining...
  • Page 12: Connectors And Slots

    915GV-M7 DDR2 ONNECTORS AND LOTS FDD1: Floppy Disk Connector The motherboard provides a standard floppy disk connector that supports 360K, 720K, 1.2M, 1.44M and 2.88M floppy disk types. This connector supports the provided floppy drive ribbon cables. IDE1: Hard Disk Connector...
  • Page 13 915GV-M7 DDR2 PCI1~PCI2: Peripheral Component Interconnect Slots This motherboard is equipped with 2 standard PCI slots. PCI stands for Peripheral Component Interconnect, and it is a bus standard for expansion cards. This PCI slot is designated as 32 bits. PCI1...
  • Page 14 PC. After PC restarts, the system will automatically set the AGP VGA card as the graphics adapter. 2. Or, re-install your operating system to ensure the AGP VGA card function can be used. Note: Please go to “http://www.biostar.com.tw” for more detailed information about XGP compatible AGP cards.
  • Page 15: Chapter 3: Headers & Jumpers Setup

    915GV-M7 DDR2 CHAPTER 3: HEADERS & JUMPERS SETUP OW TO ETUP UMPERS The illustration shows how to set up jumpers. When the jumper cap is placed on pins, the jumper is “close”, if not, that means the jumper is “open”.
  • Page 16 915GV-M7 DDR2 JKBV1: Power Source Header for PS/2 Keyboard and Mouse Pin 1-2 Close (default) +5V for PS/2 keyboard and mouse. Pin 2-3 Close PS/2 keyboard and mouse are powered by +5V standby voltage. Note: In order to support this func tion “Power-on s ystem via keyboar d and mouse”, “JKBV1”...
  • Page 17 915GV-M7 DDR2 JATXPWR1: ATX Power Connector This connector allows user to connect 24-pin power connector on the ATX power supply. Assignment +3.3V +3.3V Ground Ground Ground PW_OK Standby Voltage +5V +12V +12V 2 x 12 Detect +3.3V -12V Ground PS_ON...
  • Page 18 915GV-M7 DDR2 JCDIN1: CD-RO M Audio-in Connector This connector allows user to connect the audio source f rom the variety dev ices, like CD-ROM, DVD-ROM, PCI sound card, PCI TV turner card etc.. Assignment Left channel input Ground Ground Right channel input...
  • Page 19 915GV-M7 DDR2 JPANEL1: Front Panel Header This 24-pin connector includes Power-on, Reset, HDD LED, Power LED, Sleep button, speaker and IrDA Connection. It allows user to connect the PC case’s front panel switch f unctions. PWR_LED On/Off IR(optional) HLED Assignment...
  • Page 20 915GV-M7 DDR2 JCMOS1: Clear CMOS Header By placing the jumper on pin2-3, it allows user to restore the BIOS saf e setting and the CMOS data, please carefully f ollow the procedures to avoid damaging the motherboard. Pin 1-2 Close Normal Operation (default).
  • Page 21 915GV-M7 DDR2 JCI1: Chassis Open Header This connector allows system to monitor PC case open status. If the signal has been triggered, it will record to the CMOS and show the message on next boot-up. Assignment Case open signal Ground...
  • Page 22: Chapter 4: Useful Help

    BIOS contents are corrupted. In this Case, please follow the procedure below to restore the BIOS: Make a bootable floppy disk. Download the Flash Utility “AWDFLASH.exe” from the Biostar website: www.biostar.com.tw Confirm motherboard model and download the respectively BIOS from Biostar website.
  • Page 23 915GV-M7 DDR2 B. CPU Overheated If the system shutdown automatically after power on system for seconds, that means the CPU protection function has been activated. When the CPU is over heated, the motherboard will shutdown automatically to avoid a damage of the CPU, and the system may not power on again.
  • Page 24: Troubleshooting

    915GV-M7 DDR2 ROUBLESHOOTING Problem Solution No power to the system at all Make sure power cable is Power light don’t illuminate, f an securely plugged in. inside power supply does not turn Replace cable. Contact technical support. Indicator light on key board does not turn on.
  • Page 25: Chapter 5: Warpspeeder

    915GV-M7 DDR2 WARPSPEEDER™ CHAPTER 5: NTRODUCTION [WarpSpeeder™], a new powerful control utility, features three user-friendly functions including Overclock Manager, Overvoltage Manager, and Hardware Monitor. With the Overclock Manager, users can easily adjust the frequency they prefer or they can get the best CPU performance with just one click. The Overvoltage Manager, on the other hand, helps to power up CPU core voltage and Memory voltage.
  • Page 26: Installation

    915GV-M7 DDR2 NSTALLATION 1. Execute the setup execution file, and then the following dialog will pop up. Please click “Next” button and follow the default procedure to install. 2. When you see the following dialog in setup procedure, it means setup is completed.
  • Page 27: Warpspeederâ„¢] Includes 1 Tray Icon And 5 Panels

    915GV-M7 DDR2 ™] PEEDER INCLUDES TRAY ICON AND PANELS 1. Tray Icon: Whenever the Tray Icon utility is launched, it will display a little tray icon on the right side of Windows Taskbar. This utility is responsible for conveniently invoking [WarpSpeeder™] Utility.
  • Page 28 915GV-M7 DDR2 2. Main Panel If you click the tray icon, [WarpSpeeder™] utility will be invoked. Please refer to the following figure; the utility’s first window you will see is Main Panel. Main Panel contains fe ature s as follows: a.
  • Page 29 915GV-M7 DDR2 3. Voltage Panel Click the Voltage button in Main Panel, the button will be highlighted and the Voltage Panel will slide out to up as the following figure. In this panel, you can decide to increase CPU core voltage and Memory voltage or not.
  • Page 30 915GV-M7 DDR2 4. Overclock Panel Click the Overclock button in Main Panel, the button will be highlighted and the Overclock Panel will slide out to left as the following figure. O ve rclock Panel contains the these features: a. “–3MHz button”, “-1MHz button”, “+1MHz button”, and “+3MHz button”: provide user the ability to do real-time overclock adjustment.
  • Page 31 915GV-M7 DDR2 “Auto-overclock button”: User can click this button and [WarpSpeeder™] will set the best and stable performance and frequency automatically. [WarpSpeeder™] utility will execute a series of testing until system fail. Then system will do fail-safe reboot by using Watchdog function. After reboot, the [WarpSpeeder™] utility will restore to the hardware default...
  • Page 32 915GV-M7 DDR2 6. About Panel Click the “about” button in Main Panel, the button will be highlighted and the About Panel will slide out to up as the following figure. In this panel, you can get model name and detail information in hints of all the chipset that are related to overclocking.
  • Page 33 915GV-M7 DDR2 Note : Because the overclock, overvoltage, and hardware monitor features are controlled by several separate chipset, [WarpSpeeder™] divide these features to separate panels. If one chipset is not on board, the correlative button in Main panel will be disabled, but will not interfere other panels’...
  • Page 34 915GV-M7 DDR2 BIOS SETUP BIOS Setup ..............1 1 Main Menu ....................3 2 Standard CMOS Features................6 3 Advanced BIOS Features ................9 4 Advanced Chipset Features .................14 5 Integrated Peripherals..................17 6 Power Management Setup................22 7 PnP/PCI Configurations ................27 8 PC Health Status ..................29...
  • Page 35: Bios Setup

    915GV-M7 DDR2 BIOS SETUP BIOS Setup Introduction This manual discussed Award™ Setup program built into the ROM BIOS. The Setup program allows users to modify the basic system configuration. This special information is then stored in battery-backed RAM so that it retains the Setup information when the power is turned off.
  • Page 36 915GV-M7 DDR2 BIOS SETUP PCI Bus Support This AWARD BIOS also supports Version 2.1 of the Intel PCI (Peripheral Component Interconnect) local bus specification. DRAM Support DDR2 SDRAM (Double Data Rate Two Synchronous DRAM) are supported. Supported CPUs This AWARD BIOS supports the Intel CPU.
  • Page 37: Main Menu

    915GV-M7 DDR2 BIOS SETUP 1 Main Menu Once you enter Award BIOS™ CMOS Setup Utility, the Main Menu will appear on the screen. The Main Menu allows you to select from several setup functions. Use the arrow keys to select among the items and press <Enter> to accept and enter the sub-menu.
  • Page 38 915GV-M7 DDR2 BIOS SETUP Integrated Peripherals This submenu allows you to configure certain IDE hard drive options and Programmed Input/ Output features. Power Management Setup This submenu allows you to configure the power management features. PnP/PCI Configurations This submenu allows you to configure certain “Plug and Play” and PCI options.
  • Page 39 915GV-M7 DDR2 BIOS SETUP Set User Password If the Supervisor Password is not set, then the User Password will function in the same way as the Supervisor Password. If the Supervisor Password is set and the User Password is set, the “User” will only be able to view configurations but will not be able to change them.
  • Page 40: Standard Cmos Features

    915GV-M7 DDR2 BIOS SETUP 2 Standard CMOS Features The items in Standard CMOS Setup Menu are divided into 10 categories. Each category includes no, one or more than one setup items. Use the arrow keys to highlight the item and then use the<PgUp> or <PgDn> keys to select the value you want in each item.
  • Page 41 915GV-M7 DDR2 BIOS SETUP Main Menu Selections This table shows the selections that you can make on the Main Menu. Item Options Description Date mm : dd : yy Set the system date. Note that the ‘Day’ automatically changes when you set the date.
  • Page 42 915GV-M7 DDR2 BIOS SETUP Item Options Description Halt On All Errors Select the situation in which No Errors you want the BIOS to stop All, but Keyboard the POST process and All, but Diskette notify you. All, but Disk/ Key...
  • Page 43: Advanced Bios Features

    915GV-M7 DDR2 BIOS SETUP 3 Advanced BIOS Features Figure 3. Advanced BIOS Setup CPU FEATURE Delay Prior to Thermal Set this item to enable the CPU Thermal function to engage after the specified time. The Choices: 4, 8, 16 (default), 32.
  • Page 44 915GV-M7 DDR2 BIOS SETUP TM2 Bus Ratio Represents the frequency. Bus ratio of the throttled performance state that will be initiated when the on-die sensor goes from not hot to hot. The Choices: 0X (default). TM2 Bus VID Represents the voltage of the throttled performance state that will be initiated when the on-die sensor goes from not hot to hot.
  • Page 45 915GV-M7 DDR2 BIOS SETUP BOOT SEQ & FLOPPY SETUP First/Second/Third/Boot Other Device These BIOS attempt to load the operating system from the device in the sequence selected in these items. The Choices: Floppy, LS120, HDD-0, SCSI, CDROM, HDD-1, HDD-2, HDD-3, ZIP100, LAN, HPT370, Disabled, Enabled.
  • Page 46 915GV-M7 DDR2 BIOS SETUP CPU L3 Cache Depending on the CPU/chipset in use, you may be able to increase memory access time with this option. Enabled (default) Enable cache. Disabled Disable cache. HYPER-THREADING TECHNOLOGY This option allows you to enable or disabled CPU Hyper-Threading.
  • Page 47 915GV-M7 DDR2 BIOS SETUP SECURITY OPTION This option will enable only individuals with passwords to bring the system online and/or to use the CMOS Setup Utility. System A password is required for the system to boot and is also required to access the Setup Utility.
  • Page 48: Advanced Chipset Features

    915GV-M7 DDR2 BIOS SETUP 4 Advanced Chipset Features This submenu allows you to configure the specific features of the chipset installed on your system. This chipset manage bus speeds and access to system memory resources, such as DRAM. It also coordinates communications with the PCI bus. The default settings that came with your system have been optimized and therefore should not be changed unless you are suspicious that the settings have been changed incorrectly.
  • Page 49 915GV-M7 DDR2 BIOS SETUP DRAM RAS# PRECHARGE If an insufficient number of cycles is allowed for RAS to accumulate its charge before DRAM refresh, the refresh may be incomplete, and the DRAM may fail to retain data. Fast gives faster performance; and Slow gives more stable performance.
  • Page 50 915GV-M7 DDR2 BIOS SETUP VGA Setting On-Chip Video Memory Size Select Enabled allows caching of the video BIOS, resulting a better system performance. However, if any program writes to this memory area, a system error. The Choices: Disabled, Enabled (default).
  • Page 51: Integrated Peripherals

    915GV-M7 DDR2 BIOS SETUP 5 Integrated Peripherals Figure 5. Integrated Peripherals OnChip IDE Device IDE HDD Block Mode Block mode is also called block transfer, multiple commands, or multiple sector read / write. If your IDE hard drive supports block mode...
  • Page 52 915GV-M7 DDR2 BIOS SETUP IDE DMA Transfer Access This item allows you to enable or disable the IDE transfer access. The Choices: Enabled (default), Disabled. On-chip Primary PCI IDE This item allows you to enable or disable the primary/ secondary IDEChannel.
  • Page 53 915GV-M7 DDR2 BIOS SETUP ONBOARD DEVICE PCI Express Root Port Func, PCI Express Port 1/2/3/4 This item allows you to select the PCI Express Port. The Choices: Auto (default), Enabled, Disabled. PCI-E Compliancy Mode This item allows you to select the PCI-E Compliancy Mode.
  • Page 54 915GV-M7 DDR2 BIOS SETUP USB Mouse Support This item allows you to enable or disable the USB Mouse Legacy Support. Enabled Enable USB Mouse Support. Disabled (default) Disable USB Mouse Support. AC97 Audio This item allows you to decide to enable/ disable to support AC97 Audio.
  • Page 55 915GV-M7 DDR2 BIOS SETUP Onboard FDC Controller Select Enabled if your system has a floppy disk controller (FDC) installed on the system board and you wish to use it. If install and FDC or the system has no floppy drive, select Disabled in this field.
  • Page 56: Power Management Setup

    915GV-M7 DDR2 BIOS SETUP 6 Power Management Setup The Power Management Setup Menu allows you to configure your system to utilize energy conservation and power up/power down features. Figure 6. Power Management Setup ACPI & WAKE UP EVENTS ACPI Function This item displays the status of the Advanced Configuration and Power Management (ACPI).
  • Page 57 915GV-M7 DDR2 BIOS SETUP ACPI Suspend Type The item allows you to select the suspend type under the ACPI operating system. The Choices: S1 (POS) (default) Power on Suspend S3 (STR) Suspend to RAM S1 & S3 POS+STR Run VGABIOS if S3 Resume Choosing Enabled will make BIOS run VGA BIOS to initialize the VGA card when system wakes up from S3 state.
  • Page 58 915GV-M7 DDR2 BIOS SETUP Hot Key Power ON Input password and press Enter to set the Keyboard power on password. The Choices: Ctrl-F1 (default), Ctrl-F2, Ctrl-F3, Ctrl-F4, Ctrl-F5, Ctrl-F6, Ctrl-F7, Ctrl-F8, Ctrl-F9, Ctrl-F10, Ctrl-F11, and Ctrl-F12. POWER After PWR-Fail This setting specifies whether your system will reboot after a power fail or interrupts occurs.
  • Page 59 915GV-M7 DDR2 BIOS SETUP Power Management This category allows you to select the type (or degree) of power saving and is directly related to the following modes: 1. HDD Power Down. 2. Suspend Mode. There are four options of Power Management, three of which have fixed mode settings Min.
  • Page 60 915GV-M7 DDR2 BIOS SETUP Suspend Mode The item allows you to select the suspend type under ACPI operating system. The Choices: Disabled (default), 1 Min, 2 Min, 4 Min, 6 Min, 8 Min, 10 Min, 20 Min, 30 Min, 40 Min, 1 Hour.
  • Page 61: Pnp/Pci Configurations

    915GV-M7 DDR2 BIOS SETUP 7 PnP/PCI Configurations This section describes configuring the PCI bus system. PCI, or Personal Computer Interconnect, is a system which allows I/O devices to operate at speeds nearing the speed of the CPU itself uses when communicating with its own special components. This section covers some very technical items and it is strongly recommended that only experienced users should make any changes to the default settings.
  • Page 62 915GV-M7 DDR2 BIOS SETUP IRQ RESOURCES This submenu will allow you to assign each system interrupt a type, depending on the type of device using the interrupt. When you press the “Press Enter” tag, you will be directed to a submenu that will allow you to configure the system interrupts.
  • Page 63: Pc Health Status

    915GV-M7 DDR2 BIOS SETUP 8 PC Health Status Figure 8. PC Health Status CPU FAN Control by The Choice “smart” can make your CPU FAN to reduce noise. The Choices: SMART (default), Always On. Shutdown Temperature This item allows you to set up the CPU shutdown Temperature. This item only effective...
  • Page 64: Frequency/ Voltage Control

    915GV-M7 DDR2 BIOS SETUP 9 Frequency/ Voltage Control Figure 9. Frequency/ Voltage Control CPU CLOCK RATIO The Choices: 8X (default), 9X, 10X, 11X, 12X, 13X, 14 X, 15X, 16X, 17X, 18X, 19X, 20 X, 21 X, 22 X, and 23X.
  • Page 65 915GV-M7 DDR2 BIOS SETUP Method 2: Press the <Insert> key and Power button simultaneously, after that keep-on pressing the <Insert> key until the power-on screen showed. This action will boot-up the system according to FSB of the processor. It’s strongly recommended to set CPU Vcore and clock in default setting. If the...
