945G-M7 / 945P-M7
FCC Information and Copyright
This equipment has been tes ted and found to comply with the limits of a Class
B digital devic e, purs uant to Part 15 of the FCC Rules . T hese limits are designed
to provide reasonable protec tion against harmful interference in a residential
installation. T his equipment generates , uses and can radiate radio frequency
energy and, if not ins talled and used in accordance with the instructions , may
cause harmful interference to radio communications . There is no guarantee
that interference will not occur in a particular ins tallation.
The vendor makes no representations or warranties with respec t to the
contents here and s pecially disclaims any implied warranties of merchantability
or fitness for any purpose. Further the vendor reserves the right to revise this
publication and to make c hanges to the c ontents here without obligation to
notify any party beforehand.
D uplication of this publication, in part or in whole, is not allowed without first
obtaining the vendor's approval in writing.
The content of this user's manual is subject to be c hanged without notice and
we will not be res ponsible for any mis takes found in this user's manual. All the
brand and produc t names are trademarks of their respec tive companies .
i

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the I945G-M7 and is the answer not in the manual?

Questions and answers

Summary of Contents for Biostar I945G-M7

  • Page 1 945G-M7 / 945P-M7 FCC Information and Copyright This equipment has been tes ted and found to comply with the limits of a Class B digital devic e, purs uant to Part 15 of the FCC Rules . T hese limits are designed to provide reasonable protec tion against harmful interference in a residential installation.
  • Page 2: Table Of Contents

    Table of Contents Chapter 1: Introduction ..............1 Motherboard Features............. 1 Package Checklist ............4 Layout and Components..........5 Chapter 2: Hardware Installation ..........6 Installing Central Processing Unit (CPU)......6 FAN Headers ..............8 Installing System Memory..........9 Connectors and Slots............. 10 Chapter 3: Headers &...
  • Page 3: Chapter 1: Introduction

    945G-M7 / 945P-M7 CHAPTER 1: INTRODUCTION OTHERBOARD EATURES Supports LGA 775. Supports Intel Pentium 4 processor up to 3.8GHz. Supports Intel Pentium D processor. Front Side Bus at the following frequency ranges: ­ 533MHz (133MHz Core Clock) ­ 800MHz (200MHz Core Clock) ­...
  • Page 4 945G-M7 / 945P-M7 System Memory Supports Dual Channel DDR2. Supports DDR2 533 (266MHz) / 667 (333MHz) for a theoretical maximum bandwidth of 10.7 GB/s. Supports 256-Mb, 512-Mb, or 1G-Mb technologies for x8 and x16 devices. Supports non-ECC DIMMs. Maximum DRAM space is up to 4GB. DIMM Socket DDR Module Total Memory Size...
  • Page 5 945G-M7 / 945P-M7 Gigabit LAN (optional) Chip: RTL8110S. Half/Full duplex capability. Supports 10 Mb/s, 100 Mb/s and 1Gb/s auto-negotiation. Supports ACPI power management. Se rial ATA II Controller integrated in ICH7. Supports 4 Serial ATA II (SATA II) devices. Serial ATA 2.0 specification compliant. Data transfer rate up to 3Gb/s.
  • Page 6: Package Checklist

    945G-M7 / 945P-M7 Back Panel I/O Conne ctors 1 Serial port. 1 Printer port. 1 PS/2 Mouse port. 1 PS/2 Keyboard port. 1 VGA port. (only for 945G-M7) 1 RJ-45 LAN jack / Giga LAN jack. (optional) 4 USB 2.0 ports. 1 vertical audio port including 1 line-in connector, 1 line-out connector, and 1 MIC-in connector.
  • Page 7: Layout And Components

    945G-M7 / 945P-M7 AYOUT AND OMPONENTS JATXP WR2 JCFAN 1 JKBMS1 LGA775 CPU1 (only for 945G -M 7) 945G Super JRJ45USB1 I /O 945P JAUDIO1 J AT XPWR 1 PCI-EX16 J A UD IO2 BI OS J C DIN 1 PCI- EX1_1 COD EC J DJ 1...
  • Page 8: Chapter 2: Hardware Installation

    945G-M7 / 945P-M7 CHAPTER 2: HARDWARE INSTALLATION (CPU) NSTALLING ENTRAL ROCESSING Special Notice: Remove Pin Cap before installation, and make good preservation for future use. When the CPU is removed, cover the Pin Cap on the empty socket to ensure pin legs won’t be damaged. Pin Cap Step 1: Pull the socket locking lever out from the socket and then raise the lever up to a 90-degree angle.
  • Page 9 945G-M7 / 945P-M7 Step 2: Look for the triangular cut edge on socket, and the golden dot on CPU should point forwards this triangular cut edge. The CPU will fit only in the correct orientation. Step 2-1: Step 2-2: Step 3: Hold the CPU down firmly, and then lower the lever to locked position to complete the installation.
  • Page 10: Fan Headers

    945G-M7 / 945P-M7 FAN H EADERS These fan headers support cooling-fans built in the computer. The fan cable and connector may be different according to the fan manufacturer. Connect the fan cable to the connector while matching the black wire to pin#1.
  • Page 11: Installing System Memory

    945G-M7 / 945P-M7 NSTALLING YSTEM EMORY 1. Unlock a DIMM slot by pressing the retaining clips outward. Align a DIMM on the slot such that the notch on the DIMM matches the break on the Slot. 2. Insert the DIMM vertically and firmly into the slot until the retaining chip snap back in place and the DIMM is properly seated.
  • Page 12: Connectors And Slots

    945G-M7 / 945P-M7 ONNECTORS AND LOTS FDD1: Floppy Disk Connector The motherboard provides a standard floppy disk connector that supports 360K, 720K, 1.2M, 1.44M and 2.88M floppy disk types. This connector supports the provided floppy drive ribbon cables. IDE1: Hard Disk Connector The motherboard has a 32-bit Enhanced PCI IDE Controller that provides PIO Mode 0~4, Bus Master, and Ultra DMA 33/66/100 functionality.
  • Page 13 945G-M7 / 945P-M7 PCI1~PCI2: Peripheral Component Interconnect Slots This motherboard is equipped with 2 standard PCI slots. PCI stands for Peripheral Component Interconnect, and it is a bus standard for expansion cards. This PCI slot is designated as 32 bits. PCI1 PCI2 PCI-EX16: PCI-Express x16 Slot...
  • Page 14: Chapter 3: Headers & Jumpers Setup

    945G-M7 / 945P-M7 CHAPTER 3: HEADERS & JUMPERS SETUP OW TO ETUP UMPERS The illustration shows how to set up jumpers. When the jumper cap is placed on pins, the jumper is “close”, if not, that means the jumper is “open”.
  • Page 15 945G-M7 / 945P-M7 JATXPWR2: ATX Power Connector By connecting this connector, it will provide +12V to CPU power circuit. Assignment +12V +12V Ground Ground SATA1~SATA4: Serial ATA Connectors The motherboard has a PCI to SATA Controller with 4 channels SATA interf ace, it satisfies the SATA 2.0 spec and with transfer rate of 3Gb/s.
  • Page 16 945G-M7 / 945P-M7 JKBV1: Power Source Header for PS/2 Keyboard and Mouse Pin 1-2 Close (Default) +5V for PS/2 keyboard and mouse. Pin 2-3 close PS/2 keyboard and mouse are powered by +5V standby voltage. Note: In order to support this func tion “Power-on s ystem via keyboar d and mouse”, “JKBV1” jumper cap should be plac ed on Pin 2-3.
  • Page 17: Front Panel Header

    945G-M7 / 945P-M7 JPANEL1: Front Panel Header This 24-pin connector includes Power-on, Reset, HDD LED, Power LED, Sleep button, speaker and IrDA Connection. It allows user to connect the PC case’s front panel switch f unctions. PWR_LED On/Off HLED Assignment Functio n Assignment Functio n...
  • Page 18 945G-M7 / 945P-M7 JCDIN1: CD-RO M Audio-in Connector This connector allows user to connect the audio source f rom the variety dev ices, like CD-ROM, DVD-ROM, PCI sound card, PCI TV turner card etc.. Assignment Left channel input Ground Ground Right channel input JCMOS1: Clear CMOS Header By placing the jumper on pin2-3, it allows user to restore the BIOS saf e setting...
  • Page 19 945G-M7 / 945P-M7 JSPDIF_OUT1: Digital Audio-out Connector This connector allows user to connect the PCI bracket SPDIF output header. Assignment SPDIF_OUT Ground JSPDIF_IN1 (optional): Digital Audio-in Connector This connector allows user to connect the PCI bracket SPDIF input header. Assignment SPDIF_IN Ground...
  • Page 20: Chapter 4: Useful Help

    BIOS contents are corrupted. In this Case, please follow the procedure below to restore the BIOS: Make a bootable floppy disk. Download the Flash Utility “AWDFLASH.exe” from the Biostar website: www.biostar.com.tw Confirm motherboard model and download the respectively BIOS from Biostar website.
  • Page 21 945G-M7 / 945P-M7 B. CPU Overheated If the system shutdown automatically after power on system for seconds, that means the CPU protection function has been activated. When the CPU is over heated, the motherboard will shutdown automatically to avoid a damage of the CPU, and the system may not power on again.
  • Page 22: Troubleshooting

    945G-M7 / 945P-M7 ROUBLESHOOTING Probable Solution No power to the system at all Make sure power cable is Power light don’t illuminate, f an securely plugged in. inside power supply does not turn Replace cable. Contact technical support. Indicator light on key board does not turn on.
  • Page 23: Chapter 5: Warpspeeder

    945G-M7 / 945P-M7 WARPSPEEDER™ CHAPTER 5: NTRODUCTION [WarpSpeeder™], a new powerful control utility, features three user-friendly functions including Overclock Manager, Overvoltage Manager, and Hardware Monitor. With the Overclock Manager, users can easily adjust the frequency they prefer or they can get the best CPU performance with just one click. The Overvoltage Manager, on the other hand, helps to power up CPU core voltage and Memory voltage.
  • Page 24: Installation

    945G-M7 / 945P-M7 NSTALLATION 1. Execute the setup execution file, and then the following dialog will pop up. Please click “Next” button and follow the default procedure to install. 2. When you see the following dialog in setup procedure, it means setup is completed.
  • Page 25: Warpspeederâ„¢] Includes 1 Tray Icon And 5 Panels

    945G-M7 / 945P-M7 ™] PEEDER INCLUDES TRAY ICON AND PANELS 1. Tray Icon: Whenever the Tray Icon utility is launched, it will display a little tray icon on the right side of Windows Taskbar. This utility is responsible for conveniently invoking [WarpSpeeder™] Utility.
  • Page 26 945G-M7 / 945P-M7 2. Main Panel If you click the tray icon, [WarpSpeeder™] utility will be invoked. Please refer to the following figure; the utility’s first window you will see is Main Panel. Main Panel contains fe ature s as follows: a.
  • Page 27 945G-M7 / 945P-M7 3. Voltage Panel Click the Voltage button in Main Panel, the button will be highlighted and the Voltage Panel will slide out to up as the following figure. In this panel, you can decide to increase CPU core voltage and Memory voltage or not.
  • Page 28 945G-M7 / 945P-M7 4. Overclock Panel Click the Overclock button in Main Panel, the button will be highlighted and the Overclock Panel will slide out to left as the following figure. O ve rclock Panel contains the these features: a. “–3MHz button”, “-1MHz button”, “+1MHz button”, and “+3MHz button”: provide user the ability to do real-time overclock adjustment.
  • Page 29 945G-M7 / 945P-M7 “Auto-overclock button”: User can click this button and [WarpSpeeder™] will set the best and stable performance and frequency automatically. [WarpSpeeder™] utility will execute a series of testing until system fail. Then system will do fail-safe reboot by using Watchdog function. After reboot, the [WarpSpeeder™] utility will restore to the hardware default setting or load the verified best and stable frequency according to the Recovery Dialog’s setting.
  • Page 30 945G-M7 / 945P-M7 6. About Panel Click the “about” button in Main Panel, the button will be highlighted and the About Panel will slide out to up as the following figure. In this panel, you can get model name and detail information in hints of all the chipset that are related to overclocking.
  • Page 31 945G-M7 / 945P-M7 Note : Because the overclock, overvoltage, and hardware monitor features are controlled by several separate chipset, [WarpSpeeder™] divide these features to separate panels. If one chipset is not on board, the correlative button in Main panel will be disabled, but will not interfere other panels’...
  • Page 32 945G-M7 & 945P-M7 BIOS SETUP BIOS Setup..................1 1 Main Menu....................3 2 Standard CMOS Features................6 3 Advanced BIOS Features................9 4 Advanced Chipset Features................. 16 5 Integrated Peripherals ................. 20 6 Power Management Setup................26 7 PnP/PCI Configurations ................31 8 PC Health Status ..................
  • Page 33: Bios Setup

    945G-M7 & 945P-M7 BIOS SETUP BIOS Setup Introduction This manual discussed Award™ Setup program built into the ROM BIOS. The Setup program allows users to modify the basic system configuration. This special information is then stored in battery-backed RAM so that it retains the Setup information when the power is turned off.
  • Page 34 945G-M7 & 945P-M7 BIOS SETUP PCI Bus Support This AWARD BIOS also supports Version 2.1 of the Intel PCI (Peripheral Component Interconnect) local bus specification. DRAM Support DDR2 SDRAM (Double Data Rate Two Synchronous DRAM) are supported. Supported CPUs This AWARD BIOS supports the Intel CPU. Using Setup In general, you use the arrow keys to highlight items, press <Enter>...
  • Page 35: Main Menu

    945G-M7 & 945P-M7 BIOS SETUP 1 Main Menu Once you enter Award BIOS™ CMOS Setup Utility, the Main Menu will appear on the screen. The Main Menu allows you to select from several setup functions. Use the arrow keys to select among the items and press <Enter> to accept and enter the sub-menu. !! WARNING !! The information about BIOS defaults on manual (Figure 1,2,3,4,5,6,7,8,9) is just for reference, please refer to the BIOS...
  • Page 36 945G-M7 & 945P-M7 BIOS SETUP Integrated Peripherals This submenu allows you to configure certain IDE hard drive options and Programmed Input/ Output features. Power Management Setup This submenu allows you to configure the power management features. PnP/PCI Configurations This submenu allows you to configure certain “Plug and Play” and PCI options. PC Health Status This submenu allows you to monitor the hardware of your system.
  • Page 37 945G-M7 & 945P-M7 BIOS SETUP Set User Password If the Supervisor Password is not set, then the User Password will function in the same way as the Supervisor Password. If the Supervisor Password is set and the User Password is set, the “User”...
  • Page 38: Standard Cmos Features

    945G-M7 & 945P-M7 BIOS SETUP 2 Standard CMOS Features The items in Standard CMOS Setup Menu are divided into 10 categories. Each category includes no, one or more than one setup items. Use the arrow keys to highlight the item and then use the<PgUp>...
  • Page 39 945G-M7 & 945P-M7 BIOS SETUP Main Menu Selections This table shows the selections that you can make on the Main Menu. Item Options Description Date mm : dd : yy Set the system date. Note that the ‘Day’ automatically changes when you set the date.
  • Page 40 945G-M7 & 945P-M7 BIOS SETUP Item Options Description Halt On All Errors Select the situation in which No Errors you want the BIOS to stop All, but Keyboard the POST process and All, but Diskette notify you. All, but Disk/ Key Base Memory Displays the amount of conventional memory...
  • Page 41: Advanced Bios Features

    945G-M7 & 945P-M7 BIOS SETUP 3 Advanced BIOS Features Figure 3. Advanced BIOS Setup CPU FEATURE Delay Prior to Thermal Set this item to enable the CPU Thermal function to engage after the specified time. The Choices: 4, 8, 16 (default), 32. Thermal Management This option allows you to choose the thermal management method of your monitor.
  • Page 42: Limit Cpuid Maxval

    945G-M7 & 945P-M7 BIOS SETUP TM2 Bus Ratio This option represents the frequency. (Bus ratio of the throttled performance state that will be initiated when the on-die sensor goes from not hot to hot.) Min= 0 Max= 255 Key in a DEC number. The Choices: 0X (default).
  • Page 43 945G-M7 & 945P-M7 BIOS SETUP Cache Setup CPU L3 Cache Depending on the CPU/chipset in use, you may be able to increase memory access time with this option. Enabled (default) Enable cache. Disabled Disable cache.
  • Page 44 945G-M7 & 945P-M7 BIOS SETUP Boot Seq & Floppy Setup This item allows you to setup Boot Seq & Floppy. Hard Disk Boot Priority These BIOS attempt to arrange the Hard Disk boot sequence automatically. This will depend on which Hard Disk is installed. The Choices: Pri.
  • Page 45: Virus Warning

    945G-M7 & 945P-M7 BIOS SETUP First/Second/Third/Boot Other Device These BIOS attempt to load the operating system from the device in the sequence selected in these items. The Choices: Floppy, LS120, HDD-0, SCSI, CDROM, ZIP100, LAN, Disabled. Swap Floppy Drive For systems with two floppy drives, this option allows you to swap logical drive assignments.
  • Page 46 945G-M7 & 945P-M7 BIOS SETUP Gate A20 Option Select if chipset or keyboard controller should control Gate A20. Normal A pin in the keyboard controller controls GateA20. Fast (default) Lets chipset control Gate A20. Typematic Rate Setting When a key is held down, the keystroke will repeat at a rate determined by the keyboard controller.
  • Page 47 945G-M7 & 945P-M7 BIOS SETUP Small Logo (EPA) Show This item allows you to select whether the “Small Logo” shows. Enabled (default) “Small Logo” shows when system boot up. Disabled No “Small Logo” shows when system boots up. Summary Screen Show This item allows you to enable/disable the summary screen.
  • Page 48: Advanced Chipset Features

    945G-M7 & 945P-M7 BIOS SETUP 4 Advanced Chipset Features This submenu allows you to configure the specific features of the chipset installed on your system. This chipset manage bus speeds and access to system memory resources, such as DRAM. It also coordinates communications with the PCI bus. The default settings that came with your system have been optimized and therefore should not be changed unless you are suspicious that the settings have been changed incorrectly.
  • Page 49 945G-M7 & 945P-M7 BIOS SETUP DRAM RAS# Precharge If an insufficient number of cycles is allowed for RAS to accumulate its charge before DRAM refresh, the refresh may be incomplete, and the DRAM may fail to retain data. Fast gives faster performance; and Slow gives more stable performance.
  • Page 50 945G-M7 & 945P-M7 BIOS SETUP PCI Express Root Port Func PCI Express Port This item allows you to select the PCI Express Port. The Choices: Auto (default), Enabled, Disabled. PCI-E Compliancy Mode This item allows you to select the PCI-E Compliancy Mode. The Choices: v1.0a (default), v1.0.
  • Page 51 945G-M7 & 945P-M7 BIOS SETUP DVMT Memory Size DVMT stands for „Dynamic Video Memory Technology“. This is an enhancemnet of the unified memory architecture (UMA) concept. Where the optimum amount of memory is allocated for balanced graphics and system performance. DVMT dynamically reponds to system requirements and applications demands, by allocating the proper amount of display, texturing and buffer memory after the operating system has booted.
  • Page 52: Integrated Peripherals

    945G-M7 & 945P-M7 BIOS SETUP 5 Integrated Peripherals Figure 5. Integrated Peripherals OnChip IDE Device If you highlight the literal “Press Enter” next to the “OnChip IDE Device” label and then press the enter key, it will take you a submenu with the following options:...
  • Page 53 945G-M7 & 945P-M7 BIOS SETUP IDE HDD Block Mode Block mode is also called block transfer, multiple commands, or multiple sector read / write. If your IDE hard drive supports block mode (most new drives do), select Enabled for automatic detection of the optimal number of block mode (most new drives do), select Enabled for automatic detection of the optimal number of block read / write per sector where the drive can support.
  • Page 54 945G-M7 & 945P-M7 BIOS SETUP On-Chip Serial ATA This item allows you to choose: Disabled: disabled SATA Controller Combined Mode: PATA and SATA are combined max of 2 IDE drivers in each channel. Enhanced Mode: enabled both SATA and PATA max of 6 IDE drivers are supported.
  • Page 55 945G-M7 & 945P-M7 BIOS SETUP Onboard Device If you highlight the literal “Press Enter” next to the “Onboard Device” label and then press the enter key, it will take you a submenu with the following options: USB Controller Select Enabled if your system contains a Universal Serial Bus (USB) controller and you have USB peripherals.
  • Page 56 945G-M7 & 945P-M7 BIOS SETUP Onboard RAID <ITE8211> The Choices: Enabled (default), Disabled. Onboard RAID BIOS The Choices: Enabled (default), Disabled. Onboard 1394 The Choices: Enabled (default), Disabled. Onboard LAN This item allows you to enable or disable the Onboard LAN. The Choices: Enabled (default), Disabled.
  • Page 57 945G-M7 & 945P-M7 BIOS SETUP Onboard Serial Port 1 Select an address and corresponding interrupt for the first and second serial ports. The Choices: Disabled, 3F8/IRQ4 (default), 2F8/IRQ3, 3E8/IRQ4, 2E8/IRQ3, Auto. Onboard IR Function The Choices: Disabled (default), Enabled. UART Mode Select This item allows you to determine which Infra Red (IR) function of onboard I/O chip.
  • Page 58: Power Management Setup

    945G-M7 & 945P-M7 BIOS SETUP 6 Power Management Setup The Power Management Setup Menu allows you to configure your system to utilize energy conservation and power up/power down features. Figure 6. Power Management Setup ACPI & Wake Up Events ACPI Function This item displays the status of the Advanced Configuration and Power Management (ACPI).
  • Page 59 945G-M7 & 945P-M7 BIOS SETUP ACPI Suspend Type The item allows you to select the suspend type under the ACPI operating system. The Choices: S1 (POS) (default) Power on Suspend S3 (STR) Suspend to RAM S1 & S3 POS+STR Run VGABIOS if S3 Resume Choosing Enabled will make BIOS run VGA BIOS to initialize the VGA card when system wakes up from S3 state.
  • Page 60 945G-M7 & 945P-M7 BIOS SETUP KB POWER ON Password Input password and press Enter to set the Keyboard power on password. Hot Key Power ON Input password and press Enter to set the Keyboard power on password. The Choices: Ctrl-F1 (default), Ctrl-F2, Ctrl-F3, Ctrl-F4, Ctrl-F5, Ctrl-F6, Ctrl-F7, Ctrl-F8, Ctrl-F9, Ctrl-F10, Ctrl-F11, and Ctrl-F12.
  • Page 61 945G-M7 & 945P-M7 BIOS SETUP Power Management This category allows you to select the type (or degree) of power saving and is directly related to the following modes: 1. HDD Power Down. 2. Suspend Mode. There are four options of Power Management, three of which have fixed mode settings Min.
  • Page 62 945G-M7 & 945P-M7 BIOS SETUP Suspend Mode The item allows you to select the suspend type under ACPI operating system. The Choices: Disabled (default), 1 Min, 2 Min, 4 Min, 6 Min, 8 Min, 10 Min, 20 Min, 30 Min, 40 Min, 1 Hour. This selection will cause the system to turn off the vertical and horizontal synchronization ports and write blanks to the video buffer.
  • Page 63: Pnp/Pci Configurations

    945G-M7 & 945P-M7 BIOS SETUP 7 PnP/PCI Configurations This section describes configuring the PCI bus system. PCI, or Personal Computer Interconnect, is a system which allows I/O devices to operate at speeds nearing the speed of the CPU itself uses when communicating with its own special components. This section covers some very technical items and it is strongly recommended that only experienced users should make any changes to the default settings.
  • Page 64 945G-M7 & 945P-M7 BIOS SETUP IRQ Resources This submenu will allow you to assign each system interrupt a type, depending on the type of device using the interrupt. When you press the “Press Enter” tag, you will be directed to a submenu that will allow you to configure the system interrupts.
  • Page 65: Pc Health Status

    945G-M7 & 945P-M7 BIOS SETUP 8 PC Health Status Figure 8. PC Health Status CPU FAN Control The Choice “smart” can make your CPU FAN to reduce noise. The Choices: Always On, Smart (default). Shutdown Temperature This item allows you to set up the CPU shutdown Temperature. This item only effective under Windows 98 ACPI mode The Choices: 60 / 140 , 65 / 149 , 70 / 158 ℃, Disabled (default).
  • Page 66 945G-M7 & 945P-M7 BIOS SETUP Current CPU FAN Speed This field displays the current speed of CPU fan. Current SYS FAN Speed This field displays the current speed SYSTEM fan.
  • Page 67: Frequency/ Voltage Control

    945G-M7 & 945P-M7 BIOS SETUP 9 Frequency/ Voltage Control Figure 9. Frequency/ Voltage Control CPU Clock Ratio This item allows you to select the CPU Ratio. Min = 8 Max = 50 Key in a DEC number. The Choices: 8X (default). CPU Voltage Regulator This item allows you to select CPU Voltage Regulator The Choices: Default (default), +5%, +15%.
  • Page 68 945G-M7 & 945P-M7 BIOS SETUP Method 1: Clear the COMS data by setting the JCOMS1 ((2-3) closed)) as “ON” status. All the CMOS data will be loaded as defaults setting. Method 2: Press the <Insert> key and Power button simultaneously, after that keep-on pressing the <Insert>...
