BM 1619929437 2/03
2/12/03
Functional Description and Specifications
Disconnect the plug from the power source before making any
WARNING
!
assembly, adjustments or changing accessories. Such preventive
safety measures reduce the risk of starting the tool accidentally.
FIG. 1
VENTILATION OPENINGS
LOCKING SLEEVE
DUST SHIELD
Model number
Shank style
Maximum Capacities:
Carbide tipped bits
Thin wall core bits
NOTE: For tool specifications refer to the nameplate on your tool.
12:05 PM
Page 6
Rotary Hammer
SELECTOR LEVER
AUXILIARY
HANDLE
VENTILATION
OPENINGS
HAND GRIP
-6-
TRIGGER
SWITCH
TRIGGER
RELEASE
SWITCH
VARIABLE
SPEED DIAL
SERVICE
REMINDER
LIGHT
11235EVS
SDS Max
1-3/4"
5"
