Dining Chair Assembly
DESCRIPTION
ITEM
A
B
C
lock washer
D
Allen Wrench
Step 1：Place the chair on a smooth flat surface.
Step 2: Attach front leg (F) using Bolt A, Washer B, and Lock washer C. Tighten with Allen Wrench D
Step 3: Attach back leg (E) using Bolt A, Washer B, and Lock washer C. Tighten with Allen Wrench D
DS-2520-900-1
Parts and Hardware
ITEM
Bolt
8
E
washer
8
F
8
G
1
DESCRIPTION
back leg
front leg
chair back
attached seat
2
2
1
