PD8-6363 Explosion-Proof Dual Pulse Input Rate/Totalizer
Instruction Manual
• Fully-Approved Explosion-Proof Pulse Input Flow Rate/Totalizers
• Dual Pulse, Open Collector, NPN, PNP, TTL, Switch Contact, Sine Wave (Coil), Square Wave Inputs
• Rate, Total, and Grand Total for Each Input Channel
• Display Rate & Total at the Same Time
• Dual-Line 6-Digit Display, 0.6" (15 mm) & 0.46" (12 mm)
• SafeTouch Through-Glass Button Programming
• Display Mountable at 0°, 90°, 180°, & 270°
• Isolated 5, 10 or 24 VDC Flowmeter Power Supply
• Gate Function for Display of Slow Pulse Rates
• 4 Relays with Interlocking Capability + Isolated 4-20 mA Output Option
• Free PC-Based, On-Board, MeterView Pro USB Programming Software
• SunBright Display Standard Feature; Great for Outdoor Applications
• Total, Grand Total or Non-Resettable Grand Total
• Front Panel or Remote Total Reset
• Password Protection for Programming and Total Reset
• Total Stored in Non-Volatile Memory
• K-Factor, Internal Scaling, or External Calibration
• Operating Temperature Range: -40 to 60°C (-40 to 140°F)
• FM Approved as Explosion-Proof / Dust-Ignition-Proof / Flame-Proof
• CSA Certified as Explosion-Proof / Dust-Ignition-Proof / Flame-Proof
• ATEX and IECEx Certified as Flame-Proof
• Input Power Options: 85-265 VAC / 90-265 VDC or 12-24 VDC / 12-24 VAC
• Programmable Display, Function Keys & Digital Inputs
• Flanges for Wall or Pipe Mounting
• Explosion-Proof, IP68, NEMA 4X Die-Cast Aluminum Enclosure
• On-Board RS-485 Serial Communications
• Modbus RTU Communication Protocol Standard
• Four 3/4" NPT Threaded Conduit Openings (Two Plugs Installed)
• 3-Year Warranty
PRECISION DIGITAL CORPORATION
233 South Street • Hopkinton MA 01748 USA
Tel (800) 343-1001 • Fax (508) 655-8990
www.predig.com
