Common Computer Resolutions
Resolution
800x600
1024x768
1280x768
1280x1024
1366x768
1440x1080
1600x1200
DISCLAIMER
Maximum distance specifications may vary based on UTP cable
and crimping connection quality. For optimum performance
at maximum distances, please use STP cabling with properly
soldered shielded RJ45 connectors.

Technical Specifications

Inputs: KD-CATHDXTx - 1 HDMI/DVI connector; KD-CATHDXRx - 2 CAT5e/6 IN
»
on RJ45 connectors; Bi-directional IR / Uni-directional RS-232 on 3.5 mm mono
mini jack
Outputs: KD-CATHDXTx - 2 CAT5e/6 OUT on RJ45 connectors; KD-CATHDXRx
»
- 1 HDMI/DVI connector; Bi-directional IR / Uni-directional RS-232 on 3.5 mm
mono mini jack
Bandwidth: 10.2 Gb/s TMDS bandwidth
»
EQ Adjustments: Auto Adjust
»
HDMI ® and HDCP Licensing: Fully licensed and compatible with all HDMI
»
and HDCP techologies
Common Name Distance
SVGA 270'
XGA 270'
WXGA 270'
SXGA 270'
WXGA+ 270'
SXGA+ 140'
UXGA 140'
Link and Range: Single Link: (1080p/60) 12 bit color depth, 1920x1200 max.
»
up to 140 ft., STP 150 ft.; (1080i/60, 720p, 1080p/24) up to 270 ft.
Deep Color Support: Supports Digital Video Formats in Deep Color Mode at
»
up to 12 bits/color for 480p/720p/1080i resolutions
Lossless Compressed Digital Audio Support: Dolby
»
and DTS -HD Master Audio
™
DDC Signal (Data): Input DDC Signal: 5 Volts p-p (TTL)
»
HDMI Video/Audio Signal: Input Video Signal: 1.2 Volts p-p
»
HDMI Connector: Type A, 19 Pin Female
»
RJ45 Connectors: Shielded Link Connector RJ45
»
DDC Communication: EDID and HDCP Transparency from Display to Source
»
Power: External Power Supply – 5V DC / 2A, 110-240 VAC, 50-60 Hz
»

General Specifications

Regulation: CE, FCC, RoHS, WEEE
»
Accessories: Mounting Bracket, Locking HDMI Cable Clip,
»
KD-PS5V2A UL Certified Power Supply
Product Dimensions: L = 3.5" W = 1.75" H = 1"
»
Shipping Carton Dimensions: L = 7.5" W = 8.5" H = 2"
»
Product Weight: 1 lb
»
Shipping Weight: 2 lbs
»
Enclosure: Black Metal
»
