Summary of Contents for tempmate GS2
-
Page 2: Table Of Contents
Can I start and stop the device more than once? ....................... 15 What does the recording duration of the device mean? ................... 15 What does the shelf life mean? ............................16 Can I connect an external sensor to the tempmate.®-GS2 T and TH model? ..........16 Can I remove the external sensor? ........................... 16 How can a device be stopped? ............................16 1. -
Page 3: Tempmate.®-Gs2 Model
3. tempmate.®-GS2 Models One-way Temperature Rel. humidity Localisation Light Extended measuring range V1.0-02/2022-DE · Technische Änderungen und Irrtümer vorbehalten... -
Page 4: Device Description
empower your supply chain. 4. Device Description 5. Display Descriprion LED Indicator Start Button Stop Button 1.Signal icon 7. Alarm status 2. Probe mark 8. Start-up delay 3.MAX&MIN 9. Temperature unit 4.Charging icon 10. Humidity unit 5.Battery icon 11. Alarm type 6.Record icon 12. -
Page 5: Quick Start Guide
Create a tempmate cloud account STEP 5 Track the shipment To configure and access the device the user need a tempmate cloud account. The tempmate cloud account is free of cost and any user can create one. The only prerequisite required to creating an account is a valid email The shipment can be tracked and monitored through the tempmate cloud platform. Additionally, reports can be id. The user can create a tempmate cloud account by clicking on this link viewed and exported in PDF and CSV format from the cloud platform. https://web.tempmate.cloud/login STEP 6 Stopping the device and following the instructions. Once the shipment arrives the destination the device can be stopped by pressing continuously the red stop button for more than 5 sec. The stop of the device is confirmed by 10 times flashing of Red LED, additionally... -
Page 6: Operation And Usage
empower your supply chain. 7. Operation and Usage STEP 1 Status Check for not started device STEP 3 Start-up delay Press once the green “START” button and the screen will display the word “SLEEP” indicating that the logger is If “Startup delay” is set, once the logger is turned on it enters the start-up delay phase. The icon is displayed on the right side, indicating that the logger is in the start-up delay phase. currently in not started state. STEP 2 Starting the device STEP 4 Recording information Continuously press the green “START” button for more than 5 sec. - Page 7 Optionally the PDF report can be downloaded locally by connecting the logger to the computer using a USB cable* (*not supplied with the logger). Optionally, the logger can be configured for stop from the cloud platform remotely or by connecting to the USB port. STEP 6 View final information After stopping, press once the ”START” button to view local time of the device, the MAX and the MIN STEP 8 Charging temperature data recorded. The battery of the tempmate GS2 can be charged. If the battery is low before use, it can be directly connected to the micro USB interface for charging (Please use 5V charger). When charging, the charging icon will be displayed. V1.0-02/2022-DE · Technische Änderungen und Irrtümer vorbehalten...
-
Page 8: Faq
8. FAQ How can I start the tempmate.®-GS2 device? Can I reconfigure the parameters after the device is started? The device can be started with the green start button by pressing it continuously for more than 5 sec. Yes, the user can reconfigure or change the device configuration anytime from the cloud portal by clicking the “Edit” tab against a specific device. I have pressed the start button but still the device is not started. What should I do? How can I receive alarm threshold alerts? The device is configured to start when the start button is pressed more than 5 sec and less than 40 sec. So,... -
Page 9: What Does The Shelf Life Mean
That means that the user can start and use the device anytime before the mentioned Expiry date. Can I connect an external sensor to the tempmate.®-GS2 T and TH model? No, presently there is no possibility to connect an external sensor to the tempmate.®-GS2 T and TH model. The tempmate.®-GS2 TE comes with an inbuilt external sensor which can be used for different applications. Can I remove the external sensor? The tempmate.®-GS2 TE comes with an external sensor and it is firmly fixed into the device and can not be... -
Page 10: Main Technical Specifications Tempmate.®-Gs2 T
9. Main Technical Specifications tempmate.®-GS2 9. Main Technical Specifications tempmate.®-GS2 Battery type All the variation available in Lithium and Non-Lithium option Battery type All the variation available in Lithium and Non-Lithium option Temperature Range -30°C to +70°C Temperature Range -30°C to +70°C Temperature Accuracy ±0.3°C (-10°C ~ 45°C) , ±0.5°C (Other) - Page 11 9. Main Technical Specifications tempmate.®-GS2 Battery type All the variation available in Lithium and Non-Lithium option Temperature Range -200°C to +100°C ±0.5°C (-10°C ~ 45°C) , ±1°C (Other) Temperature Accuracy Temperature Resolution 0.1°C Humidity Range Available with the Model Humidity Accuracy Available with the Model...
-
Page 12: Contact Information
CONTACT INFORMATION Do you have any questions? Please contact us - our experienced team will be happy to support you. sales@tempmate.com +49 7131 6354 0 V1.0-02/2022-DE · Technische Änderungen und Irrtümer vorbehalten... - Page 13 GmbH Edisonstr. 25 74076 Heilbronn, Germany Tel. +49-7131-6354-0 sales@tempmate.com www.tempmate.com...
