Uplift Desk FRM072 Quick Start Manual

Basic Display
Angled Keypad
FRM072
Package Contents
Keypad
Desk shown upside down
(2) #10x5/8'' Wood Screws (provided with desk and labeled H14)
Step 1 - Attach Keypad to Desktop
There are keypad attachment holes pre-drilled into UPLIFT desktops. The pre-drilled
holes are located on both the left and right sides so you can choose which side of the
desktop you'd like to attach the keypad. Note: Typically the desk is upside down when
assembling and attaching the keypad, so if this is the case the keypad will be on the
opposite side once the desk is flipped upright.
If your desktop doesn't have pre-drilled keypad holes, refer to the Optional Desktop
Drilling Instructions on the back page.
A. Align the keypad mounting holes with the pre-drilled holes in the desktop.
B. Being careful not to overtighten the screws to avoid stripping (especially if using a
drill to insert the screws), attach the keypad to the desktop with two #10x5/8" wood
screws provided with your desk and labeled H14.
