Uplift Desk FRM002 Instructions

Basic Angled Keypad
FRM002
Package Contents
Keypad
Desk shown upside down
(2) #10x5/8'' Wood Screws
Step 1 - Attach Keypad to Desktop
There are keypad attachment holes pre-drilled into UPLIFT desktops. The pre-
drilled holes are located on both the left and right sides so you can choose
which side of the desktop you'd like to attach the keypad. Note: Typically the
desk is upside down when assembling and attaching the keypad, so if this
is the case the keypad will be on the opposite side once the desk is flipped
upright.
If your desktop doesn't have pre-drilled keypad holes, refer to the
Desktop Drilling Instructions
A. Align the keypad mounting holes with the pre-drilled holes in the desktop.
B. Being careful not to overtighten the screws to avoid stripping (especially if
using a drill to insert the screws), attach the keypad to the desktop with two
#10x5/8" wood screws provided with your desk and labeled H14.
(provided with desk and labeled H14)
on the back page.
Optional
