What You Need
Gateway
External antenna
Not included - optional
3
Installation Conditions
Mounting
5
Mounting holes Ø4 mm
Connect
7
a
Power
Power supply
SD-card
Screws
Not included - optional
Temperature
-14° - 131°F
-10 – 55°C
Humidity
< 80% - non
condensing
2
Location
Place Gateway central and in line of sight
Access Requirements
4
60 mm
6
Configure Gateway
Internal Power Connection
7
b
(optional)
QG-WD-CR-Gateway 2124
Min. 50 mm
To acces
Micro SD card
35 mm
