Marten Coltrane Supreme 2 Owner's Manual

Hide thumbs Also See for Coltrane Supreme 2:
Table of Contents

Advertisement

Quick Links

Download this manual
Coltrane Supreme 2
OWNERS MANUAL
Serial number
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Coltrane Supreme 2 and is the answer not in the manual?

Questions and answers

Related Manuals for Marten Coltrane Supreme 2

Summary of Contents for Marten Coltrane Supreme 2

  • Page 1 Coltrane Supreme 2 OWNERS MANUAL Serial number...

  • Page 2: Table Of Contents

    Welcome Unpacking Contents How to unpack Initial setup Burning-in your loudspeakers Connecting your loudspeakers Choosing cables Wiring method Connections Room Acoustics Positioning Loudspeaker placement Rear and side walls Listening distance Focusing your loudspeakers Bass-adjustment Enclosed CD / USB Care of your loudspeakers Service Warranty Compliance...
  • Page 3 Welcome Thank you for choosing Coltrane Supreme 2. We’ve spent years engineering the sound of this loudspeaker to offer true musicality. Coltrane Supreme 2 presents a balance of intuitive design and technological expertise. The result is music as it should be, with vivid dynamics and a detailed sound stage.
  • Page 4 Unpacking Coltrane Supreme 2 is packed in 5 crates: 2 x base units 2 x top units 1 x mid/high units and accessories Please check the contents when you receive your loudspeakers. If the shipping box does not arrive in its original state, please contact your dealer immediately.

  • Page 5: How To Unpack

    Unpacking How to unpack 1. Roll the crates close to the intended listening place making sure you have the left and right cabinet components correctly positioned 2. Open each crate carefully to avoid damage to the contents 3. Turn the crate containing the right base unit on its side so the wheels face outwards (fig a) fig a 4. Remove the lid...
  • Page 6 Unpacking 8. Remove the foam from the lid of the accessory crate and place it on top of the base unit to protect it from damage from the heavy top unit (fig c) fig c 9. Lift the top unit out of its crate. (fig d) fig d 10. Place it on top of the foam on the base unit...
  • Page 7 Unpacking 11. Lift the top unit enough for the fifth person to pull the foam out and carefully lower the top unit onto the base unit (fig e) fig e 12. Using the larger allen key, loosely screw two M10 bolts including two washers into the holes inside the top unit (fig f) fig f...
  • Page 8 Unpacking 13. Adjust the top unit so that it’s aligned with the base unit and tighten the bolts inside the top unit 14. Screw the passive driver (accessory crate) for each speaker tower into place with 8 x black Torx screws per driver 15. Connect the jumpers tightly between the base and top unit.
  • Page 9 23.4 Lower the speaker with the jack 23.5 Repeat steps 23.1 - 23.4 for the left-side of the speaker 23.6 Adjust each Marten Isolator to ensure the speaker is level 23.7 Rotate each Marten Isolator so the Marten logo faces forwards 23.8 Tighten nuts to fix the position of each Marten Isolator...

  • Page 10: Initial Setup

    We recommended the use of the burn-in track (CD/USB) to speed up this process. Due to the high-tech materials used in the drivers, Coltrane Supreme 2 may sound a bit harsh at first. After approximately 50 hours of playing your loudspeakers will sound much better.

  • Page 11: Connecting Your Loudspeakers

    We recommend using an amplifier with sufficient power: typically a minimum of 60 watts. On the back of each Coltrane Supreme 2 cabinet, you will find two pairs of WBT Nextgen terminals that will accept any standard connections.

  • Page 12: Room Acoustics

    Room acoustics A good listening room has just the right amount of reflection and absorption. The performance of any loudspeaker depends on the speaker’s location in the room and the acoustic conditions in that part of the room. Furnishings, size and proportions all affect tonal balance, imaging and bass characteristics.

  • Page 13: Positioning

    Rear and side walls For the best results, Coltrane Supreme 2 should be no closer than 80cm (31.5”) from the rear wall. Marten loudspeakers should not be placed close to a side wall, as reflections from these can disturb the depth of the sound image.

  • Page 14: Enclosed Cd / Usb

    There are also three tracks purely for your listening pleasure; these were recorded in our studio in Gothenburg, Sweden. You can also download these files from marten.se/audiofiles 1. Burn-in track* 2. The Look Of Love** - Jeanette Lindström & Steve Dobrogosz 3. Blue In Green - Tommy Kotter...

  • Page 15: Service

    Refer all servicing to qualified service personnel. In the event your loudspeakers need to be serviced, please contact your dealer. They can decide whether the problem can be remedied locally or if they need to contact Marten for service. Warranty Marten provides a transferable, limited manufacturer’s warranty.

  • Page 16: Technical Specifications

    70mm solid laminated wood front, back, top and bottom: Matte Walnut, Matte Cherry, Matte Maple and Matte Oak Stands Mirror polished stainless steel with Marten Isolators Dimensions (WxHxD) 54 x 200 x 59cm (21.2 x 78.8 x 23.2”) Net weight...
