Summary of Contents for Marten Mingus Quintet 2 Statement Edition
- Page 1 Mingus Quintet 2 | Statement Edition OWNERS MANUAL Serial number...
-
Page 2: Table Of Contents
Welcome Unpacking Contents How to unpack Initial setup Burning-in your loudspeakers Connecting your loudspeakers Choosing cables Connections Room Acoustics Positioning Loudspeaker placement Rear and side walls Listening distance Focusing your loudspeakers Bass-adjustment Enclosed CD / USB Care of your loudspeakers Service Warranty Compliance... - Page 3 Welcome Thank you for choosing Mingus Quintet 2 Statement Edition (SE). We’ve spent years engineering the sound of this loudspeaker to offer true musicality. Mingus Quintet 2 SE presents a balance of intuitive design and technological expertise. The result is music as it should be, with vivid dynamics and a detailed sound stage.
-
Page 4: How To Unpack
8.1 Screw Isolators into the stand as far as possible without over- tightening 8.2 Place speaker upright 8.3 Adjust each Marten Isolator to ensure the speaker is level 8.4 Rotate each Marten Isolator so the Marten logo faces forwards 8.5 Tighten nuts to fix the position of each Marten Isolator... -
Page 5: Initial Setup
Initial setup Your newly unpacked Mingus Quintet 2 SE loudspeakers need considerable playing time in order to reach their optimum performance. We recommended the use of the burn-in track (CD/USB) to speed up this process. Due to the high-tech materials used in the drivers, Mingus Quintet 2 SE may sound a bit harsh at first. -
Page 6: Connecting Your Loudspeakers
Connecting your To get the most of Mingus Quintet 2 SE please loudspeakers consider the following when connecting them to your system. Choosing cables The cables you use can have a dramatic effect on the sound of your loudspeakers. Be sure to use the same brand, type and length of cable for each channel. -
Page 7: Room Acoustics
Room acoustics A good listening room has just the right amount of reflection and absorption. The performance of any loudspeaker depends on the speaker’s location in the room and the acoustic conditions in that part of the room. Furnishings, size and proportions all affect tonal balance, imaging and bass characteristics. -
Page 8: Positioning
Rear and side walls For the best results, Mingus Quintet 2 SE should be no closer than 60 cm (23.6”) from the rear wall. Marten loudspeakers should not be placed close to a side wall, as reflections from these can disturb the depth of the sound image. -
Page 9: Enclosed Cd / Usb
There are also three tracks purely for your listening pleasure; these were recorded in our studio in Gothenburg, Sweden. You can also download these files from marten.se/audiofiles 1. Burn-in track* 2. The Look Of Love** - Jeanette Lindström & Steve Dobrogosz 3. Blue In Green - Tommy Kotter... -
Page 10: Service
Refer all servicing to qualified service personnel. In the event your loudspeakers need to be serviced, please contact your dealer. They can decide whether the problem can be remedied locally or if they need to contact Marten for service. Warranty Marten provides a transferable, limited manufacturer’s warranty. -
Page 11: Technical Specifications
Cabinet 25-40 mm:s fibre laminate cabinet Solid wood top and bottom: Zebrano, Walnut or Oak Stands Mirror polished stainless steel with Marten Isolators Dimensions (WxHxD) 28 x 109 x 38 cm (11” x 42.9” x 15”) Net weight 63 kg (140 lbs)
