Marten FormFloor Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

FormFloor
Owners manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FormFloor and is the answer not in the manual?

Questions and answers

Related Manuals for Marten FormFloor

Summary of Contents for Marten FormFloor

  • Page 1 FormFloor Owners manual...

  • Page 2: Table Of Contents

    Owners manual Table of contents Introduction Marten Philosophy Unpacking Quick Setup Connecting the loudspeakers Choice of cable Connections Burn-in Room Acoustics Positioning Loudspeaker Placement Distance to back and side walls Focusing the Loudspeakers Toe-in Enclosed CD Care of Loudspeakers Service...

  • Page 3: Introduction

    Introduction Congratulations! You are now the proud owner of a pair of Marten loudspeakers. At the forefront of current designs, the FormFloor will reveal the full emotional range of music with vivid dynamics and detail. Properly installed, your FormFloor loudspeakers will give you many years of listening pleasure.To realize the highest sound quality from your loudspeakers, some important...

  • Page 4: Unpacking

    • Raise the speaker upright. Quick Setup Your FormFloor loudspeakers need quite a bit of playing time in order to reach their maximum performance. The use of the burn-in CD enclosed with the Miles loudspeakers is recommended to speed up this process. Follow these steps: 1.

  • Page 5: Connecting The Loudspeakers

    Connections At the bottom of your FormFloor, you will find one pair of terminals that will accept any standard connection but preferably banana plugs. Whatever type of connection you use, make sure that the contact is tight, and has a proper contact area.

  • Page 6: Burn-In

    24 hours before attempting to adjust the placement of the loudspeakers in your listening room. Due to the high-tech materials used in the drivers, the FormFloor will sound a bit harsh in the beginning, but after 50 hours of playing your loudspeakers will sound good.

  • Page 7: Positioning

    Other manufacturers usually recommend that their speakers be free-standing in the room to avoid reflection from the back wall. However, for good results, the FormFloor should be no closer than 40 cm (15.7 Inch) from the rear wall.

  • Page 8: Enclosed Cd

    © 200, PROPHONE RECORDS AB For more information of the CD “Feathers” please visit www.prophonerecords.se Marten loudspeakers require no special treatment apart from the kind of handling you Care of loudspeakers would apply to any high-tech product in your home.

  • Page 9: Warranty

    Warranty Exclusions Transportation damage, visible or hidden. Damage should be reported immediately to the transport company. Registration of the complaint should be sent to the Marten distributor. Scratches in paint, wood, metal, or carbon surfaces. Complaints should be made to the dealer within three days after the sale.

  • Page 10: Technical Specifications

    Owners manual Technical Specifications: FormFloor Frequency range: 36-40000 Hz +-3dB  Power rating: 150 W Sensitivity: 87 dB/w/m Impedance: 8 ohm (5.9 ohms minimum) Type: Ported system, port resonance 34 Hz Drive units: One 7î  ceramic-mid, 2.2î  ribbon-tweeter Crossover frequency: Second order 3000 Hz Terminals: Single wire binding posts Cabinet: 19 mm MDF Dimensions (WxHxD): 210 x 110 x 330 mm (8.3î  x 43.3î  x 13î ) Net weight: 17 kg/ ea. (37.7 lbs) Finishes: Piano lacquer: Maple, Cherry, Walnut, Black, White Marking of the î...
