CONNECTOR FOR OPTIONAL
ACCESSORIES
Example
Depending on the selected
equipment specification, both
sides of the auxiliary battery
feature connectors for OE and
authority equipment scopes.
Important connectors for
optional accessories:
LED 360° marker strobe 1
blue or red and blue/yellow
STOP signal indicator 2
Official-user scope 3 Special
output for various functions
including speed signal
Rear fog light 4
LED 360° marker strobe 5
blue or red and blue/yellow
Ask your BMW Motorrad
Partner for advice regard-
ing the special function config-
uration options.
For further information see:
bmw-motorrad-authorit-
ies.com
ATTENTION
Discharging the auxiliary
battery as a result of directly
connected consumers
Battery is deep-discharged;
this voids the guarantee
Connect additional equip-
ment to the connectors for
OA only.
259
