- Page 1 BMW MOTORRAD QUICK REFERENCE GUIDE 2021/22...
-
Page 2: Models Covered
Models Covered: In ascending capacity order G310 • C400 • C600/650 • G650 • F700/800 • F750/850/900 • S1000 • R1200/1250 • K1300 • K1600 • Please note: Rope style tyre plugs can be used as a temporary solution to get the customer mobile. -
Page 3: Securing Motorcycle For Transportation
Securing motorcycle for transportation Use masking tape or soft cloths suitably positioned to prevent scratching the parts of the motorcycle. ATTENTION Vehicle toppling to side Risk of damage to parts if vehicle topples Make sure that the vehicle is secured so that it cannot topple •... - Page 4 G310 Remove the seat using the ignition key. • • Begin by connecting one end of the red jump lead to the positive terminal of the • discharged battery and the other end to the positive terminal of the donor battery.
- Page 5 C400 Place the Scooter on its stand and remove the battery cover. Remove screws • Lift battery cover at the edges on both sides and while doing so, unclip mounting • clips from legshield Remove battery cover • Removing the battery holder Press locks •...
- Page 6 C400 Continued.. • Press locks to the centre and fold battery holder to the top. • Unhook battery holder at the rear on the battery compartment and remove. with Keyless Ride (0193) Press locks to the centre and fold battery holder to the top.
- Page 7 C600/650 Place the MaxiScooter on its stand. • Remove the right side panel as follows: • Open stowage-compartment lid (1). • Remove screws (2). • Remove screw (1) and remove top right side panel (2) , noting the locators (arrows) . •...
- Page 8 C600/650 Continued.. Disconnect the jump lead from the negative terminal and the ground point first, then • disconnect the second jump lead from the positive terminal and the battery connection point. • No keyless start function available on this model G650 Make sure the ground is level and firm and place the motorcycle on its stand.
- Page 9 G650 Continued.. Remove the centre trim panel. Remove the following components: • Oil-tank cap (1) • Screws (2) • Screws (3) • Centre trim panel (4) • Install oil-tank cap (1) Disengage large heat shield from the battery (1) • Push back cover 1 of the battery's positive terminal.
- Page 10 G650 Continued.. Start the engine of the vehicle with the discharged battery in the usual way; if the • engine does not start, wait a few minutes before repeating the attempt in order to protect the starter motor and the donor battery. Disconnect jump leads first from the negative terminal, then from the positive •...
- Page 11 F700/800 Continued.. Removing centre trim panel. • Remove screws (1) with plastic washers (2) . • Remove screws (3) . • Disengage centre trim panel (4) . • Begin by connecting one end of the red jump lead to the positive terminal of the •...
- Page 12 F750/850/900 Removing seat using the ignition key. • Press in the lock and flip open positive terminal cover. • Begin by connecting one end of the red jump lead to the positive terminal of the • discharged battery and the other end to the positive terminal of the donor battery. Then connect one end of the black jump lead to the negative terminal of the donor •...
- Page 13 F750/850/900 Continued.. Keyless start aerial location: (2) Under seat S1000 up to 12/2018 Remove the front seat. • Push front seat (1) to one side by applying pressure to the seat surface as • shown (arrows) . Remove screws (2) . •...
- Page 14 S1000 up to 12/2018 Continued.. • Begin by connecting one end of the red jump lead to the positive terminal of the discharged battery and the other end to the positive terminal of the donor battery. Then connect one end of the black jump lead to the negative terminal of the donor •...
- Page 15 S1000 01/2019 onwards Remove the front seat. • Push rider's seat (1) at the seat cushion surface (arrow) forward. • Remove bolt (2) . • Lift rider's seat (1) at rear and remove • Begin by connecting one end of the red jump lead to the positive terminal of the •...
- Page 16 S1000 01/2019 onwards Continued.. Keyless start antenna location...
- Page 17 R1200/1250 2013 onwards Remove the battery cover on right hand side • Remove protective cap • Use the red jump lead to connect the positive battery connection point of the drained • battery to the positive terminal of the donor battery. Then connect one end of the black jump lead to the negative terminal of the donor •...
- Page 18 R1200/1250 2013 onwards continued.. Keyless start antenna location: Up under rear mudguard (view from underneath) (view from above) K1300 Removing battery-compartment cover on top of fuel tank •...
- Page 19 K1300 Continued.. Begin by connecting one end of the red jump lead to the positive terminal of the • discharged battery and the other end to the positive terminal of the donor battery. Then connect one end of the black jump lead to the negative terminal of the donor •...
- Page 20 K1600 Continued.. Location of ring antenna...
