Kenwood KDW24FI/B User Manual

Domestic dishwasher
Hide thumbs


Domestic Dishwasher



  Summary of Contents for Kenwood KDW24FI/B

  • Page 1 Domestic Dishwasher KDW24FI/B Code:0120504283...
  • Page 2: Safety Is A Good Habit To Get Into

    - After removing the packing, check to make sure that the appli- ance is not damaged. If in doubt, contact a qualified professional. - The dishwasher must only be used by adults for the washing of household dishes and cooking utensils.
  • Page 3: Close-Up View (Interior)

    Close-up View (Interior) Upper Rack Top Spray Arm Rack Height Adjustor Lower Rack Washing Filter Technical characteristics Width Depth Height Capacity Mains water pressure Power voltage Total absorber power Salt Container Cap Bottom Spray Arm Detergent and Rinse Aid Dispenser Turbo Dry-fan Third Sprayer 12 standard place settings...
  • Page 4: Installation

    Levelling the Appliance Once the appliance is positioned, adjust the feet (screwing them in or out) to adjust the dishwasher, making it level. In any case, the appliance should not be inclined more than 2˚. If the appli- ance is level, it will help ensure proper performance.
  • Page 5 Remove the small plastic plugs that cover the holes on the inside of the dishwasher door and fasten the panel in place with the screws provided (Fig.
  • Page 6: Adjusting Door Springs

    1.Install the continuous base moulding , following the manufacturer’s instructions . 2. Slowly open the door of the dishwasher to check to see if the door strikes or rubs against the base moulding. 3. If so, rest the bottom edge of the panel on the base moulding and mark the part to be cut.
  • Page 7 Assembly Instructions for Integrated Dishwasher...
  • Page 8 Assembly Instructions for Integrated Dishwasher...
  • Page 9: Loading The Dishwasher

    Loading the Dishwasher Before placing the dishes in the dishwasher, remove the larger food debris to prevent the filter from becoming clogged, which results in reduced performance. If the pots and pans have baked-on food that is extremely hard to remove, we recommend that they be allowed to soak before they are washed.
  • Page 10: Starting The Appliance

    Setting The Start Delay Time Open the door of the dishwasher partially. If the "C" button is pressed (see, Close-up View" Control Panel"). The start time for the wash cycle can be delayed for 2,4 or 6 hours.
  • Page 11 Salt Salt The hardness of the water varies from place to place. If hard water is used in the dishwasher, deposits will form on the dishes and utensils. The appliance is equipped with a special softener that uses a salt specifically designed to eliminate lime and minerals from the water.
  • Page 12: Detergent And Rinse Aid

    Detergent and Rinse Aid Detergent Detergent specifically intended for use with dishwashers must be used. The dispenser must be refilled before the start of each wash cycle following the instructions provided in the "Wash Cycle Table." The detergent dispenser is located on the inside panel the door.
  • Page 13: Wash Cycle Table

    Wash Cycle Table Cycle Cycle Selection Information Very dirty dishes, pots and pans. (Not to be used with deli- cate items) Heavy Duty Normal dirty dishes, pots and pans. Stan- dard daily cycle. Normal Wash (IEC-EN50242) Normal dirty dishes, pots and pans without dried on residue.
  • Page 14: Energy Saving Tips

    Energy Saving Tips -It is important to try and run the dishwasher when it is fully loaded in order to save on energy. In order to prevent odors from forming and food from caking onto the dishes, you can run the hold cycle.
  • Page 15: Troubleshooting

    Troubleshooting It may occur that the dishwasher does not function or does not function properly. Before calling for assistance, Iet us see what can be done first: have you forgotten to press one of the buttons or to perform an essential operation?
  • Page 16 Diagram The symbol on the product or on its packaging indicates that this product may not be treated as household waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product.
