USER GUIDE
Grille Installation
REMOVING AND INSTALLING GRILLE
WARNING
!
Disconnect electric power to the unit before
removing the grille.
When using the unit, the grille must be installed.
WARNING
!
Do NOT touch the condenser fins. The condenser
fins are SHARP and can be easily damaged.
Removing the grille
1.
Disconnect power to the unit.
2.
Remove the two screws.
3.
Remove grille from unit.
Installing the grille
1.
Align cabinet and grille holes and secure, but do not
over tighten grille screws.
2.
Reconnect power to the unit.
Condenser
Grille Installation
Screws
13
u-line.com
