  • Page 1 670 Series Bursters OPERATOR MANUAL SECOND EDITION...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS DESCRIPTION Function Model Numbers Accessory Model Numbers Specifications INSTALLATION Unpacking and Set-up OPERATION General Safety Control/Feature & Function Form Set-up Procedure With And Without Tractors Form Set-up Procedure With Imprinter Normal Loading Operating Hints Troubleshooting Vertical Folder Merger/Burster...

  • Page 5: Function

    DESCRIPTION SLITTER FUNCTION Slitter enables the operator to remove trim at same speed forms are being burst. BURSTER IMPRINTER Moore 676/680 Burster bursts (breaks apart) single Imprinter unit enables operator to print and multi-part continuous forms and feeds them signatures at same speed forms are being sequentially onto the stacker.

  • Page 6: Specifications

    SPECIFICATIONS FORM SPECIFICATIONS Variable Speed 30-500 ft/mm (4.6-154 m/mm) Capacity 1-8 pan forms Maximum Depth 17 inches (43 cm) Minimum depth 2 3/4 inches (7cm) Maximum Width Before Slitting 19 1/4 inches (49cm) Maximum Width After Slitting 17 inches (43cm) Form Types Carbon or Carbonless Form Weights...

  • Page 7: General

    OPERATION SAFETY GENERAL This section describes built-in safety devices to protect operator, but these devices do not replace This section describes controls, features, and normal good operator practices. operating procedures for this identifies and describes -Do not touch any moving parts control devices of machine.
  • Page 8 WEDGER EDGE SLITTERS SLITTER 8 PIN TRACTOR OP. ADJUSTMENT SCREW RIGHT PAPER FIG. 5 GUIDE 8 PIN TRACTOR DR. CENTER PAPER GUIDE OPTIONAL LEFT PAPER GUIDE URGE ROLLER URGE ROLLER MAGNETIC STOP STACKER GRILL FORM LENGTH SCALE STACKER ADJUSTMENT STACKER WHEEL RACK ASSEMBLY FIG.

  • Page 9: Control/Feature & Function

    CONTROLS AND FEATURES Refer to Figures on previous page for locations of controls and indicators below. CONTROL / FEATURE FUNCTION On/Off Switch Controls power to Burster. Indicator light lets operator know that power is on. Start Button Starts Burster Stop Button Stops Burster Machine Speed Thumb Wheel Varies Burster Speed...

  • Page 10: Form Set-Up Procedure With And Without Tractors

    FORM SET-UP PROCEDURE WITH AND WITHOUT TRACTORS 1.Turn on machine. Measure form length using form length scale on sequence stacker. (Fig. 6) 2- Press form length switch to align alignment mark with form length on form length scale. (Fig. 4) 3.
  • Page 11 Tear adjustable accommodate characteristics of various forms. To adjust height bar must be pushed to compress spring and lift out. Rotate 180 degrees (turned over) and replaced making sure that square end of bar locks into brackets. (Fig. 9, shown in HIGH position) 15.

  • Page 13: Form Set-Up Procedure With Imprinter

    FORM SET-UP PROCEDURES 10. Move timing collar so that mark on collar aligns with mark on side frame. Tighten setscrews. (Fig. 11) WITH IMPRINTER 11. Remove forms from tractors. Install signature patches on imprint cylinder. (Fig. 12) NOTE: It is recommended that numbered forms or checks fed into imprinter should be last form first, right 12.

  • Page 14: Operating Hints

    6. Set up tear bar as before. (Fig. 9) bar, vary form length setting up to 1/2” ahead or behind actual form size setting, 7. Set up Stacker Wheel Assembly as and/or put tear bar in low position. before. (Fig. 6) 5.
  • Page 15 PROBLEM CAUSE SYMPTOM Burster will not run. Power light on. Safety cover not closed. Jam detection grill not activating switch. Last form switch activated (no forms in tractors). Faulty interlock switch. Faulty run switch. Faulty stop switch. Faulty last form switch. Faulty jam detection switch.
  • Page 16 SYMPTOM PROBABLE CAUSE Stacker does not run but Burster does. Broken belt Loose stacker drive gear/tbroken drive pin. Faulty stacker motor. Faulty stacker motor speed control Faulty stacker switch. Rollers don’t rotate/machine runs. Broken drive belt, Loose pulley. Won’t burst properly. Incorrect roller tension.

  • Page 17: Vertical Folder

    VERTICAL FOLDER SET-UP FUNCTION Vertical folder provides means for folding two-wide forms side-to-side prior to their entry into burster. SET-UP PROCEDURE 1. Place forms on floor at infeed end of burster. 2. Thread forms through folding bale. (Fig. 13) If you are going to imprint, arrange forms so that side to be imprinted is facing down.

  • Page 18: Merger/Burster

    MERGER-BURSTER SET-UP FUNCTION FD589 Merger/Burster Center slits continuous forms and allows forms to be merged into burster for slitting, imprinting, bursting and stacking. SET-UP PROCEDURE 1. Set forms in tractor. (see page 6, Fig. 8) 2. Adjust center slitter to the middle of the forms.
