- Page 1 MSS129900298046 MSS129900298047 MSS129900298048 ASSEMBLY AND CARE GUIDE MAINSTAYS FOREST HILLS 3 PIECE PATIO BISTRO SET Need Assistance? Contact our toll free Customer Service Hotline at: (877) 980-6928 -Monday through Friday 7:30am until 3:30pm PST-...
-
Page 2: Warranty
MSS129900298046 MSS129900298047 MSS129900298048 Warranty 2 YEAR LIMITED WARRANTY WHAT IS COVERED We warrant the frame to be free of manufacturing defects to the original purchaser for two years. WHAT IS NOT COVERED This warranty does not cover commercial use, hardware, acts of nature, fire, freezing, and abusive use. - Page 3 MSS129900298046 MSS129900298047 MSS129900298048 A. Read instructions thoroughly. Acquaint yourself with the inventory of parts and the accompanying drawings to ensure safe and proper assembly. B. Lay out all of the parts on a flat surface and identify them using the table below. C.
- Page 4 MSS129900298046 MSS129900298047 MSS129900298048 Assembly Single chair Note: Do not tighten bolts until all parts are connected Step 1: Attach seat(C),leg connector bracket 1(D) to the right armrest(B) using two bolts(AA),one bolt(BB) at front and one bolt(CC) at the rear. Step 2: Attach assembled seat(C) with right armrest(B) and leg connector bracket1(D) to left armrest(A) using two bolts(AA), one bolt(BB) at front and one bolt(CC) at the rear.
-
Page 5: Maintenance
MSS129900298046 MSS129900298047 MSS129900298048 Assembly Table Note: Do not tighten bolts until all parts are connected. You will need a Phillips Screwdriver. Step 1: Insert leg(Y) into the joint on table frame(X) and tighten screws(EE). Step 2: Assemble leg fixture bracket(Z) to legs(Y) using bolts(DD) and ratchet tool(GG). Step 1.
