Erskine Attachments 900549 Operator's Manual

Mini stump grinder for mini skid steer loaders and mini track loaders

Advertisement

Quick Links

Mini Stump Grinder
For
Mini Skid Steer Loaders
And
Mini Track Loaders
Operator's Manual
Set-Up Assembly
Maintenance
Parts Information
Read this Manual Before Use

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 900549 and is the answer not in the manual?

Questions and answers

Summary of Contents for Erskine Attachments 900549

  • Page 1 Mini Stump Grinder Mini Skid Steer Loaders Mini Track Loaders Operator’s Manual Set-Up Assembly Maintenance Parts Information Read this Manual Before Use...
  • Page 2: Table Of Contents

    Serial Number………….._____________ YOUR ATTACHMENTS DEALER ADDRESS: PHONE: CONTACT: NOTE: Erskine Attachments LLC reserves the right to make improvements in design or changes in specifications at any time without notice and without incurring any obligations to install them on units previously sold.
  • Page 3: Safety

    Indicates potentially Erskine Attachments LLC cannot anticipate every hazardous situation which, if not avoided, possible circumstance that might involve potential will result in death or serious injury.
  • Page 4  Avoid the hazard by relieving the  Do not modify equipment or add attachments that pressure before disconnecting are not approved by Erskine Attachments LLC. hydraulic lines.   Use adequate safety warning lights and devices Use a piece of paper or cardboard, NOT BODY as required by local regulations.
  • Page 5: Serial Number/Decal Location

    SERIAL NUMBER AND SAFETY DECAL LOCATIONS Serial Number Location: It is important to refer to the serial number of the attachment when making repairs or ordering parts. Early or later models (identification made by serial number) may use different parts, or it may be necessary to use different procedures in doing a specific operation.
  • Page 6 The locations of the safety decals are shown. If these decals are missing, damaged, or painted over they Mini Brand Decal must be replaced. Call Erskine Attachments LLC (218- Location: On either side of the cutter shield 435-4045) for replacement decals.
  • Page 7: Users Mounting Instructions

    USER’S INSTRUCTIONS FOR MOUNTING THE MINI STUMP GRINDER After uncrating the attachment, use the following procedure to mount the attachment to the loader. Coupler wedges or pins must extend through the holes in the attachment mounting plate. Levers must be fully down and locked. Failure to secure wedges or pins can allow attachment to come off and cause injury or death.
  • Page 8 USER’S INSTRUCTIONS FOR MOUNTING THE MINI STUMP GRINDER Attaching Hydraulics: 1. Connect the hydraulic quick couplers from the attachment to the loader. IMPORTANT: Make sure the quick couplers are fully engaged. If the quick couplers do not fully engage, check to see that the couplers are the same size and brand.
  • Page 9: Operating Instructions

    OPERATING INSTRUCTIONS Hydraulic Controls All functions can be activated by the steering lever switches on the loader (if loader is equipped), or with the pistol grip control harness. NOTE: Your loader must have the attachment control kit installed to make use of the lever switches.
  • Page 10 OPERATING INSTRUCTIONS Operation 1. With the operator in the operating position, start the engine. 2. For proper operation of the attachment, try to approach the stump from a position that will allow the loader to sit as level as possible. Remember to position the grinder so that wood chips and debris will be thrown in a safe direction.
  • Page 11 OPERATING INSTRUCTIONS 7. Once the attachment has started cutting, engage the control to start the grinder arm Direction of Loader swinging. travel between cuts NOTE: The arm senses the difficulty of the cut and will automatically adjust the travel speed. 1 to 2 inches 8.
  • Page 12 _____________________ROUTINE MAINTENANCE________________ Lower the stump grinder to rest on the ground, shut down the engine, relieve the hydraulic pressure to the attachment, wait for all motion to stop, and set park brake before leaving the operator’s position to perform service of any kind. It is the operator’s responsibility to make daily inspections of the loader and attachment for damage, loose bolts, fluid leaks, or anything else that could cause a potential service or safety problem.
  • Page 13: Routine Maintenance

    ROUTINE MAINTENANCE LUBRICATION (continued) Grease the swing cylinder bushings after every 8 hours of operation. Grease the lift cylinder pins after every 8 hours of operation. GEARBOX OIL LEVEL Check the oil level in the gearbox at least once per year. The gearbox should be approximately 1/3 full.
  • Page 14 ROUTINE MAINTENANCE TEETH REMOVAL AND REPLACEMENT 1. With the attachment on a flat level surface, lift up the swing arm (using a jack or a hoist) and brace with jack stands or blocks in a lifted position. Make sure the mounting plate stays flat on the ground.
  • Page 15: Set Up Assembly

    SET UP ASSEMBLY OF THE GENERIC CONTROL HANDLE HARNESS NOTE: If the loader is equipped with an Attachment Control package, the appropriate harness should be installed from the factory. Mounting the generic control handle wire harness will vary from loader to loader. Use these instructions as a general guide.
  • Page 16: Parts Information

    PARTS INFORMATION ITEM PART NO. DESCRIPTION STOCK NO. 400600 GRINDER MOUNT MINI W/A 400601 FRAME SWING MINI SG W/A 400602 FRAME ARM MINI SG W/A 400604 WHEEL GRINDER 16 ASSM 400605 SHIELD MINI STUMP GRINDER W/A 311657 SHIELD RUBBER 310198 PIN 1.00 X 7.63 W/A 311605 PIN 1.25 X 6.75 W/A...
  • Page 17 PARTS INFORMATION...
  • Page 18 PARTS INFORMATION ITEM PART NO. DESCRIPTION STOCK NO. 311659 VALVE ASSM STUMP GRINDER 400074 CYLINDER 2 X 4 W/BUSHINGS 400015 CYLINDER 2.5 X 6 W/BUSHINGS 300694 MOTOR HYD 6.2 13071 BOLT HEX 5/16 X 4-1/2 NC GR 5 37211 NUT HEX LOCK 5/16 NC 320089 ADPT ELB 8MB-6MJ-90...
  • Page 19 PARTS INFORMATION 315128 PKG HRN - FUNC CONTROL 315110 PISTOL GRIP ASSM ALL 315126 HRN LOADER GENERIC 300247 BRKT WR HRN GEN MINI PNT 315127 HRN BLOWER GENERIC OPTIONAL WIRE HARNESSES (NOT SHOWN) Bobcat® Loaders 315090 HRN 14 PIN COMMON Case®...
  • Page 20: General Specifications

    GENERAL SPECIFICATIONS Model Drive System Hydraulic with Gearbox Hydraulic Requirements 7 to 14 GPM 36” Maximum Cutting Diameter 6” below ground Maximum Cutting Depth Cutting Arc 66° Cutting Wheel Diameter Approx. 18” Cutting Wheel Speed 500 to 1000 RPM Operating Weight 395# All dimensions are in INCHES.
  • Page 21: Notes

    NOTES ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________...
  • Page 22 NOTES ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________...
  • Page 23: Warranty

    Erskine Attachments, LLC to improve its products whenever it is possible and practical to do so. Erskine Attachments, LLC reserves the right to make changes and or add improvements at any time without incurring any obligation to make such changes or add such improvements to products previously sold.
  • Page 24 P/N 400609 Date Printed: 11/12/2018 Erskine Attachments LLC Printed in U.S.A.
