Page 1: Operation Manual
FLOOR UNIT OPERATION MANUAL AZ092AOBHA AU092ACBHA (HFU-09H03(B)/R1) AZ122AOBHA AU122ADBHA (HFU-12H03(B)/R1) AZ142AOBHA AU142ADBHA (HFU-14H03(B)/R1) Please read this operation manual before using the air conditioner. - Page 3 Cautions Do not obstruct or cover the ventilation grille of the air conditioner. Do not put fingers or any other things into the inlet/outlet and swing louver. Do not allow children to play with the air conditioner. In no case should children be allowed to sit on the outdoor unit.
-
Page 6: Parts And Functions
Parts and Functions Indoor unit Outdoor unit HFU-09H03(B)/R1 HFU-12H03(B)/R1 HFU-14H03(B)/R1 1.OUTLET 2.CONTROL PANEL 3.INLET 4.FILTER ( inside ) 5.OUTLET... -
Page 24: Installation Manual Of Room Air Conditioner
Installation Manual of Room Air Conditioner Figure .1 Figure .2 Figure .3 Installation of outdoor unit selection of installation place Place strong enough to support the unit and will not cause vibration and noise. Place where discharged wind and noise doesnt cause a nuisance to the neighbors. - Page 27 Installation Manual of Room Air Conditioner 3. Piping connection Connecting method Apply refrigerant oil at half union and flare nut. To bent a pipe, give the roundness as large as possible not to crash the pipe. When connecting pipe, hold the pipe center to center then screw nut on by hand, refer to Fig.
- Page 29 When connecting indoor and outdoor wire, check the number on indoor and outdoor terminal blocks. Terminals of same number and same color shall be connected by the same wire. Incorrect wiring may damage air conditioner’s control or cause operation failure. +1X0.75mm +1X0.75mm...
