DUCT TYPE AIR CONDITIONER
INSTRUCTION
MANUAL
AD242AMNAA
AU242ANNAA
(HDU-24CA03/M(R1))
AD282AMMAA
AU282ANMAA
(HDU-28C03/M)
AD282AMACA
AU282ANAFA
(HDU-28H03/M)
AD28NAMBAA
AU28NANBAA
(HDU-28HA03/M(R1))
AD28NAMNAA
AU28NANNAA
(HDU-28CA03/M(R1))
AD362AMBAA
AU362APBAA
(HDU-36HC03/M(R1))
****
No. 0010570247
G
AD36NAMNAA
AU36NAPNAA
(HDU-36CA03/M(R1))
AD36NAMBAA
AU36NAPBAA
(HDU-36HA03/M(R1))
AD42NAMMAA
AU42NAPMAA
(HDU-42C03/M)
AD42NAMACA
AU42NAPAGA
(HDU-42H03/M)
AD42NAMBAA
AU42NAPBAA
(HDU-42HA03/M(R1))
AD42NAMNAA
AU42NAPNAA
(HDU-42CA03/M(R1))
