- Page 1 OWNER'S MANUAL XL-600 POWER AMPLIFIER A Division of Rockford Corporation 613 South Rockford Drive Tempe, Arizona 85281 602 - 967 - 3565...
-
Page 2: Specifications
SPECIFICATIONS POWER RATING: Less than 0.08% THD at any power level up to 305 watts per channel into 8 ohms at any frequency from 20 - 20 kHz with both channels driven. CONTINUOUS POWER OUTPUT: 450 watts per channel into 4 ohms at less than 0.1% THD, 20 - 20 kHz. 900 watts in mono into 8 ohms at less than 0.1% THD, 20 - 20 kHz. -
Page 3: Installation
INSTALLATION The gloss black insert on the faceplate of your new Hafler Equipment has been packaged with a removable protec- tive coating. Please peel off this coating following installa- tion. -
Page 4: Input Connections
The XL-600 is normally wired for use on 120 Volt 60 Hz power lines. If your line (mains) voltage is different, you will require the optional export multi-voltage transformer, which accommodates voltages from 100 to 240 VAC, at 50-60 Hz. -
Page 5: Output Connections
Output Connections To preserve the high damping factor of the XL-600, and to minimize power loss, the use of at least wire is recommended, especially for speakers of less than 8 ohms impedance, or for wire runs of 15 feet or more. -
Page 6: Operation
The red pilot bar will light a few seconds before operation is auto- matically restored if the XL-600 has cooled down and the power switch is left on. check for inadequate ventilation, continued excessive input signal, or a severely reduced load impedance. -
Page 7: Initial System Check Out
The fuse holders on the back panel provide a measure of protection against excessive power output to the speakers. They are not intended to protect the amplifier. The XL-600 is supplied with 5 ampere fast blow fuses installed. This value will afford minimal protection for most speakers. A spare pair of 10 ampere fast blow fuses has been included, for testing purposes, or high power applications. - Page 8 It will already be exceedingly low on the XL-600 as you receive it because each amplifier chan- nel has been factory adjusted using a typical loudspeaker load. But when the XL-600 is connected to your own speakers, careful readjustment by a technician may yield some slight improvement.
-
Page 9: Performing The Adjustments
A pair of headphones which have a high degree of isolation from outside sounds may simplify your test listening, but are not essential. If a very sensitive meter is available, it can replace the listening requirement, but your ears are better than conventional meters. - Page 10 The test procedure is as follows: 1. First use the right channel of the XL-600 as the driving amplifier and the left channel as the test amplifier. Turn off the amplifier each time before making any change in connections, and before removing the cover.
-
Page 11: In Case Of Difficulty
DC voltage present at the output. Minor turn-on thumps or clicks are normal and should be ignored. Since the XL-600 is direct coupled, any DC present at the input to the amplifier will be passed onto the output. - Page 12 The Hafler XL-600 is warranted for 3 years from date of purchase, including parts, labor, and return shipping costs from the factory to the owner within the Continental USA.
