Thank you for choosing Genesis Custom Window Shades. With proper installation
and care, your new shades will provide many years of beauty and performance.
Tools and Fasteners Needed
Power Drill, 1/4" Driver and drill bits
Tape Measure
Flat blade Screwdriver
Phillips Screwdriver
Pencil
Level
The inside depth or projection of outside or ceiling brackets required depends on the diameter of the
shade itself and installation obstructions that must be cleared. T-Handles can replace window cranks on
some installations.
Inside Mount
Standard Roll
Material comes off the
backside of the roller.
Reverse Roll
Material comes off the
front of the roller.
Reverse Inside
Reverse Inside
Reverse Inside
Mount
Mount
Mount
Pin
Pin
Pin
C
ustom
r
pring
oller
Install brackets against a flat surface with the screws provided. Use
wall anchors (not provided) if installing into drywall.
Make sure the brackets are mounted level or the shade will roll
crooked.
Insert pin on right side of shade into the bracket.
Then insert spear on spring end on the left side of shade into the op-
posite bracket.
Reverse brackets will be supplied with shades ordered as such.
After brackets are installed, insert pin on left side of shade into the
bracket.
Then insert spear on spring end on the right side of shade into the
opposite bracket.
Spear
Spear
Spear
Pin
W
s
indoW
hades
i
i
nstallation
nstruCtions
Mounting Surface
Wood
Drywall, Plaster
Metal
Outside Mount
Reverse Outside
Mount
Spear
Fastener
#6 Hex Head
Provided
Wall Anchors
Not Provided
Sheet Metal
Not Provided
Ceiling Mount
Reverse Ceiling
Mount
Pin
Spear
