INSTRUCTIONS FOR USE
SERVICE MANUAL
To avoid personal injury or damage to bed,
please read all sections pertaining to
the bed model before use.
GF Health Products, Inc. - www.grahamfield.com
ETL/UL/CSA APPROVED
Zenith Series Service Manual 999-0831-190C DEC. 2013
ZENITH
SERIES
UL 60601-1
IEC 60601-2-38
CSA 22.2 601.1
