INSTRUCTIONS FOR USE
SERVICE MANUAL
To avoid personal injury or damage to bed,
please read all sections pertaining to
the bed model before use.
GF Health Products, Inc. - www.grahamfield.com
ETL/UL/CSA APPROVED
Zenith Series Service Manual 999-0856-190C - DEC. 2013
ZENITH
SERIES
UL 60601-1
IEC 60601-2-38
CSA 22.2 601.1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ZENITH Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Basic American ZENITH Series

Summary of Contents for Basic American ZENITH Series

  • Page 1 To avoid personal injury or damage to bed, please read all sections pertaining to the bed model before use. ETL/UL/CSA APPROVED UL 60601-1 IEC 60601-2-38 CSA 22.2 601.1 Zenith Series Service Manual 999-0856-190C - DEC. 2013 GF Health Products, Inc. - www.grahamfield.com...
  • Page 2 This service manual covers the following Zenith Models: 76” & 80” Full Electric with Low Roll Only & Grid Decks = ZG58174 Basic American Medical Products 336 Trowbridge Drive Fond du Lac, WI 54937 For Zenith 5000 Bed Service Parts...

  • Page 3: Table Of Contents

    ZENITH SERIES TABLE OF CONTENTS IMPORTANT INFORMATION REGARDING YOUR BED Safety & Warnings ....... . 4 - 5 Entrapment/Compliance .

  • Page 4: Safety & Warnings

    ZENITH SERIES IMPORTANT SAFETY AND WARNING INFORMATION This product is a variable height, adjustable mattress Beds manufactured by Basic American Medical Products platform, which will provide comfort and convenience are designed for use within an institutional healthcare for residents/patients and caregivers in long term environment (i.e.

  • Page 5: Entrapment/Compliance

    (HBSW), formed in 1999. GF Health Products, Inc’s Long- for reducing the risk of bed entrapment: “Hospital Term Care Bed division: Basic American Medical Products, is Bed System Dimensional and Assessment Guidance an HBSW charter member. As a result of our commitment to to Reduce Entrapment”.

  • Page 6: Recommended Maintenance

    ZENITH SERIES Regular maintenance of the Long Term Bed is necessary to ensure continuing proper and safe operation. Please read and observe the following recommended maintenance schedule. RECOMMENDED INSPECTION PERIODS Inspect Every Every ITEM on Receipt 3 Months 6 Months Maintenance Inspection of All Components at Receipt of Shipment Make sure all parts/components are included (Please see “Unpacking The Bed”).

  • Page 7: Warning Labels And Environmental Specifications

    ZENITH SERIES The following warning labels have been placed on the bed to help protect you and the bed from damage. Please do not remove any labels from the bed. WARNING! CAUTION DO NOT LOWER BED WHEN OBJECTS ARE THIS BED IS SUITABLE FOR USE ONLY WITH BENEATH BED.

  • Page 8: Section A - Bed Set-Up

    ZENITH SERIES SECTION A ZENITH 5000 Bed Set-up Instructions GF Health Products, Inc. - www.grahamfield.com Zenith 5000 Service Manual 999-0856-190C - DEC. 2013...

  • Page 9: Unpacking Your Bed

    ZENITH SERIES UNPACKING THE BED DISCARD KEEP 1. Cable Tie on Bundle 9. Wireform Wallsaver • Make sure all parts/components are included. 2. Large Foam Block 10. Two Mattress Retainers • Check all bed components for obvious damage. 3. Large Cable Tie - CUT 11.

  • Page 10: Headboard And Footboard Installation

    ZENITH SERIES HEAD- AND FOOTBOARD ASSEMBLY 2. FOOTBOARD INSTALLATION 1. HEADBOARD INSTALLATION • The footboard comes with four pre-installed • The headboard comes with four pre-installed inserts - consider this the outside of the board. inserts - consider this the inside of the board.

  • Page 11: Standard Mattress Retainer Installation

    ZENITH SERIES STANDARD MATTRESS RETAINER INSTALLATION (Using 2 Retainers 999-0844-124) 1. Determine if you need to position your bed in an 80” or 76” 4. On the head end, carefully squeeze the Mattress Retainer ends configuration (80” outside holes; 76” inside holes - see inward, toward the center of the retainer, and insert the ends Closeups A &...

  • Page 12: Standard Wallsaver Installation

    ZENITH SERIES STANDARD WIREFORM WALLSAVER INSTALLATION WALLSAVER ASSEMBLY 1. Position the Wireform Wallsaver (Part 999-0856-180) with bent end facing upward and tab ends facing inward as shown at right. 2. Determine the position desired (See bottom of page). 3. Gently squeeze the tab ends of the wallsaver...

  • Page 13: Plugging In Your Optional Staff/Nurse Control

    ZENITH SERIES PLUGGING IN THE OPTIONAL FOOTBOARD NURSE/STAFF CONTROL STEP 1 - ATTACHING THE FOOTBOARD You can order an optional Staff Control for the Zenith 5000 which includes a Staff Control Assembly and Shroud Cover pre-installed to the Footboard at the manufacturing facility.

  • Page 14: Pendant/Hand Controller Operation

    ZENITH SERIES ZENITH 5000 PENDANT/HAND CONTROLLER OPERATION The hand controller comes standard on the Zenith 5000 series and can be plugged into either side of the bed. The plug features a lock-on cap. A pendant holster for attaching to optional assist devices is also provided.

  • Page 15: Optional Staff/Nurse Control Operation

    ZENITH SERIES BED OPERATIONS FOR OPTIONAL NURSE/STAFF CONTROL PANEL When you purchase your boards directly from our company, you have the option of ordering a Nurse/Staff Control Assembly which would come pre-installed into the footboard at the manufacturing facility. Operations are listed below.

  • Page 16: Stationary/Low Roll Positioning

    ZENITH SERIES BED OPERATIONS - STATIONARY/LOW ROLL POSITIONING The Zenith 5000 is sold as a “Low Roll” bed giving the user the option of placing it in a stationary (non-moving) position or lowering it into a “low roll” position. This is accomplished by lowering the bed until the stationary wheels raise off the floor and the rolling casters contact the floor surface for easy mobility.

  • Page 17: Section B - Assist Devices

    ZENITH SERIES SECTION B ASSIST DEVICES Model ZG58174 GF Health Products, Inc. - www.grahamfield.com Zenith 5000 Service Manual 999-0856-190C - DEC. 2013...

  • Page 18: Optional Pivoting Assist Bar Installation

    ZENITH SERIES OPTIONAL PIVOT ASSIST BAR INSTALLATION & OPERATION KIT ZA85400 - (Sample shows bar positioned on left side of bed) 1. At the head end of the bed, position the Pivoting Assist Bar (#2) bracket over the Head Deck (#1) frame and align the two holes...

  • Page 19: Optional Half Rail Installation

    ZENITH SERIES OPTIONAL PLASTIC HALF RAIL INSTALLATION & OPERATION KIT ZA84200 - (Sample shows rail positioned on right side of bed) RH Plastic Half Rail 1. Position the Plastic Half Rail (#2) as shown, with the taller, straight edge Assembly (#2) toward the head end of the bed and arms angled toward center of the bed.

  • Page 20: Optional Trapeze Support Installation

    ZENITH SERIES OPTIONAL TRAPEZE SUPPORT INSTALLATION (The Trapeze Support is attached to the head section of the bed.) Please Order Kit Number ZA79000 Trapeze Support vertical support tube. (TMI Bar Sleeve would be inserted inside the tube.) Use first holes in...

  • Page 21: Section C - Mechanical/Electrical Information

    ZENITH SERIES SECTION C Mechanical & Electrical Information GF Health Products, Inc. - www.grahamfield.com Zenith 5000 Service Manual 999-0856-190C - DEC. 2013...
  • Page 22 ZENITH SERIES ZENITH 5000 MECHANICS ZENITH 5000 ELECTRICAL NOTE: All dimensions are in a range of +/- .25 inches • • Overall Bed Length (with brds & wallsaver) . . 82”/86” Power/Frequency ... . 120 Volt/ 50/60 Hz •...
  • Page 23 ZENITH SERIES ZENITH 5000 SERIES ELECTRICAL COMPONENTS Plug-in for Optional Battery Control/Junction Box Backup Part # 999-0844-300B Quantity = 1 Pendant/Hand Controller Box and cable color = White Part # 999-0775-305 Quantity = 1 Pendant & Alligator Clip Part # 999-0808-112...
  • Page 24 ZENITH SERIES ZENITH 5000 SERIES ELECTRICAL CABLING POWER CABLE PENDANT CABLE HEAD CABLE FOOT CABLE HI/LO CABLE (FOOT) HI/LO CABLE (HEAD) BLACK CONTROL CABLE GROUND WIRE III IIII Control Cable (crown) Head - Port I Foot - Port II HI/LO (Ft) - Port III...

  • Page 25: Section D - Service/Replacement Parts

    ZENITH SERIES SECTION D SERVICE/REPLACEMENT PARTS GF Health Products, Inc. - www.grahamfield.com Zenith 5000 Service Manual 999-0856-190C - DEC. 2013...
  • Page 26 ZENITH SERIES SERVICE/REPLACEMENT PART RECORD (Page 1) DECKING Part Number Description Order Date Price 999-0844-920SP Head/Back Deck & Hardware Pack 1 Deck 999-0844-930SP OR - Foot Deck & Hardware Pack 1 Deck 999-0844-940SP OR - Knee Deck & Hardware Pack 1 Deck Deck Hardware Pack - INCLUDES .
  • Page 27 ZENITH SERIES SERVICE/REPLACEMENT PART RECORD (Page 2) PENDANT/HAND CONTROLLER Part Number Description Order Date Price 999-0808-305 Pendant/Hand Controller (Std. Model) 1 Pendant 999-0791-000 Pendant Holster (Std. for all pendants) 1 Holster SHORT BLACK CONTROL CABLE Part Number Description Order Date...
  • Page 28 ZENITH SERIES SERVICE/REPLACEMENT PART DIAGRAM - ELECTRONICS CONTROL BOX CONTROL CABLE HEAD CABLE BATTERY FOOT CABLE COMPARTMENT FOOT HI/LO HEAD HI/LO FOOT FOOT-END HI/LO MOTOR HEAD-END HI/LO MOTOR FOOT/KNEE MOTOR FEMALE PLUG ON STRAIGHT END - PENDANT CABLE MALE PLUG...
  • Page 29 ZENITH SERIES REPLACEMENT OF 9V BATTERY & OPTIONAL BATTERY BACKUP CHARGER AND BATTERY PACK REPLACING YOUR INTERNAL 9V BATTERY: 1. Remove battery cover on the underside of your control box by unscrewing the two phillips screws as shown. 2. Remove the existing battery connected to the Connector Cable from the battery slot.
  • Page 30 ZENITH SERIES SECTION E FRAMING SERVICE PARTS For All Zenith 5000 Bed Models GF Health Products, Inc. - www.grahamfield.com Zenith 5000 Service Manual 999-0856-190C - DEC. 2013...
  • Page 31 ZENITH SERIES SERVICE/REPLACEMENT PART DIAGRAM - DECKING HEAD DECK TO MAIN FRAME SEAT PAN BRACKETS Seat Bracket second Deck Bracket) DETAIL OF DECK KNEE DECK ATTACHMENT TO MAIN FRAME (Similar for all decks) SEAT PAN BRACKETS FOOT DECK TO KNEE DECK...
  • Page 32 ZENITH SERIES SERVICE/REPLACEMENT PART DIAGRAM - MAIN FRAME CAPPING HEAD FOOT CAPS OR PLUGS ARE NOT COVERED UNDER WARRANTY (PACKS OF 12 CAN BE ORDERED IN THE EVENT YOU DAMAGE OR LOSE ANY CAPS/PLUGS ON THE BED - SEE BOTTOM OF PAGE 27 FOR ORDER NUMBERS) GF Health Products, Inc.
  • Page 33 ZENITH SERIES SERVICE/REPLACEMENT PART DIAGRAM - CAPPING ON HEAD, KNEE, AND FOOT DECKS CAPPING ON ARMS & LEGS 2X 100-4715-011 2X 100-4700-018 Round End Caps End Caps 2X 100-4700-018 Rectangular End Caps 2X 100-4715-011 Round End Caps 2X 100-4700-021 Rectangular End Caps...

  • Page 34: Section E - Troubleshooting

    ZENITH SERIES SECTION E TROUBLESHOOTING All ZENITH 5000 Models GF Health Products, Inc. - www.grahamfield.com Zenith 5000 Service Manual 999-0856-190C - DEC. 2013...
  • Page 35 ZENITH SERIES ZENITH 5000 ELECTRONIC TROUBLESHOOTING QUICK REFERENCE The Zenith 5000 Series beds use a 4-motor system with ILCON electronics. NO POWER 1. Check Outlet. 2. Unplug Power Cord and Check following . . . a. Check Power Cord for damage or pinching.
  • Page 36 ZENITH SERIES ZENITH 5000 ELECTRONIC TROUBLESHOOTING QUICK REFERENCE HEAD OR FOOT MOTOR MALFUNCTIONING (DECK DOES NOT GO UP AND/OR DOWN) 1. Check All Motor Cable Connections. 2. Check Motor Condition - Cracked Housing, Scratches, Bent Shaft, etc. 3. Is Function Locked Out on Staff Control? 4.
  • Page 37 ZENITH SERIES TROUBLESHOOTING/REPLACING THE STAFF CONTROL (#7) 1. REMOVING AND REPLACING THE Staff Control Assembly with STAFF CONTROL ASSEMBLY bevel, panel & cables attached a. UNPLUG THE POWER CORD FROM THE WALL OUTLET. b. Unscrew the four Phillips Screws (#1) that attach the Shroud (cable cover) to the footboard and set aside.
  • Page 38 ZENITH SERIES NOTES: _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ GF Health Products, Inc. - www.grahamfield.com...

  • Page 39: Warranty Information

    ■ Any repair work or replacement shall not exceed the warranty duration. ■ Basic American Medical Products will, at its option, repair or replace defective product or parts, provided that the replacement or return has been previously authorized by Basic American or one of its divisions under the terms of this warranty.
  • Page 40 336 Trowbridge Dr. • Fond du Lac, WI 54937 Customer Service: 1.800.365.2338 • Fax: 920.929.8213 www.grahamfield.com © 2013 GF Health Products, Inc. All Rights Reserved Basic American Medical Products and Zenith are registered trademarks of GF Health Products, Inc.
