- Page 1 Installation and Operating Instructions Universal electronics kit for the LFG5 left-foot accelerator pedal, VAS version Art. no. BLF00004 www.veigel-automotive.de...
- Page 2 Document no. 250503 Created 2018-03-21 Name Schulz Subject to technical modifications without prior Revised 2021-06-28/Sch. notification and to errors. Reproduction, even in part, only permitted with Version 3 permission from Veigel GmbH + Co. KG.
-
Page 3: Table Of Contents
Contents Contents Contents .....................1-1 Revision history ....................1-2 General information ..................2-1 General safety information .................. 2-1 Product description ...................3-1 Function ......................3-1 Type plate ......................3-1 Scope of delivery ....................3-2 Block diagram ..................... 3-3 Intended use ....................... 3-4 Operation ....................4-1 Operation of the electronic switchover .............. -
Page 4: Contents
Contents Revision history Edition Revisions Chapter 01 / 2018-03-21 Initial version 02 / 2018-04-10 Editorial revision Correction of parts list included in scope of 03 / 2021-06-28 delivery... - Page 5 ATTENTION! This symbol refers to important additional information. NOTE This symbol refers to tips and recommendations. Veigel hotline Veigel GmbH + Co. KG Telephone: +49 (0) 7941 60585-0 Verrenberger Weg 36 Fax: +49 (0) 7941 60585-20 74613 Öhringen, Germany...
- Page 6 Contents Blank page for your notes...
-
Page 7: General Information
If the driving aid is installed in an authorised workshop, the installation re- cord must be filled in (see appendix). If it is installed at the factory, a sep- arate installation record will be prepared and archived at the Veigel factory. - Page 8 General information Observe the following in particular as a user: • Comply with generally accepted codes of practice when using and oper- ating the driving aid! ATTENTION! • Observe the applicable accident prevention and safety provisions when op- erating the driving aid! •...
-
Page 9: Product Description
The electronic left-foot accelerator meets the stringent provisions laid down by the automotive industry. Type plate Veigel GmbH + Co. KG 74613 Öhringen Type: Version: Type designation: xxxxxx-xxx Factory no.:... -
Page 10: Scope Of Delivery
Product description Scope of delivery Fig. 3-1: Scope of delivery Item Description Art. no. VAS safety electronics 230351 Button 230128 Sticker 250458 VAS universal cable set 230354 You will also need a second accelerator module that is identical to the one fitted in your vehicle, along with two matching contact housings and one connector housing with matching connectors. -
Page 11: Block Diagram
Product description Block diagram Switchover button VAS safety elec- Left-foot accelerator Target vehicle tronics module/right-foot accelerator module... -
Page 12: Intended Use
Product description Fig. 3-2: Electronic left-foot accelerator installed Intended use Use the LFG5 universal kit to install the module in automatic vehicles that do not have a vehicle-specific conversion kit. -
Page 13: Operation
Operation Operation Take a moment to familiarise yourself with the converted vehicle. It may be advisable to visit a driver training area to adapt to the unfamiliar mode of operation. The driving aid is easy to operate and its electronic control unit complies with the highest safety standards of the automotive industry. -
Page 14: Safety Information
The responsible repair shop should contact the system manufacturer in case of any doubt. (For details of the Veigel GmbH + Co. KG hotline, see page 1-3.) Arrange for any irregularities to be examined by a workshop. -
Page 15: Assembly
The tightening torques as specified by the vehicle manufacturer apply when converting vehicles using Veigel driving aids. Unless otherwise stated in the text, the usual DIN tightening torques provided ATTENTION! in the table below apply for Veigel parts. Coarse thread Fine thread Tightening torque (Nm) -
Page 16: Lfg5 Electrical Connections
Assembly LFG5 electrical connections Disconnect the contact housing (coming from the motor control device) from the original accelerator pedal module. Crimp the accelerator module connections on with the matching original contact housing (vehicle-specific). Crimp the motor control device connection on with the matching original mating connector on the contact housing that you disconnected previously. -
Page 17: Accelerator Pedal Signal/Pin Assignment
Assembly Accelerator pedal signal/pin assignment To find out how the pins and signals are assigned, use a multimeter to test the cables on the original ac- celerator module. The following signals are usually present: 2x supply voltage, 2x signal cables+, 2x earth. -
Page 18: Installing The Accelerator Module
Assembly Installing the accelerator module Create a suitable holder to enable you to assemble the second accel- erator pedal module in the vehicle. Fasten this holder to the available screw points as a first preference or, alternatively, to new drill holes you have made in the vehicle. - Page 19 Assembly Installing the accelerator module Make sure that there is a gap of 50 mm between the additional accelerator module and the ATTENTION! brake pedal to rule out the pos- sibility of operating errors. Also make sure that the accel- erator and brake pedal plate is not elevated.
-
Page 20: Installing The Accelerator Module
Assembly Installing the accelerator module See Fig. 5-7 to 5-9 for examples of how to install the fastenings for the additional accelerator module. Fig. 5-7: Example installation Fig. 5-8: Example installation Fig. 5-9: Example installation... -
Page 21: Button With Integrated Status Led
Assembly Button with integrated status LED Drill a hole with a minimum 19.2 mm diameter in a suitable place. Note the length of the button and plan for a minimum depth of 40 mm. Insert and screw down the button, then connect it to the wiring har- ness supplied. -
Page 22: Laying The Cables
Assembly Laying the cables Before finally laying the cables, check that the two contact housings have been assembled on the accelerator modules correctly (see Operation on page 4-1). If NOTE they have not, replace the contact housings on the accelerator modules. Securely fasten the VAS safety electronics in the vehicle, then lay and fasten the cables, preferably... -
Page 23: Maintenance And Care
Maintenance and care Maintenance and care Safety information Maintenance and repair work on the devices may only be performed by authorised and appropriately trained staff! ATTENTION! Arrange for functional faults to be remedied immediately by a specialist workshop. Only personnel authorised by us may open the control, otherwise any warranty claim shall be invalidated. -
Page 24: Transport, Storage And Disposal
Transport, storage and disposal Transport, storage and disposal Transport and storage Transport and storage are only permitted in the original packaging. Disposal Always comply with national and regional waste disposal directives. We ensure that the majority of the materials used to make our products are re- cyclable, right from the design phase. -
Page 25: Installation Record
Installation record Installation record This record will be completed if the driving aid is installed at a specialist workshop. If it is installed at the Veigel factory, a separate installation record will be pre- pared and archived there. Customer: Installation date:... - Page 26 Installation record Blank page for your notes...
- Page 27 Installation record Blank page for your notes...
- Page 28 Veigel GmbH + Co. KG Verrenberger Weg 36 74613 Öhringen, Germany tel. +49 (0) 7941 60585 0 fax +49 (0) 7941 60585 20 info@veigel-automotive.de www.veigel-automotive.de A SOLUTION FOR EVERY VEHICLE...
