Specifications

General
Power requirements 100 to 240 V AC, 50/60 Hz
Current consumption
1 to 0.5 A
Operating temperature
5°C to 40°C (41°F to 104°F)
Storage temperature
–20°C to +60°C (–4°F to +140°F)
Operating humidity 20% to 90% (relative humidity)
Mass 13.5 kg (29 lb 12 oz)
424 × 132 × 450 mm (w/h/d)
Dimensions
(19 × 5
including projecting parts
Digital video input
SDI INPUT BNC (2)
MAIN: Component serial digital
(270 Mbps)
SMPTE 259M/ITU-R BT-656
SUB: Component serial digital
(270 Mbps)
SMPTE 259M/ITU-R BT-656
(video only, no embedded audio)
DSK INPUT BNC (2)
FILL: Component serial digital
(270 Mbps)
SMPTE 259M/ITU-R BT-656
(video only, no embedded audio)
IN: Component serial digital (270
Mbps)
SMPTE 259M/ITU-R BT-656
(video only, no embedded audio)
Digital video outputs
PROGRAM 1/2/3/4 BNC (4)
Analog video inputs
REF. VIDEO BNC (2), including a loop-
through output
Black burst signal
0.3 Vp-p, 75 ohms, sync negative
× 18
7 3
/ / inches)
8 4
Analog video output
MONITOR OUTPUT
BNC (1), l.0 Vp-p, 75 ohms,
unbalanced
Control input/output
REMOTE INPUT D-sub 9-pin (1)
RS-422A standards
REMOTE OUTPUT
D-sub 9-pin (1)
RS-422A standards
ISR D-sub 25-pin
RS-232C standard
GPI BNC (3)
TTL level, 10 kilohms
MOUSE D-sub 9-pin (1)
RS-232C standard
Supplied accessories
Operation manual (1)
Design and specifications are subject to change
without notice.
