PA4G
14 SEER Single and Three Phase
Single Packaged Air Conditioner System
with R-410A Refrigerant
2-5 Nominal Tons (Sizes 24-60)
For your convience, please record the model and serial numbers of your new equipment in the spaces
provided. This information, along with the installation data and dealer contact information, will be
helpful should your system require maintenance or service.
UNIT INFORMATION
Model #
Serial #
ACCESSORIES (List type of model #)
Our products are designed, tested and built in accordance with DOE standardized procedures; however, actual operating results and efficiencies may
vary based on manufacturing and supplier tolerances, equipment configuration, operating conditions and installation practices.
Owner's Information Manual
Fig. 1 – Unit PA4G
NOTE TO EQUIPMENT OWNER:
NOTE TO INSTALLER:
This manual must be left with the eqipment owner.
INSTALLATION INFORMATION
Date Installed
DEALERSHIIP CONTACT INFORMATION
Company Name
Address
Phone Number
Technician Name
A09183
