Removing the Disk Interconnect Board

Perform the following procedure to remove the disk interconnect board from
the storage tray:
1 Remove the two retaining screws from the disk interconnect board, as shown in
Figure 3
2 Disconnect any cables from the disk interconnect board.
3 To remove the disk interconnect board, hold it by the edges and lift straight up,
Figure 3.
Removing the Disk Interconnect Board
as shown in Figure 3.
Removing the Disk Interconnect Board
5
