- Page 1 SSQ4004 SSQ8001 SSQ12001 SSQ SERIES AMPLIFIERS Application Guide Please read through this manual to familiarize yourself with your new amplifier. Should your Triton Amplifier ever require service, you will need to have the original dated receipt.
-
Page 2: Technical Features
Congratulations and thank you for purchasing your Triton SSQ Amplifier. With a focus on quality, innovation, and value, you now own the ultimate in sound quality and engineering from a factory that truly believes in the relentless pursuit of perfection. Incorporating the highest quality parts and state- of-the-art materials, these amplifiers deliver the ultimate in sound quality and power performance. -
Page 3: Frequency Response
SPECIFICATIONS FOR TRITON SSQ AMPLIFIERS (Due to continuing improvements these specifications are subject to change without any notice. Do not attempt to fix or repair this unit. Unauthorized repairs will void the manufacturer’s warranty..) MODEL SSQ4004 POWER RMS 2 Ohm @ 14.4V 4x120 POWER RMS 4 Ohm @ 14.4V... - Page 4 MODEL SSQ80001 POWER RMS 1 Ohm @ 14.4V >800W POWER RMS 2 Ohm @ 14.4V >600W POWER RMS 4 Ohm @ 14.4V >400W THD=N @ Nominal Power Frequency Response 20-450Hz >78dB(1W) Input Sensitivity 0.22-5.2(±10%) Damping Factor 100(4Ω) Operating Voltage 6.5-15.8(±0.3) High Pass Filter 20-35Hz(±3) Low Pass Filter...
- Page 5 Installation of Triton SSQ Amplifiers requires detailed knowledge of electronics wiring. We strongly recommend installation by an authorized Triton dealer. This Owner’s Manual only provides general installation and operation instructions. If you have any reservations about your installation skills, please contact your local Triton dealer for assistance. GENERAL INSTALLATION TIPS •...
- Page 6 INSTALLATION SEQUENCE • Triton Audio recommends having all products installed by Authorized Triton dealers. Check www.Triton-Audio.com for the most up to date owners manauals. • Before installing the amplifier turn off the source and all other electronic devices in the audio system to prevent any damages.
- Page 7 PRE INPUTS STEREO PRE OUT HI LEVEL INPUTS Hi-level STEREO OUTPUTS Set-up Adjustment AVAILABLE CONTROLS CONTROLS...
- Page 8 AUTO TURN ON BY SPEAKER IN (without REMOTE IN) Select ON the switch “Hi-In Auto Turn-On” Auto Turn-On L: 7 mm (5/16”) MAX: 16 AWG Hi-level STEREO OUTPUTS NO CONNECT! Set-up Adjustment AVAILABLE CONTROLS CONTROLS...
-
Page 9: Installation Examples
INSTALLATION EXAMPLES 4 Ω Subwoofer L-R Subwoofer L-R *Coaxial speakers *Coaxial speakers...
