- Page 1 Version : 2021 Rev.0 1200°C Muffle Furnace with Vacuum SH-FU-1.5MGV / 10MGV / 31MGV 1500°C Muffle Furnace with Vacuum SH-FU-4.5MHV / 18.7MHV...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Keep this manual on-hand so it can be used by all operators of the unit. Use the unit only in the way described in this manual. Failure to follow the instruction in this manual may cause wrong operation. 1. -
Page 3: General Description
1. General description Thank you for purchasing our product. We know that in today's competitive marketplace, customers have many choices when purchasing laboratory equipment. We appreciate your choosing our quality product. We stand behind our products and want to let you know we are here if you need us. Before you use the unit, read this entire manual carefully to understand how to install, operate and maintain the unit in a safe manner. -
Page 4: Graphic Symbols
2. Graphic symbols BE SURE THAT YOU UNDERSTAND ALL OF THESE SYMBOLS BEFORE OPERATING THE UNIT. Important operating and / or maintenance instruction. Read the accompanying text carefully. This symbol indicates items and procedures that are STRICTY PROHIBITED with regards to the unit. Potential electrical hazards. -
Page 5: The Outward
3. The outward Vent port Heater S/W Temp Controller Gas valve Concent Pressure gauge Vacuum port Main S/W Gas out port Vacuum & Vent Gas in valve port <SH-FU-1.5MGV / 10MGV / 31MGV>... - Page 6 Vent port Heater S/W Temp Controller Gas valve Concent Pressure gauge Vacuum port Main S/W Gas out port Vacuum & Vent Gas in valve port <SH-FU-4.5MHV / 18.7MHV>...
-
Page 7: Installation
4. Installation ① Once the product is ③ Lift the box as shown in ② Unscrew the bottom of delivered, place the the picture. the box. package on a flat location. ④ Unwrap the bag. ⑤ Place the equipment on ⑥... - Page 8 Level controller Level controller <Clockwise> <Counter clockwise> Stopper <Lock position> <Unlock position> • When stopping moving • When moving equipment or installing equipment When installing equipment, fix the stopper to the floor by turning the level controller clockwise or counterclockwise. Serial label shows the electric power specification of the unit.
-
Page 9: Vacuum Setting And Operation
5. Vacuum Setting and Operation ① Connect the input gas to the Gas in port. ② Connect the Vacuum Pump to the Vacuum port. ③ Turn the Vacuum & Vent valve towards Vacuum. Atmospheric pressure ④ Close the Gas valve. Vacuum Pressurization [Gauge status]... -
Page 10: Temperature Setting And Operation
6. Temperature Setting and Operation ex) 100℃ for 1 hour, 200℃ for 1 hour. Press SET for 1 sec Press SET for 3 sec Press SET for 3 sec, Press SET for 1 sec, Goes to setting mode. Goes to pattern mode. Press SET for 1 sec Press PT1 "... - Page 11 Changing setting After setting Changing setting After setting press for 1 sec press for 1 sec press SET for 1 sec press SET for 1 sec 1.LC means program No, Setting "0" is no effect for operating. LC means parameter when operating is end. RST-Stop operating after last segment HOLD-Keep temp of last segment PTH1-Endless loop of No.1 program...
- Page 12 Changing setting After setting After setting press for 1 sec press SET for 1 sec press SET for 1 sec TS1(Time Signal) is setting for usage of function. SP2 is setting parameter for keep Only use in case of using controller EV. section of 1st testing temp.
- Page 13 Changing setting After setting Changing setting After setting press for 1 sec press for 1 sec press SET for 1 sec press SET for 1 sec SP3 is setting parameter for Time3 is setting parameter for keep section of 2nd testing Temp. heating time of SP3(Time:Min).
- Page 14 After setting Changing setting After setting press for 1 sec press SET for 1 sec press SET for 1 sec Time4 is setting parameter for TS4 is setting parameter for usage of function. keeping time of SP4. Only use in case of using controller EV(event). ex) Setting : Keep 200℃(SP4) for 1 hour.
- Page 15 After setting After setting press SET for 1 sec press SET for 1 sec RPT is repeat mode of section, REN is setting setting last segment No of repeat available setting 1~999. mode. But you don't need to use repeat ※...
- Page 16 Present Temp Check heater (PV) ex) 2% heating (PV) Program 1 Program 1 lamp lighting lamp lighting Check operating Check operating Setting Temp SET 1 sec SET 1 sec (SV) Yellow light on PRG1 show SV on SP. Press SET for 1 sec to check present operating showing on SP.
- Page 17 "HOLD OFF" STEP "OFF" Do not change Do not change Program 1 Program 1 lamp lighting lamp lighting Check operating Check operating SET 1 sec SET 1 sec Press SET for 1 sec to check present operating Press SET for 1 sec to check present showing on SP.
-
Page 18: Specification
7. Specifications (SH-FU-1.5MGV / 10MGV / 31MGV) 1200°C Muffle Furnace with Vacuum Model SH-FU-1.5MGV SH-FU-10MGV SH-FU-31MGV Max Temp 1200℃ (2192℉) Temp Controller Programmable Controller(SP590) Heater Capa 1100 W 3000 W 6000 W Capa 1.5L 115x115x115mm 215x215x215mm 315x315x315mm Dimension Internal (W×D×H) 4.53x4.53x4.53''... - Page 19 7. Specifications (SH-FU-4.5MHV / 18.7MHV) 1500°C Muffle Furnace with Vacuum Model SH-FU-4.5MHV SH-FU-18.7MHV Max Temp 1500℃ (2732℉) Temp Controller Programmable Controller(SP590) Sensor R type Heater Capa 3300 W 10000 W Capa 4.5 L 18.7 L 150x200x150mm 250x300x250mm Dimension Internal (W×D×H) 5.91x7.87x5.91'' 9.84x11.81x9.84'' 630x590x830mm...
