- Page 1 www.samheung21.com Version : 2021 Rev.0 1200°C TUBE FURNACE Gas Flow Package SH-FU-50/80/100/120STG-WG SH-FU-50/80/100/120LTG-WG Tel. +82 42 826 5172 E-mail. i-sales@samheung21.com Sejong-si, Republic of Korea...
-
Page 2: Table Of Contents
Table of Contents Keep this manual on-hand so it can be used by all operators of the unit. Use the unit only in the way described in this manual. Failure to follow the instruction in this manual may cause wrong operation. 1. -
Page 3: General Description
1. General Description Thank you for purchasing our product. We know that in today's competitive marketplace, customers have many choices when purchasing laboratory equipment. We appreciate your choosing our quality product. We stand behind our products and want to let you know we are here if you need us. Before you use the unit, read this entire manual carefully to understand how to install, operate and maintain the unit in a safe manner. -
Page 4: Graphic Symbols
2. Graphic Symbols BE SURE THAT YOU UNDERSTAND ALL OF THESE SYMBOLS BEFORE OPERATING THE UNIT. Important operating and / or maintenance instruction. Read the accompanying text carefully. This symbol indicates items and procedures that are STRICTY PROHIBITED with regards to the unit. Potential electrical hazards. -
Page 5: The Outward
3. The Outward < 50/80/100/120STG > < 50/80/100/120LTG >... -
Page 6: Key Feature
4. Key Feature • Digital display of temp and time • Auto back up • Multi key-in (100Ω(DIN Pt100Ω), KPt100Ω(JPt100Ω), K(CA)) • Precise temperature control • Alarm when timer ends • Over-temperature protection • Separated body and control box design function(FU-xxTG) protecting from thermal shock(FU-xxTG) -
Page 7: Installation
5. Installation ① Once the product is ② Unscrew the bottom of ③ Lift the box as shown in delivered, place the the box. the picture. package on a flat location. ④ Unwrap the bag. ⑤ Place the equipment on ⑥... - Page 8 <Fig-1> Refer to above fig-1, level the equipment by adjusting the feet. Serial label shows the electric power specification of the unit. Connect power and turn on the main switch(E.L.B). Please do not raise up it high temp at once. It case to decline durability.
- Page 9 -How to use assemble pipe lines 1) Please check if all parts are in the package; -1 panel of 1 Flowmeter and valve, -3 pipe lines with nuts, -1 Gas gauge with valve Fig-3) Fig-2) Fig-3) In case of Pipe parts for 2 gas channels, 1 panel of 2 Flow-meters and valves, 4 pipe lines with nuts, 1 Gas gauge with valve.
- Page 10 2) Screw down the panel of flow meter and valve, connect 3 pipe lines each(Fig-4, -5, -6). Tighten the each bolt and nut with spanner. (Fig-4) (Fig-5) (Fig-6)
-
Page 11: Setting And Operation
6. Setting and Operation 1) Controller ① LCD display ② Program mode lamp ③ Heater lamp ④ Timer lamp ⑤ Auto tune lamp ⑥ Local mode lamp ⑦,⑧ Shift button (Mute) ⑨,⑩ Setting ⑪ Program ↔ Local ⑫ Mode ⑬ Start/Stop... - Page 12 (1) Stand by [ PV: current temp. SV: Target temp. TM: Holding time at target temp. ] 00:00 (hour : minute) (2) Local mode 1. Press ⑫ to set temp. and holding time 2. Set Temp. and Time with ⑦,⑧,⑨,⑩ and save it with pressing ⑫. 3.
- Page 13 (3) Program mode # Program mode provides 5 Pattern settings and 9 Step settings for each pattern. # In program mode, it can be set not only TM (holding time at target temp.) but also TS (ramp up time to target temp.). [ P1-Step1 : Pattern no.1 and Step no.1 TS: Ramp up time to target temp.
- Page 14 4. If you want to finish setting of pattern, set TM with 00:00 in last Step. Setting page and save it with pressing ⑫. Then it completes setting of pattern no.1. 5. Set number of cycling for the saved Pattern with ⑦,⑧,⑨,⑩. (* 999 cycles can be set.
- Page 15 7. Specifications 1200℃ Tube Furnace Gas Flow Package – 50/80/100/120STG-WG (300mm Length Hot Zone) Model SH-FU-50STG-WG SH-FU-80STG-WG SH-FU-100STG-WG SH-FU-120STG-WG Furnace SH-FU-50STG SH-FU-80STG SH-FU-100STG SH-FU-120STG Gas Flowmeter 1EA Stainless Steel Pipe & Connector Components Gas Sealing Mask Quartz Tube (Length 1000 mm)
-
Page 16: Specification
7. Specifications 1200℃ Tube Furnace Gas Flow Package – 50/80/100/120LTG-WG (600mm Length Hot Zone) Model SH-FU-50LTG-WG SH-FU-80LTG-WG SH-FU-100LTG-WG SH-FU-120LTG-WG Furnace SH-FU-50LTG SH-FU-80LTG SH-FU-100LTG SH-FU-120LTG Gas Flowmeter 1EA Stainless Steel Pipe & Connector Components Gas Sealing Mask Quartz Tube (Length 1200 mm) 120V FU50LTGWG120 FU80LTGWG120... - Page 17 Memo...
- Page 18 Memo...
- Page 19 www.samheung21.com...
