- Page 1 GS3060 GSM-GPRS INTERFACE INSTALLATION MANUAL WARNING: This manual contains information on limitations regarding product use and function and information on the limitations as to liability of the manu- facturer. The entire manual should be carefully read. firealarmresources.com...
- Page 2 firealarmresources.com...
-
Page 3: Table Of Contents
Installing the GS3060 ........4... - Page 4 IMPORTANT The equipment is fixed, wall-mounted and shall be installed in the position specified in these instructions. The equipment enclosure must be fully assembled and closed, with all the necessary screws/tabs and secured to a wall before operation. Internal wiring must be routed in a manner that prevents: - Excessive strain on wire and on terminal connections - Loosening of terminal;...
-
Page 5: Introduction
• Panel transmission monitoring for up to four phone numbers Technical Specifications The input voltage to the GS3060 can be drawn from the UL/ULC Listed control panel or provided by an external UL/ULC Listed power supply rated for the application (external power-limited source). -
Page 6: Identification Of Parts
Figure 1 - Parts LOCK OPEN OFF ON NOTE: For UL/ULC installa- tions, connections between the alarm control panel out- puts (telephone interface Tip/Ring, output relay con- tacts) and GS3060 inputs (Tip/Ring, Z1-Z4) shall be tie wrap PGM1 PGM2 PGM3 PGM4 AUX+ TAMPER... -
Page 7: Description
4 hours standby power capabilities. An example of a suitable listed compatible control unit is the DSC Model PC1864 with an AUX output rated 11.1 - 12.6VDC. An example of a suitable Listed power supply is DSC Model PC5204 with an AUX output rated 11.6 - 12.6VDC. -
Page 8: Installing The Gs3060
NOTE: Electrical current drawn from this terminal is drawn directly from the power supply. This must be added to the GS3060 current when determining the total draw on the host panel or power supply. Jumper JP3 does not limit the electrical current available on this output. -
Page 9: Status Leds
‘No Service’. If this LED flashes, the following list indicates the specific trouble based on the number of flashes, by priority. When turned on, the GS3060 checks for the trouble conditions to be restored in the order listed below. The GS3060 indicates the status of the highest priority, unrestored trouble condition with the corresponding number of flashes of the red LED. -
Page 10: Operating Principles
• The central station receiver acknowledges the alarm and sends a command to the GS3060 to gen- erate the corresponding 1400Hz Kiss-off signal for a minimum of 800msec. After the GS3060 generates a Kiss-off signal, it sends the next alarm or, if no further alarms need to be sent, the control panel goes on-hook. -
Page 11: Outputs
The GS3060 has four open collector outputs capable of a maximum of 50mA. Internal events on the GS3060 can trigger the outputs to turn on an LED or activate an input on the host panel. The default settings are as follows. -
Page 12: Low Power Radio Shutdown
YELLOW light will flash one time when the signal is transmitted and two times when it gets a kiss-off. SIM – the SIM should be activated at least 24 hours prior to installation. The GS3060 will not show signal strength until the SIM is active. - Page 13 • When used as the primary communicator, the yellow light will always be • When used as a backup communicator, the yellow light will be ON when there is a no phone line connected to the GS3060 TIP and RING, or the line voltage goes below 2.8VDC.
- Page 14 GS3060 low battery trouble (one flash) and an insufficient signal strength trouble (four flashes) are present; the red light will flash one time. Once the GS3060 low battery trouble condition is corrected, the red light will then begin flashing four times.
- Page 15 • The lights will continue to flash in this sequence until the battery is charged above 12.4VDC Swinger Shutdown for Telephone • If the GS3060 is configured as a backup, it can send a maximum of 3 TLM troubles and restorals per day Line Monitor (TLM) transmissions for •...
-
Page 16: Gs3060 Wiring Diagrams
GS3060 Wiring Diagrams Figure 2 - Wiring Diagram firealarmresources.com... - Page 17 CMC. 3. Output 4 on the GS3060 must be set as “Active High” (default). 4. When powering the GS3060 Radio by an...
- Page 18 - 24h Test Transmission must be enabled on the dialler and on the GS3060. Figure 6 - DSC Subscribers’ Unit Fire and GSM Transmitter Mounted in the Same Room Wiring Diagram for DSC Subscribers’ Unit Fire and GSM Transmitter (Passive Communication System)
- Page 19 GS3060 Wiring Diagrams Figure 7 - DSC Subscribers’ Unit Fire and GSM Transmitter Mounted Remotely Alternate Wiring Diagram for DSC Subscribers’ Unit Fire and GSM Transmitter Passive Communication System -Using Phone Line Supervision Relay GSM Network AUX Power Fire Alarm...
- Page 20 GS3060 Wiring Diagrams Figure 8 -Connection Details for GSM Supervision Relay and Redundant Fire Alarm Transmission Connection Details for GSM Supervision Relay & Redundant Fire Alarm Transmission GS3060 12 13 19 20 O1 O2 O3 O4+OC L1 L2 L3 L4...
- Page 21 GS3060 Wiring Diagrams Figure 9 - Connection Details for GSM Supervision Relay, Phone Line Supervision and Redundant Fire Alarm Transmission Connection Details for GSM Supervision Relay, Phone Line Supervision Relay and Redundant Fire Alarm Transmission GS3060 12 13 O1 O2 O3 O4+OC...
- Page 22 IMPORTANT READ CAREFULLY: DSC Software purchased with or without Products and Components is copyrighted and is purchased under the following license terms: 3. COPYRIGHT • This End User License Agreement ("EULA") is a legal agreement between You (the company, individual or entity who acquired the Soft-...
- Page 23 This equipment generates and uses radio frequency energy the end user. and if not installed and used properly, in strict accordance with the DSC c/o APL Logistics, 757 Douglas Hill Rd., Lithia Springs, GA 30122 manufacturer's instructions, may cause interference to radio and Additional Information television reception.
- Page 24 Access cards or tags returned for replace- purchase, the product shall be free of defects in materials ment under warranty will be credited or replaced at DSC's and workmanship under normal use. During the warranty option. Products not covered by this warranty, or other-...
