HP Vectra VE4 Installation Manual

Smart 16/4 pci token-ring
Hide thumbs Also See for Vectra VE4:

Advertisement

Quick Links

Download this manual See also: Reference Manual, User Manual
Smart 16/4 PCI Token-Ring
Installation Guide

Advertisement

loading

Related Manuals for HP Vectra VE4

Summary of Contents for HP Vectra VE4

  • Page 1 Smart 16/4 PCI Token-Ring Installation Guide...
  • Page 2 Hewlett-Packard Company. Microsoft®, Windows® and MS-DOS® are registered trademarks of Microsoft Corporation. is a trademark of Intel Corporation. Pentium® is a registered trademark of Intel Corporation. Hewlett-Packard France Commercial Desktop Computing Division 38053 Grenoble Cedex 9 France...
  • Page 3 • Interrupt • I/O Address Procedure 1 With the HP Vectra turned off install the Madge Smart16/4 PCI TR adapter card into a PCI slot. 2 Power on the machine and boot to a DOS prompt. 3 Insert Netware Client for DOS and Windows Disk 1 and execute “A:\INSTALL.”...
  • Page 4 1 Connecting to a Netware 3.12 Server Windows for Workgroups 6 After windows loads, open the “NETWORK” folder, and double-click the “NETWORK SETUP” icon. 7 Select “Networks” and verify that “Novell Netware (Workstation Shell 4.0 and above)” is optioned under “Install Windows support for the following network only.”...
  • Page 5 2 When prompted, click on “Other Locations.” 3 Insert drivers disk 2 of 2, set the path to “A:\WIN95\RPL\” and click “OK.” (If you have an HP preloaded HDD, set the path to “C:\LANDRV\MADGE\DISK2\ WIN95\RPL\”) 4 Verify that “Madge Smart 16/4 PCI Ringnode (BM) 2” is listed and click on “Finish.”...
  • Page 6 1 Connecting to a Netware 3.12 Server Windows 95 SR2...
  • Page 7 • Interrupt • I/O Address Procedure 1 With the HP Vectra turned off install the Madge Smart16/4 PCI TR adapter card into a PCI slot. 2 Power on the machine and boot to a DOS prompt. 3 Insert Netware Client for DOS and Windows Disk 1 and execute “A:\INSTALL.”...
  • Page 8 2 Connecting to a Netware 4.11 Server Windows for Workgroups 6 After windows loads, open the “NETWORK” folder, and double-click the “NETWORK SETUP” icon. 7 Select “Networks” and verify that “Novell Netware (Workstation Shell 4.0 and above)” is optioned under “Install Windows support for the following network only.”...
  • Page 9 2 When prompted, click on “Other Locations.” 3 Insert drivers disk 2 of 2, set the path to “A:\WIN95\RPL\” and click “OK.” (If you have an HP preloaded HDD, set the path to “C:\LANDRV\MADGE\DISK2\ WIN95\RPL\”) 4 Verify that “Madge Smart 16/4 PCI Ringnode (BM) 2” is listed and click on “Finish.”...
  • Page 10 2 Connecting to a Netware 4.11 Server Windows 95 SR2...
  • Page 11 • Interrupt • I/O Address Procedure 1 With the HP Vectra turned off install the Madge Smart16/4 PCI TR adapter card into a PCI slot. 2 Power on the machine and run Windows. 3 After windows loads, open the “NETWORK” folder, and double-click the “NETWORK SETUP”...
  • Page 12 3 Connecting to a Windows NT 3.51 Server Windows for Workgroups 11 Confirm the DMA and hit enter. 12 At the “Network Drivers” window, click on “Close.” 13 At “Network Setup” click on “OK.” 14 Specify your User Name, Workgroup Name, and Computer Name and hit enter.
  • Page 13 2 When prompted, click on “Other Locations.” 3 Insert drivers disk 2 of 2, set the path to “A:\WIN95\RPL\” and click “OK.” (If you have an HP preloaded HDD, set the path to “C:\LANDRV\MADGE\DISK2\ WIN95\RPL\”) “Madge Smart 16/4 PCI Ringnode” should now be listed. Click on “Finish.”...
  • Page 14 14 Insert drivers disk 2 of 2, set the path to “A:\” and click “OK.” (If you have an HP preloaded HDD, set the path to “C:\LANDRV\MADGE\DISK2\”) 15 Click on “Yes” button to finish the setup installation and restart your...
  • Page 15 • I/O Base Address • Interrupt Request Level Procedure 1 With the HP Vectra turned off install the Madge Smart16/4 PCI TR adapter card into a PCI slot. 2 Power on the machine and log onto windows NT with administrator privileges.
  • Page 16 Windows NT Workstation Version 3.51 10 Set the path to “A:\NT” in the “Insert Disk” dialog box, and then insert the disk 2 of 2. (If you have an HP preloaded HDD, set path to “C:\LANDRV\MADGE\DISK2\NT\”) 11 Click “OK” at the “Install Driver” dialog box.
  • Page 17 • I/O Base Address • Interrupt Request Level Procedure 1 With the HP Vectra turned off install the Madge Smart 16/4 PCI TR adapter card into a PCI slot. 2 Power on the machine and log into NT workstation with administrator privileges.
  • Page 18 14 Insert the Windows NT Workstaion CD. 15 In the “Windows NT Setup” enter the path to your NT files, and click on the “Continue” button. (If you have an HP preloaded HDD, set path to “C:\I386”) 16 Click on the “OK” button in the “Madge Smart 16/4 PCI Adapter” dialog box.

  • Page 19: Connecting To A Windows Nt 4.0 Server

    • Interrupt • I/O Address Procedure 1 With the HP Vectra turned off install the Madge Smart16/4 PCI TR adapter card into a PCI slot. 2 Power on the machine and run Windows. 3 After windows loads, open the “NETWORK” folder, and double-click the “NETWORK SETUP”...
  • Page 20 4 Connecting to a Windows NT 4.0 Server Windows for Workgroups 11 Confirm the DMA and hit enter. 12 At the “Network Drivers” window, click on “Close.” 13 At “Network Setup” click on “OK.” 14 Specify your User Name, Workgroup Name, and Computer Name and hit enter.
  • Page 21 2 When prompted, click on “Other Locations.” 3 Insert drivers disk 2 of 2, set the path to “A:\WIN95\RPL\” and click “OK.” (If you have an HP preloaded HDD, set the path to “C:\LANDRV\MADGE\DISK2\ WIN95\RPL\”) “Madge Smart 16/4 PCI Ringnode” should now be listed. Click on “Finish.”...
  • Page 22 14 Insert drivers disk 2 of 2, set the path to “A:\” and click “OK.” (If you have an HP preloaded HDD, set the path to “C:\LANDRV\MADGE\DISK2\”) 15 Click on “Yes” button to finish the setup installation and restart your...
  • Page 23 • I/O Base Address • Interrupt Request Level Procedure 1 With the HP Vectra turned off install the Madge Smart16/4 PCI TR adapter card into a PCI slot. 2 Power on the machine and log onto windows NT with administrator privileges.
  • Page 24 Windows NT Workstation Version 3.51 10 Set the path to “A:\NT” in the “Insert Disk” dialog box, and then insert the disk 2 of 2. (If you have an HP preloaded HDD, set path to “C:\LANDRV\MADGE\DISK2\NT\”) 11 Click “OK” at the “Install Driver” dialog box.
  • Page 25 • I/O Base Address • Interrupt Request Level Procedure 1 With the HP Vectra turned off install the Madge Smart 16/4 PCI TR adapter card into a PCI slot. 2 Power on the machine and log into NT workstation with administrator privileges.
  • Page 26 14 Insert the Windows NT Workstaion CD. 15 In the “Windows NT Setup” enter the path to your NT files, and click on the “Continue” button. (If you have an HP preloaded HDD, set path to “C:\I386”) 16 Click on the “OK” button in the “Madge Smart 16/4 PCI Adapter” dialog box.
  • Page 28 Version Number Madge PCI Rev.1...
