- Page 1 FALCON 500 Micro Hardness Tester | Vickers, Knoop, Brinell MANUAL / SEMI - FULLY AUTOMATED...
- Page 2 FALCON 500 FALCON 600 Unparalleled configuration freedom… Our vision, your future... A FORCE RANGE THAT SETS NEW STANDARDS! The FALCON 500 offers a leading technology base for manual, automatic or fully automated testing of Micro and Macro Vickers, Knoop or Brinell assignments. 10gf 2kgf FALCON 501...
- Page 3 BOUNDLESS Multi loadcell, ball bearing, force actuator INNOVATION OPTIONAL Optical zoom, auto focus, stage overview camera Z-AXIS BALL SCREW Precision movement Observe, Think, Try, Change... Rigidity and perpendicular indenter positioning are crucial to obtain Vickers indents with a perfect geometry. Re-invented, adjustable indenter actuators provide maintenance free, smooth force application, easy to access and easy to replace indenters.
- Page 4 TECHNOLOGY Changing the game... CONNECTIVITY, CONTROL & QUALITY ASSURANCE 6 POSITION PRECISION TURRET & OPTICAL SYSTEM The system has bi-directional in and output channels. Tester control can be conducted remotely and supports The 6 position turret is supplied as a standard feature on all 500 models and for instance, but not limited to robotic systems.
- Page 5 AUTOMATIC IMAGE EVALUATION AUTO FOCUS Fast & precise, observe how IMPRESSIONS finds focus from a large distance, as far as the travel of the Z-axis allows. Algorithms used for close distance ILLUMINATION SETTINGS autofocusing set new standards in AF speed. IMPRESSIONS software automatic illumination system adapts to the correct illumination regardless of the sample surface quality, wherever on the sample, independent from material (steel, carbide,...
- Page 6 Science fiction?... No, just reality ahead of schedule The Graphical User interface (GUI), contains industry preferred applications, and offers easy to learn, advanced workflow control. A simple test can be set up and conducted in about 3 seconds… IMPRESSIONS layout & functions will match not only your particular application requirements, but also meet the needs and preferences of your operators.
- Page 7 Easy to operate, time reducing solutions... VIDEO OVERLAY GRAPHIC PATTERN EDITOR The IMPRESSIONS pattern editor allows the user to create any number of test HARDNESS OF SCREW THREAD patterns with a large number of variable DECARBONIZED ZONE (ISO-898-1) settings. Create test patterns with great precision and freedom.
- Page 8 Yes, we can... SNAPSHOT FUNCTION The IMPRESSIONS pattern editor allows the user to create any number of test patterns with a large This handy function in IMPRESSIONS number of variable settings. Create test patterns with great precision and freedom. Verify the settings Kic CRACK MEASUREMENT allows you to make screen captures of in the preview mode.
- Page 9 AMMUNITION TESTING PATTERN CONFIGURATOR & REPORTING This application is developed in close cooperation with special manufacturers of ammunition shells and casings. It allows single and multiple shell/casing testing according to the requirements in the industry. The fully automatic test procedure generates a detailed report, providing single readings and statistics with Go/No indication.
- Page 10 1.5mm chemical resistant plastic plating, edges made of shock resistant 3mm ABS side liner • Industrial quality, for workshop or laboratory Designed for hardness testing instruments, Anvils painted in INNOVATEST® RAL colors matching our testers. 15” 55” Fixtures & vices Vibration isolation stage...
-
Page 11: Order Details
ORDER DETAILS FALCON 500 Motorized CNC X-Y stage, 307x208mm, total load up to 400Kgf max UN-XY571712 Displacement: 170x120mm, resolution 0.001mm, repeatibility +/- FALCON 501 v2 / 501 FA v2 Micro hardness tester, 10gf - 2kgf FALCON 501 / 501 FA 0.003mm FALCON 502 v2 Micro hardness tester, 1gf - 2kgf FALCON 502... - Page 12 ACCESSORIES OVERVIEW CAMERA OBJECTIVES Limit switch relocator AS500XL-150-16 Printer Laser Printer UN-PRINT 2.5x Long Working Distance objective 20x Long Working Distance objective Projector On request, any brand of choice UN-PROJECTOR ISO / ASTM BRINELL direct and indirect verification/calibration & certification CALCEFRDW/1B 5x Long Working Distance objective 50x Long Working Distance objective...
- Page 13 Connectivity Plus Powerfull External Intell Core i9 PC, with 16gb RAM, and 512gb SSD drive (or UN-SYSPCIMP01 better) Windows 10 pre-installed, IMPRESSIONS™ tester work flow software INNOVATEST recommends Embedded Industrial computers with DeepFreeze enabled. Blue Tooth connectivity UN-BTADAPT Wireless system Keyboard & wireless mouse...
-
Page 14: Specifications
High performance embedded controller, i7, mSSD 120 GBxx, ISO 4545 ASTM E92 Standard (Recommended) MS Windows® 10 operated , up to 8 years* INNOVATEST warranty JIS Z 2251 Electronic system High performance external controller, i7, mSSD 120 GBxx, (Optional) MS Windows® 10 operated, 1 year factory warranty BRINELL HBW1/1 | HBW1/1.25 | HBW1/2.5 | HBW1/5 | HB1/10 | HBW1/30 | HBW2.5/6.25... -
Page 15: Technical Drawings
TECHNICAL DRAWINGS All dimensions in these drawings are in mm, approximate. Working heights and or workpiece accommodation varies depending on the stages and stage accessories used. Please contact our sales department for more details. FEATURED BY IMPRESSIONS v2 ADVANCED SOFTWARE APPLICATIONS... - Page 16 Descending test head, the products without prior work piece position fixed work piece position notice. We recommend you See brochure B18F5000/XX See brochure B18F5000/XX to contact our sales office for up-to-date information. Brochure B18 500/14/EN www.innovatest-europe.com © All rights reserved, 2018...
- Page 17 Phone: +31 43 3520060 Fax: +31 43 3631168 info@innovatest-europe.com www.innovatest-europe.com INNOVATEST USA Company INNOVATEST Deutschland GmbH INNOVATEST Shanghai Co,. Ltd. Sales & Service Sales & Service Sales & Service Phone: +49 245 670 59 500 Phone: +86 21 60906200 Phone: +1 267 317 4300 info@innovatest-deutschland.com...
