- Page 1 NEMESIS 5100 Universal Hardness Tester | Rockwell, Vickers, Knoop, Brinell AUTOMATIC / FULLY AUTOMATED...
- Page 2 Truly Universal... Our vision, your future... The NEMESIS 5100 Series Universal Hardness testing systems provide exceptional performance and are designed with enhancements that deliver unparalleled accuracy and reliability, improved ergonomics and an overall enhanced and pleasant experience for the operator. The IMPRESSIONS tester control and work fl ow software, forms an integral component of the testing system.
- Page 3 TECHNOLOGY Crossing all boundaries... CONNECTIVITY, CONTROL & QUALITY ASSURANCE 8 POSITION PRECISION TURRET & LASER POSITIONING The system has bi-directional in and output channels. Tester control can be conducted remotely and supports The 8 position turret is supplied as a standard feature on all 5100 models and for instance, but not limited to robotic systems.
- Page 4 THE POWER OF INNOVATION It’s not about ideas, it’s about making ideas happen... Sophisticated and unique, 100% linear, vertical force actuator. Cutting edge technology, high speed turret with integrated multi load cell signal handling, stage overview camera at indenter position, power LED TTL illumination, positioning laser and an advanced collision detection and test head retraction system.
- Page 5 TECHNOLOGY Servo Drive System for Vertical force low force models actuator with The high speed 8 position turret or revolver is the main center of performance of the NEMESIS 5100 series. position reading position reading system system Designed for test forces up to 3000kgf in the NEMESIS 5100 confi guration, this masterpiece of mechanics and optics also incorporates load cells and electronics to handle all force application and force system feedback.
-
Page 6: Auto Focus
AUTOMATIC IMAGE EVALUATION AUTO FOCUS AUTO FOCUS AUTO FOCUS Fast & precise, observe how IMPRESSIONSTTM fi nds Fast & precise, observe how IMPRESSIONSTTM fi nds Fast & precise, observe how IMPRESSIONS fi nds ILLUMINATION SETTINGS focus from a large distance, as far as the travel of focus from a large distance, as far as the travel of focus from a large distance, as far as the travel of the Z-axis allows. - Page 7 Science fi ction?... No, just reality ahead of schedule The Graphical User interface (GUI), contains industry preferred applications, and off ers easy to learn, advanced workfl ow control. A simple test can be set up and conducted in about 3 seconds… IMPRESSIONS layout &...
- Page 8 Easy to operate, time reducing solutions... VIDEO OVERLAY GRAPHIC PATTERN EDITOR The IMPRESSIONS pattern editor allows the user to create any number of test HARDNESS OF SCREW THREAD patterns with a large number of variable DECARBONIZED ZONE (ISO-898-1) settings. Create test patterns with great precision and freedom.
- Page 9 Yes, we can... SNAPSHOT FUNCTION The IMPRESSIONS pattern editor allows the user to create any number of test patterns with a large he IMPRESSIONS pattern editor allows the This handy function in IMPRESSIONS number of variable settings. Create test patterns with great precision and freedom. Verify the settings number of variable settings.
- Page 10 NEMESIS 5100 AMMUNITION TESTING PATTERN CONFIGURATOR & REPORTING This application is developed in close cooperation with special manufacturers of ammunition shells and casings. It allows single and multiple shell/casing testing according to the requirements in the industry. The fully automatic test procedure generates a detailed report, providing single readings and statistics with Go/No Go indication.
- Page 11 1.5mm chemical resistant plastic plating, edges made of shock resistant 3mm ABS side liner • Industrial quality, for workshop or laboratory Designed for hardness testing instruments, painted in INNOVATEST® RAL colors matching our testers. 15” 55” Vibration Isolation stage Sample holders...
-
Page 12: Order Details
ORDER DETAILS FALCON 600 NEMESIS 5100 NEMESIS 5101 Universal hardness tester, 500gf - 250kgf NEMESIS 5101 Lock fl ange UN-XYZ BUSH50 Mounting plate for lock fl ange UN-XYZ30FP50-55 NEMESIS 5102 Universal hardness tester, 50gf - 250kgf NEMESIS 5102 Quick change anvil base (required for mounting testing tables, anvils) AS5000-450 Our vision, your future... - Page 13 ACCESSORIES ACCESSORIES OVERVIEW CAMERA OBJECTIVES Test tables Testing table fl at ø200mm, screwfi x UN-TESTTABLE/010 Testing tabe fl at ø235mm, screwfi x UN-TESTTABLE/012 20x Long Working Distance objective 0.7x Objective with Ringlight for Brinell 0.7x Objective with Ringlight for Brinell Large fl at surface testing table 350x250mm, thickness 30mm with 2 T-slots, for UN-TESTTABLE/015 large components...
- Page 14 FALCON 600 ANVILS FIXTURES AND VICES Our vision, your future... AS3000-19-04 UN-TESTTABLE/002 UN-TESTTABLE/002 UN-ANVIL/010 UN-ANVIL/010 UN-ANVIL/011 UN-ANVIL/011 UN-CVANVIL680 UN-CVANVIL50200 UN-AXLECHUCK UN-CLAMP/105 UN-CLAMP/115 UN-VBLOCK404050 UN-CROSSBLOCK01 UN-ANVIL/005 UN-ANVIL/006 UN-ANVIL/040 UN-WIRE/105 UN-JOMFIX1 UN-JOMFIX3 UN-VICE/115 10gf 10kgf 10 kgf HARDNESS SCALES UN-ANVIL/050 31.25kgf 10 kgf UN-ANVILSV/105 UN-ANVILSV/106 UN-ANVIL/045...
- Page 15 "Powerfull External Intell Core i7 PC, with 16gb RAM, and 512gb SSD drive UN-SYSPCIMP01 STANDARD (or better) Windows 10 pre-installed, IMPRESSIONS™ tester work fl ow software Automatic focussing UN-AUTOFOC STANDARD INNOVATEST recommends Embedded Industrial computers with DeepFreeze Our vision, your future... enabled." Report confi gurator UN-REPORTA STANDARD Blue Tooth connectivity...
-
Page 16: Specifications
Electronic system High performance embedded controller, i7, mSSD 120 GBxx, Standard (Recommended) MS Windows® 10 operated , up to 8 years* INNOVATEST warranty Kic Fracture toughness All Vickers forces & scales Electronic system High performance external controller, i7, mSSD 120 GBxx, (Optional) MS Windows®... -
Page 17: Technical Drawings
REV-DESCRIPTION: REV-DATE: TOLERANCES GENERAL NOTES: (UNLESS OTHERWISE SPECIFIED). (UNLESS OTHERWISE SPECIFIED). ISO 2768-mK. CORPORATE HEADOFFICE. INNOVATEST Shanghai Co., Ltd SALES & SERVICE CHINA & ASIA INNOVATEST Europe BV. MANUFAC, SALES & SERVICE. DRAWN BY: DRAWN DATE: SURFACE TREAT: SF FINISH:... - Page 18 Micro/Macro Vickers, Knoop information. IMPRESSIONS™ 12” full color touch & Brinell Hardness testers screen. Descending test head, Brochure B18 5100/10/EN See brochure B19N7700/XX fi xed work piece position www.innovatest-europe.com See brochure B18N9100/XX...
- Page 19 Phone: +31 43 3520060 Fax: +31 43 3631168 info@innovatest-europe.com www.innovatest-europe.com INNOVATEST USA Company INNOVATEST Deutschland GmbH INNOVATEST Shanghai Co,. Ltd. Sales & Service Sales & Service Sales & Service Phone: +49 245 670 59 500 Phone: +86 21 60906200 Phone: +1 267 317 4300 info@innovatest-deutschland.com...
