Summary of Contents for INNOVATEST FALCON500
- Page 1 FALCON 500 Micro Hardness Tester | Vickers, Knoop, Brinell MANUAL / SEMI - FULLY AUTOMATED...
- Page 2 FALCON 500 FALCON 600 Unparalleled confi guration freedom… Our vision, your future... The FALCON 500 off ers a leading technology base for manual, automatic or fully automated testing of Micro and Macro Vickers, Knoop or Brinell assignments. A FORCE RANGE THAT SETS NEW STANDARDS! With a wide choices of test force confi gurations, answering any possible imagination, the FALCON 500 can be 2kgf FALCON 501...
- Page 3 BOUNDLESS Multi loadcell, ball bearing, force actuator INNOVATION OPTIONAL Optical zoom, auto focus, stage overview camera Z-AXIS BALL SCREW Precision movement Observe, Think, Try, Change... Rigidity and perpendicular indenter positioning are crucial to obtain Vickers indents with a perfect geometry. Re-invented, adjustable indenter actuators provide maintenance free, smooth force application, easy to access and easy to replace indenters.
- Page 4 TECHNOLOGY Changing the game... CONNECTIVITY, CONTROL & QUALITY ASSURANCE 6 POSITION PRECISION TURRET & OPTICAL SYSTEM The system has bi-directional in and output channels. Tester control can be conducted remotely and supports The 6 position turret is supplied as a standard feature on all 500 models and allows for instance, but not limited to robotic systems.
- Page 5 Science fi ction?... No, just reality ahead of schedule The Graphical User interface (GUI), contains industry preferred applications, and off ers easy to learn, advanced workfl ow control. A simple test can be set up and conducted in about 3 seconds… IMPRESSIONS layout &...
- Page 6 Easy to operate, time reducing solutions... VIDEO OVERLAY GRAPHIC PATTERN EDITOR The IMPRESSIONS pattern editor allows the user to create any number of test HARDNESS OF SCREW THREAD patterns with a large number of variable DECARBONIZED ZONE (ISO-898-1) settings. Create test patterns with great precision and freedom.
- Page 7 Yes, we can... SNAPSHOT FUNCTION The IMPRESSIONS pattern editor allows the user to create any number of test patterns with a large he IMPRESSIONS pattern editor allows the This handy function in IMPRESSIONS number of variable settings. Create test patterns with great precision and freedom. Verify the settings number of variable settings.
- Page 8 AUTOMATIC IMAGE EVALUATION AUTO FOCUS Fast & precise, observe how IMPRESSIONS fi nds focus from a large distance, as far as the travel of the Z-axis allows. Algorithms used for close distance ILLUMINATION SETTINGS autofocusing set new standards in AF speed. IMPRESSIONS software automatic illumination system adapts to the correct illumination regardless of the sample surface quality, wherever on the sample, independent from material (steel, carbide,...
- Page 9 AMMUNITION TESTING PATTERN CONFIGURATOR & REPORTING This application is developed in close cooperation with special manufacturers of ammunition shells and casings. It allows single and multiple shell/casing testing according to the requirements in the industry. The fully automatic test procedure generates a detailed report, providing single readings and statistics with Go/No indication.
- Page 10 1.5mm chemical resistant plastic plating, edges made of shock resistant 3mm ABS side liner • Industrial quality, for workshop or laboratory Additional screen Designed for hardness testing instruments, painted in INNOVATEST® RAL colors matching our testers. 15” 55” Embedded sample holders Fixtures & vices Keyboard &...
-
Page 11: Order Details
ORDER DETAILS FALCON 500 FALCON 501 Micro hardness tester, 3gf - 2kgf FALCON 501 Fixtures and V Groove clamp for small round parts dia. 0.8-5 mm UN-VGROOVECLAMP vices FALCON 503 Micro hardness tester, 10gf - 10kgf FALCON 503 Axle chuck UN-AXLECHUCK FALCON 505 Micro hardness tester, 200gf - 31.25kgf FALCON 505... - Page 12 ACCESSORIES ORDER DETAILS ACCESSORIES OBJECTIVES SOFTWARE Manual on-screen measurement UN-MANM STANDARD 2.5x Long Working Distance objective 10x Long Working Distance objective 50x Long Working Distance objective Automatic measurement UN-AUTOM STANDARD 5x Long Working Distance objective 20x Long Working Distance objective 100x Long Working Distance objective Automatic focussing UN-AUTOFOC...
-
Page 13: Specifications
SPECIFICATIONS HARDNESS SCALES TURRET VICKERS HV0.001 | HV0.002 | HV0.003 | HV0.004 | HV0.005 | HV0.006 | HV0.007 | HV0.008 | HV0.009 Motorized turret Ultra-fast, 6 position turret, 2 indenter positions, 4 objective positions HV0.010 | HV0.015 | HV0.020 | HV0.025 | HV0.050 | HV0.1 | HV0.2 | HV0.3 | HV0.5 | HV1 | HV2 Objectives Long working distance 2.5x, 5x, 10x, 20x, 50x, 100x ISO 6507... -
Page 14: Technical Drawings
We recommend you See brochure B18F5000/XX See brochure B18F5000/XX to contact our sales offi ce for up-to-date information. Brochure B18 500/08/EN www.innovatest-europe.com © All rights reserved, 2018... - Page 15 Phone: +31 43 3520060 Fax: +31 43 3631168 info@innovatest-europe.com www.innovatest-europe.com INNOVATEST USA Company INNOVATEST Deutschland GmbH INNOVATEST Shanghai Co,. Ltd. Sales & Service Sales & Service Sales & Service Phone: +49 245 670 59 500 Phone: +86 21 60906200 Phone: +1 267 317 4300 info@innovatest-deutschland.com...
