Summary of Contents for Marvel MACL215-IS01B
- Page 1 GE T TING STARTED QUICK REFERENCE GUIDE MAR VEL CLEAR ICE MACHINES M A C L 2 1 5 - I S 0 1 B M A C L 2 1 5 - S S 0 1 B M A C P 2 1 5 - I S 0 1 B M A C P 2 1 5 - S S 0 1 B T H E O R I G I N A L R E F R I G E R AT I O N E X P E R T S S I N C E 1 8 9 2...
-
Page 2: Table Of Contents
State of California to cause birth defects or other reproductive harm. Got a Marvelous Design? We would love to see how your Marvel product looks in its WARNING new home. Send us photos at marketing@marvelrefriger- ation.com, and we might feature your Marvel home design... -
Page 3: Unpacking Your Appliance
UNPACKING YOUR APPLIANCE WARNING CAUTION If the appliance was shipped, handled, or stored in other EXCESSIVE WEIGHT HAZARD than an upright position for any period of time, allow the ap- Use two or more people to move product. pliance to sit upright for a period of at least 24 hours before Failure to do so can result in personal injury. -
Page 4: Electrical
ELECTRICAL Electrical Connection A grounded 115 volt, 15 amp dedicated circuit is required. This product is factory equipped with a power supply cord that has a three-pronged, grounded plug. It must be plugged into a mating grounding type receptacle in ac- cordance with the National Electrical Code and applicable Do not remove local codes and ordinances (see figure below). -
Page 5: Installing Your Appliance
- even if they sit out for "just a few hours". ice production. For this reason it is important this area not be obstructed and the grille openings kept clean. Marvel follow the instructions below to help prevent does not recommend the use of a custom made grille as accidents. - Page 6 INSTALLING YOUR APPLIANCE Minimum Maximum WARNING Model Height Height " Electrical Shock Hazard " MLC**15 • Do not use an extension cord with this appliance. MOC**15 They can be hazardous and can degrade product Table A MP**15 performance. • electrical supply. •...
-
Page 7: Door Reversal
DOOR REVERSAL Door Reversing Instructions 1. Open door. 2. Loosen screw #1 and #2 using a Philips Screwdriver on top and bottom hinge. Slide door and remove the door from the unit. 3. Once door is removed, using a Philips Screwdriver remove screws from magnet actuator located on inside and bottom of door. -
Page 8: Using Your Electronic Control
Time to reach set point varies based upon ambient temperature, temperature of product loaded, door openings, etc. Marvel recommends allowing the unit to reach set points before loading. -
Page 9: Installing The Water Supply
INSTALLING THE WATER SUPPLY Water Supply CAUTION Observe and follow all local building codes when installing this appliance. This ice machine must be connected to a potable cold water supply line. delivering water pressure between a minimum of 20 psi and a maximum of 120 psi. Use 1/4"... -
Page 10: Installing The Drain Plumbing
INSTALLING THE DRAIN PLUMBING CAUTION Drain line coiled and This drain pump is designed to be installed in Marvel ice secured to the back of the machines only and approved for use with water only. cabinet. Uncoil, route to an appropriate drain and cut to length. -
Page 11: Ice Maker Operation
ICE MAKER OPERATION The Ice Making Process sheet is released and slides onto the grid cutter cutter’s heated fractional freezing to form a slab of ice that is clear and wires. The water containing the dissolved minerals is has less dissolved solids than the water it is produced drained after each freezing cycle. - Page 12 ICE MAKER OPERATION Ice Production The ice machine will keep producing ice until the ice machine’s bin is full and will restart automatically when In normal mode the ice machine will produce up to 39 ice needs to be replenished in the bin. The ice bin is pounds (17.7 kg) of clear ice in a 24-hour period when installed in a 72°F ambient with a 55°F water supply.
-
Page 13: Care And Cleaning
CAUTION Use only Marvel-approved ice machine cleaner and follow all label warnings and directions. Incorrect chemical usage, and any damage that may result, is not covered by warranty. Available to order Clear Ice Machine Cleaner, 4-oz. - Page 14 CARE AND CLEANING Refer to your cleaning solution instructions to determine the proper amount of cleaning solution to add based on evaporator plate. Pour the cleaning the fresh water reservoir. Splash shield Splash shield brackets Lift fascia door up to access evaporator plate Remove all of the ice from...
- Page 15 If Service is Required: It is strongly recommended to periodically inspect and • please contact your dealer or call Marvel Customer Service at 616-754-5601 for directions on how to obtain warranty coverage in your area. showing signs of corrosion should be replaced.
-
Page 16: Warranty
For designated Marvel Professional product, Marvel offers a one year extension of the two year warranty coverage from the date of purchase, free of charge. To take advantage of this third year warranty, you must register your product with Marvel within 60 days from the date of purchase at marvelrefrigeration.com and provide proof of purchase. - Page 18 Marvel Refrigeration 1260 E. Van Deinse St. Greenville MI 48838 616.754.5601 All specifications and product designs subject to change without notice. Such revisions do not entitle 4/30/2022 the buyer to corresponding changes, improvements, additions, replacements or compensation for previously purchased products.
