400W Metal Case Fog Machine
READ AND SAVE THESE INSTRUCTIONS FOR FUTURE
REFERENCE
IMPORTANT SAFETY INSTRUCTION
:
CAUTION
-Risk of burn, fire or electrical shock.
-For indoor use only.
-Please read instruction manual before using.
-Don't immerse in liquid.
I.FOG MACHINE TECHNICAL SPECIFICATIONS
Item Code: 5724042
Model: FM400-2
Rating Voltage: AC120V, 60Hz
Power: 400W
Ambient Temperature: -10 ~ 45°C
II. RECEIVER: TECHNICAL SPECIFICATIONS
Item Name: Receiver
Rating Voltage：AC120V,60Hz
Max. Current：5A
III.WIRELESS REMOTE:
TECHNICAL SPECIFICATIONS
Item Name: Wireless Remote
Working Voltage: 12V
Require:1 x 12V, 23A Battery( Included)
WARNING:
To prevent risk of personal injury, fire, and electric shock:
Never leave unit unattended while plugged in. Unplug when not in use.
Read all important safety instructions and cautions.
Connect only to a properly grounded outlet.
Place product on a flat, level surface and connect the cord to prevent the product from overturning.
For use only in covered areas. Keep unit dry, do not expose to rain or moisture. Do not immerse unit.
Leave enough space for good ventilation. Keep unit cool and away from other objects.
Use only with SVI Fog Liquid (sold separately).
Do not operate unit without fog liquid.
Pour fog liquid carefully to avoid spills which could result in electrical
shock. Do not use if liquid spills onto unit. Let unit dry completely before plugging in.
Do not overfill the liquid.
User Manual
Fuse: F5A, 125V !
Preheat Time: 5 ~ 6 Minutes
Fog Output: 2,000 CFM
Tank Capacity: 0.45 Liter
Dimensions: L230 X W110 X H190mm
L9 X W4.3 X H7.5inch
Model Number: FRC-4
Working Current：2.0mA
Model Number:IL-1
Working Current: 10mA
Advertisement
Table of Contents
Related Manuals for involight FM400-2
Summary of Contents for involight FM400-2
- Page 1 -Please read instruction manual before using. -Don’t immerse in liquid. I.FOG MACHINE TECHNICAL SPECIFICATIONS Item Code: 5724042 Fuse: F5A, 125V ! Model: FM400-2 Preheat Time: 5 ~ 6 Minutes Rating Voltage: AC120V, 60Hz Fog Output: 2,000 CFM Power: 400W Tank Capacity: 0.45 Liter Ambient Temperature: -10 ~ 45°C...
- Page 2 Keep away from flames and flammable/explosive substances to avoid fire or explosions. Never pour flammable liquids such as gas, perfume etc. into the fog machine. Keep product and fog liquid out of reach of children. Use only under adult supervision. Do not spray in the direction of flames or people.
- Page 3 STORAGE: It is important to keep fluid in the unit when storing for an extended period of time, it will keep the seal and the parts lubricated. 1. Remove the tank cap at the back of the fogger (power cord side). 2.
